Solid State Devices, Inc.
14701 Firestone Blvd * La Mirada, Ca 90638
Phone: (562) 404-4474 * Fax: (562) 404-1773
ssdi@ssdi-power.com * www.ssdi-power.com
SZN4460NGC thru SZN4496NGC Series
And
SZN6485NGC thru SZN6491NGC Series
DESIGNER’S DATA SHEET
FEATURES:
Hermetic Mil-Temp Range COTS
Rated at 1.5 W
Available in Axial and Square Tab Surface Mount
(SMS) version
Tolerances of 5%, 2%, or 1% Available.
Replaces 1N4460 – 4496 and 1N6485 – 6491
Category III Metallurgical Bond
1.5 WATT
3.3 – 200 VOLTS
ZENER DIODES
Maximum Ratings
Nominal Zener Voltage
Maximum Zener Current
Forward Surge Current
(8.3 msec Puls)
Continuous Power
Operating and Storage Temp.
Thermal Resistance,
Junction to Lead
L=3/8” (Axial)
Symbol
Value
Units
V
Z
I
ZM
I
ZSM
P
D
Top
Tstg
R
θJL
R
θJE
3.3 - 200
7.2 - 433
.072 – 4.2
1.5
-65 to +175
-65 to +200
125
90
V
mA
A
W
ºC
ºC/W
ºC/W
AXIAL (__)
DIM
A
B
C
D
MIN.
.080”
.145”
1.00”
.028”
MAX
.107”
.181”
---
.034”
Thermal Resistance,
Junction to End Cap
(SMS)
Part Number/Ordering Information
6/
__
__ __
SZN
__
│
│
│
│
│
│
│
│
│
└
│
│
└
Screening
7/
NGC = Group A, HR Screening
│
│
& Group B Testing
│
│
└
Package Type
│
__
= Axial Leaded
│
SMS = Surface Mount Square Tab
│
└
Tolerance
__
= 5%
C = 2%
D = 1%
DIM
A
B
C
D
MIN.
.125”
.195”
.023”
Body to Tab Clearance: .003”
MAX.
.135”
.260”
.027”
SQUARE TAB (SMS)
Voltage/Family
4460 thru 4496: 6.2V thru 200V, See Table on Page 2
6485 thru 6491: 3.3V thru 5.6V, See Table on Page 2
All dimensions are prior to
soldering
Note
:
Burn-In: HTRB per 1038A, t=96hrs., T
A
=150°C @ 80% rated V
Z
NOTE:
All specifications are subject to change without notification.
SCD's for these devices should be reviewed by SSDI prior to release.
DATA SHEET #: Z00013B
DOC
Solid State Devices, Inc.
14701 Firestone Blvd * La Mirada, Ca 90638
Phone: (562) 404-4474 * Fax: (562) 404-1773
ssdi@ssdi-power.com * www.ssdi-power.com
SZN4460NGC thru SZN4496NGC Series
And
SZN6485NGC thru SZN6491NGC Series
Electrical Characteristics @ 25°C
PART
NUMBER
Nominal
Zener
Voltage
(note 1)
VZ @ IZT
VOLT
SZN6485
SZN6486
SZN6487
SZN6488
SZN6489
SZN6490
SZN6491
SZN4460
SZN4461
SZN4462
SZN4463
SZN4464
SZN4465
SZN4466
SZN4467
SZN4468
SZN4469
SZN4470
SZN4471
SZN4472
SZN4473
SZN4474
SZN4475
SZN4476
SZN4477
SZN4478
SZN4479
SZN4480
SZN4481
SZN4482
SZN4483
SZN4484
SZN4485
SZN4486
SZN4487
SZN4488
SZN4489
SZN4490
SZN4491
SZN4492
SZN4493
SZN4494
SZN4495
SZN4496
3.3
3.6
3.9
4.3
4.7
5.1
5.6
6.2
6.8
7.5
8.2
9.1
10.0
11.0
12.0
13.0
15.0
16.6
18.0
20.0
22.0
24.0
27.0
30.0
33.0
36.0
39.0
43.0
47.0
51.0
56.0
62.0
68.0
75.0
82.0
91.0
100.0
110.0
120.0
130.0
150.0
160.0
180.0
200.0
Zener
Test
Current
IZT
mA
76
69
64
58
53
49
45
40.0
37.0
34.0
31.0
28.0
25.0
23.0
21.0
