LAST UPDATED: August 22, 2007
L1795A BARRIER STRIP
These rugged 12 way terminal blocks are moulded in polyester, and are not subject to
accidental chipping.
The L1795A has one row of screw terminals and one row of right angle through-chassis
terminations for printed circuit boards.
CURRENT RATING:
15A (using screw or soldered connections at
70
°
C maximum ambient)
5A (with fast on connections)
-55
°
C to +100
°
C (ambient)
4 KV rms
<3 milliohms
>100 megohms
6.9mm (terminals to panel face)
2.8mm x 0.61mm for solderless snap on
connections or solder.
0.7 Nm
Moulding: polyester, black
Terminals: brass, tinned
Screws: steel, nickel plated 4 BA panhead
1.02mm +/- 0.8mm
None
TEMPERATURE RANGE:
VOLTAGE PROOF:
CONTACT RESISTANCE:
INSULATION RESISTANCE:
CREEPAGE RESISITANCE:
TERMINATIONS:
MAXIMUM TORQUE
(terminal screws):
MATERIALS:
P.C.B. PIN DIAMETER
APPROVALS
ORDERING REFERENCE: L1795A
Dialight BLP reserve the right to change without prior notice the information contained within this leaflet
Dialight BLP Ltd., Exning Road, Newmarket, Suffolk, CB8 0AX, England
Tel: +44 (0)1638 665161 Fax: +44 (0)1638 660718 email: sales@blpcomp.com http://www.blpcomp.com
A subsidiary of Dialight plc
