REVISION AD
DO NOT
SCALE FROM
THIS PRINT
((No OF POS + 4) x
.0500[1.270]) .008[.20]
FSH-1XX-XX-XXX-XX-XX-X-XX
No OF POSITIONS
-DH ROW SPEC:
-05 THRU -25
-RA ROW SPEC:
-05 THRU -46
(PER ROW)
[INCREMENTS OF 5 STD]
LEAD STYLE
-01
-02
-03
-04
OPTION
-TR: TAPE & REEL
(NOT AVAILABE WITH -RA OPTION)
OPTION
-C: POLYIMIDE FILM (USE K-DOT-.177-.281-.005)
(10 POSITION MIN) (SEE FIG 3, SHT 2)
(NOT AVAILABLE WITH -RA)
OPTION
-SL: SOLDER LOCKS
ROW/TAIL SPECIFICATION
-DH: DOUBLE HORIZONTAL
(USE FSH-XX-D-ES-XX-XX)
-RA: RIGHT ANGLE
(USE FSH-XX-D-ES-XX-XX)
.099 2.51 REF
.259 6.58 REF
.150 3.81
REF
.125 3.18
.040 1.02 REF
.040 1.00 REF
2
.135 3.43
REF
1
.050 1.27
REF
NOTES:
SEE NOTE 10
.016 0.41 SQ REF
PLATING SPECIFICATION
-L: LIGHT SELECTIVE (USE T-1S15-XX-L)
-F: FLASH SELECTIVE (USE T-1S15-XX-F)
-S: SELECTIVE GOLD/MATTE TIN TAIL (USE T-1S15-XX-S)
-LM: LIGHT SELECTIVE GOLD/MATTE TIN TAIL(USE T-1S15-XX-L)
-FM: FLASH SELECTIVE GOLD/MATTE TIN TAIL(USE T-1S15-XX-F)
-STL: SELECTIVE GOLD CONTACT, TIN/LEAD TAIL(USE T-1S15-XX-STL)
-FTL: FLASH SELECTIVE GOLD CONTACT, TIN/LEAD TAIL(USE T-1S15-XX-FTL)
(No OF POS x .0500
[1.270]) -.0500[1.270]
.160 4.06 REF
"A" (SEE NOTE 3)
C
.205±.010 5.21±0.25
SEE NOTE 7
T-1S15-03-XXX
[PIN 2]
T-1S15-03-XXX
[PIN 1]
.050 1.27
REF
C
.155 3.94 REF
SEE NOTE 2
SEE NOTE 5
.035 0.89
C
.025 0.64
(No OF POS + 2) x .0500
[1.270]
1.
C
REPRESENTS A CRITICAL DIMENSION.
2. COPLANARITY TO INCLUDE INSULATOR: .0060[.152].
3. MAXIMUM HEIGHT VARTIATION BETWEEN ROWS: .005[.13].
4. MINIMUM PUSHOUT FORCE: .5 LB.
5. MAXIMUM BURR ALLOWED [SHEARED TAILS]: .002[.05].
6. MAXIMUM ALLOWABLE BOW: .002[.05] INCH/INCH AFTER ASSEMBLY.
7. FIRST AND LAST PINS TO BE FLUSH TO .001 ABOVE OR BELOW LINE MADE BY BODY (SEE SHT 3).
8. MAX FLASH TO BE .015[.38].
C 9. END SHROUDS NOT TO BE CUT.
10. POSITIONS 13-28 (ONCE CUT) TO HAVE 1 TAB EVENLY SPACED BETWEEN
THE FIRST AND LAST CORE. POSITIONS 29-46 TO HAVE TWO TABS EVENLY SPACED
BETWEEN THE FIRST AND LAST CORES.
11. FOR POSITIONS 13-27, MIDDLE SHROUD WILL NOT BE CENTERED
FOR ODD POSITION PARTS.