19.0
17.0
15.5
14.0
12.5
11.5
10.5
9.5
8.5
7.5
7.0
6.5
6.0
5.5
5.0
4.5
4.0
3.7
3.3
3.0
2.8
2.5
2.0
2.0
1.9
1.7
1.6
1.4
1.2
Maximum
Zener
Impedance
(note 2)
ZZ @ IZT
Ohms
10
10
9
9
8
7
5
4
2.5
2.5
3
4
5
6
7
8
9
10
11
12
14
16
18
20
25
27
30
40
50
60
70
80
100
130
160
200
250
300
400
500
700
1000
1300
1500
Maximum Knee
Impedance
ZZK @ IZK
Ohms
400
400
400
400
500
500
600
200
200
400
400
500
500
550
550
550
600
600
650
650
650
700
700
750
800
850
900
950
1000
1100
1300
1500
1700
2000
2500
3000
3100
4000
4500
5000
6000
6500
7000
8000
Maximum Reverse
Leakage Current
Maximum
Continuous
Current
(note 3)
IZM
mA
433
397
366
332
304
280
255
230
210
191
174
157
143
130
119
110
95
90
79
71
65
60
53
48
43
40
37
33
30
28
26
23
21
19
17
16
14
13
12
11
9.5
8.9
7.9
7.2
Maximum
Surge
Current
(note 4)
IZSM
Amps
4.2
3.9
3.6
3.3
3.0
2.7
2.5
2.3
2.1
1.9
1.7
1.6
1.4
1.3
1.2
1.1
.95
.90
.79
.71
.65
.60
.53
.48
.43
.40
.37
.33
.30
.28
.26
.23
.21
.19
.17
.16
.14
.13
.12
.11
.095
.089
.079
.072
IR @ VR
µA
50
50
35
5.0
4.0
1.0
0.5
10.0
5.0
1.0
.50
.30
.30
.30
.20
.05
.05
.05
.05
.05
.05
.05
.05
.05
.05
.05
.05
.05
.05
.05
.25
.25
.25
.25
.25
.25
.25
.25
.25
.25
.25
.25
25
.25
VR (note 8)
Volts
1.0
1.0
1.0
1.0
1.0
1.0
2.0
3.72
4.08
4.50
4.92
5.46
8.00
8.80
9.60
10.40
12.00
12.80
14.40
16.00
17.60
19.20
21.60
24.00
26.40
28.80
31.2
34.4
37.6
40.8
44.8
49.6
54.4
60.4
65.6
72.8
80.8
88.0
96.0
104.0
120.0
128.0
144.0
160.0
mA
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
.5
.5
.5
.25
.25
.25
.25
.25
25
.25
.25
.25
.25
.25
.25
.25
.25
.25
.25
.25
.25
.25
.25
.25
.25
.25
.25
.25
.25
.25
.25
.25
.25
.25
.25
NOTES:
1/ All zener voltages are measured with an automated test set using a 35 msec test time. Longer or shorter test time will have a corresponding effect on the measured
value due to heating effects.
2/ Zener impedance is derived from the AC voltage divided by the AC current with RMS value of 10% of DC zener test current superimposed on the test current.
3/ Ratings based on maximum zener voltage of individual units (leaded units).
4/ Figures shown are for a peak sinusoidal surge current of 8.3 msec duration, non-repetitive. The 8.3 msec square pulse rating is 71% of the value shown.
5/ SSDI standard marking consists of a contrasting color cathode dot or band. Part number information is included on packaging labels.
6/ For Ordering Information, Price, and Availability- Contact Factory.
7/ Screening based on MIL-PRF-19500. Screening flows available on request.
8/
Voltages are shown for 5% tolerance devices.
NOTE:
All specifications are subject to change without notification.
SCD's for these devices should be reviewed by SSDI prior to release.
DATA SHEET #: Z00013B
DOC
