Conformal Coated Inductors - Axial
ctparts.com
CTC5F Series
From 1.0 µH to 10,000 µH
Part
Number
CTC5F-1R0K
CTC5F-1R2K
CTC5F-1R5K
CTC5F-1R8K
CTC5F-2R2K
CTC5F-2R7K
CTC5F-3R3K
CTC5F-3R9K
CTC5F-4R7K
CTC5F-5R6K
CTC5F-6R8K
CTC5F-8R2K
CTC5F-100K
CTC5F-120K
CTC5F-150K
CTC5F-180K
CTC5F-220K
CTC5F-270K
CTC5F-330K
CTC5F-390K
CTC5F-470K
CTC5F-560K
CTC5F-680K
CTC5F-820K
CTC5F-101K
CTC5F-121K
CTC5F-151K
CTC5F-181K
CTC5F-221K
CTC5F-271K
CTC5F-331K
CTC5F-391K
CTC5F-471K
CTC5F-561K
CTC5F-681K
CTC5F-821K
CTC5F-102K
CTC5F-122K
CTC5F-152K
CTC5F-182K
CTC5F-222K
CTC5F-272K
CTC5F-332K
CTC5F-392K
CTC5F-472K
CTC5F-562K
CTC5F-682K
CTC5F-822K
CTC5F-103K
Not shown at actual size.
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
1200
1500
1800
2200
2700
3300
3900
4700
5600
6800
8200
10000
SPECIFICATIONS
Parts are available in ±10% tolerance only.
L Test
Freq.
(MHz)
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.25
.25
.25
.25
.25
.25
.25
.25
.25
.25
.25
.25
Q
Factor
Min.
47
46
45
43
45
46
44
44
44
47
50
50
49
55
44
45
46
49
45
53
52
49
51
45
45
57
56
60
58
60
54
67
60
60
60
57
65
45
49
47
50
47
43
43
44
45
43
42
49
Q Test
Freq.
(MHz)
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.79
.25
.25
.25
.25
.25
.25
.25
.25
.25
.25
.25
.25
SRF
Min.
(MHz)
140
130
115
105
100
92
85
75
70
65
55
50
46
44
49
45
40
38
34
29
27
25
21
10.5
10
9.7
8.5
8.0
7.5
7.0
6.5
6.2
5.7
4.7
4.5
4.2
3.8
1.5
1.2
1.0
0.97
0.92
0.84
0.80
0.74
0.73
0.66
0.54
0.47
DCR
Max.
Ω
(Ω)
0.07
0.093
0.12
0.14
0.19
0.28
0.35
0.4
0.55
0.72
1.02
1.32
1.62
2.0
0.8
0.89
0.96
1.19
1.37
1.93
2.11
2.23
2.7
2.44
3.12
3.6
4.1
4.4
5.0
5.8
6.4
7.4
9.5
10.5
11.8
13.0
17.5
22.1
26.5
29.9
33.8
47.3
53.0
73.8
81.6
98.9
111
119
137
Rated DC
Max.
(mA)
1900
1600
1300
1200
1100
950
800
750
650
550
500
475
450
400
620
610
600
500
490
410
400
380
370
360
325
290
275
260
250
240
225
200
180
174
168
152
135
115
110
105
99
83
80
67
63
56
54
52
49
Inductance
(µH)
Compliant
RoHS
CHARACTERISTICS
Description:
Axial leaded conformal coated inductor
Applications:
Used in less harsh environments. Ideal for less
critical RFL/EMI applications.
Operating Temperature:
-55°C to +125°C
Inductance Tolerance:
±10%
Rated Current:
Based on the inductance change within 10% of
initial value
Testing:
Inductance and Q are tested on an HP4285A at
specified frequency
Packaging:
Bulk pack or Tape & Reel, 5,000 parts per reel
Marking:
Parts are EIA color banded which indicates inductance
code and tolerance
Miscellaneous:
RoHS Compliant.
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
PHYSICAL DIMENSIONS
Size
mm
inches
A
Max.
9.52
0.375
B
Max.
4.44
0.175
C
Nom.
29.2
1.15
22 AWG
Nom.
0.6430
0.02535
09.14.09
CENTRAL
Manufacturer of Passive Components
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2009 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