12. FIRST AND LAST PINS TO BE FLUSH TO .004 ABOVE LINE MADE BY BODY AND PIN 1 (SEE SHT 4).
-DH: DOUBLE HORIZONTAL
[AVAILABLE IN POSITIONS -05 THRU -25]
FIG 1
.028 0.70
.085 2.15
.0495[1.26] REF
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN INCHES.
TOLERANCES ARE:
DECIMALS
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
.XX: .01[.3]
.XXX: .005[.13]
.XXXX: .0020[.051]
ANGLES
2
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
PATENT NUMBERS
6159045
MATERIAL:
DO NOT SCALE DRAWING
SHEET SCALE: 2.5:1
VECTRA E130i, COLOR: BLACK
TERMINAL: PHOS BRONZE, THICKNESS: .0160 SQ
.050 SHROUDED TERMINAL ASSEMBLY
FSH-1XX-XX-XXX-XX-XX-X-XX
9/8/1999
SHEET
1
OF
4
F:\DWG\MISC\MKTG\FSH-1XX-XX-XXX-XX-XX-X-XX-MKT.SLDDRW
BY:
DEANP
REVISION AD
-RA: RIGHT ANGLE
(SAME AS FIG 1, UNLESS OTHERWISE STATED)
[AVAILABLE IN POSITIONS -05 THRU -46]
FIG 2
-C: POLYIMIDE FILM
NOTE: "R" = USE MEASURED DIMENSION (REF)
"S" = {("R" - .1772[4.501]) / 2} .020[.51]
"R" (SEE NOTE)
"S"
(SEE NOTE)
.142 3.61
FIG 3
2 MAX SWAY
(ANY DIRECTION)
2 MAX TOE
(ANY DIRECTION)
.075 1.91
90°±3°
.050 1.27
T-1S15-03-XXX
"B"
.039±.010 0.990±0.25
.177 4.50 REF
.100 2.53
.050 1.27
.09 2.3
T-1S15-04-XXX
TUBE: PT-1-24-02-53
PLUG: TP-09
-DH
.025 0.64
SEE NOTE 11
PACKAGING VIEW
TUBE ALL POSITIONS
-RA
TUBE: PT-1-24-01-45
PLUG: TP-07
FIG 4
FSH-119-XX-XX-RA-XX
SHOWN
F:\DWG\MISC\MKTG\FSH-1XX-XX-XXX-XX-XX-X-XX-MKT.SLDDRW
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 2.5:1
.050 SHROUDED TERMINAL ASSEMBLY
FSH-1XX-XX-XXX-XX-XX-X-XX
9/8/1999
SHEET
2
OF
4
BY:
DEANP
REVISION AD
IN-PROCESS 1
"A"
.090±.005 2.29±0.13
IN-PROCESS 2
(AFTER FIRST ROW FORMED)
'F'
"A"
.245 6.22
PROPRIETARY NOTE
.004[0.10]
(TAILS ONLY)
DETAIL 'F'
SCALE 16 : 1
.001 0.03 MAX
(SEE NOTE 7)
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
SHEET SCALE: 2.5:1
.050 SHROUDED TERMINAL ASSEMBLY
FSH-1XX-XX-XXX-XX-XX-X-XX
9/8/1999
SHEET
3
OF
4
F:\DWG\MISC\MKTG\FSH-1XX-XX-XXX-XX-XX-X-XX-MKT.SLDDRW
BY:
DEANP
REVISION AD
'H'
.004[0.10]
(TAILS ONLY)
DETAIL 'H'
SCALE 16 : 1
.004 0.10 MAX
(SEE NOTE 12)
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
SHEET SCALE: 2.5:1
.050 SHROUDED TERMINAL ASSEMBLY
FSH-1XX-XX-XXX-XX-XX-X-XX
9/8/1999
SHEET
4
OF
4
F:\DWG\MISC\MKTG\FSH-1XX-XX-XXX-XX-XX-X-XX-MKT.SLDDRW
BY:
DEANP
