12SQ080 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > 12SQ080

Preview

12SQ080: DescriptionSCHOTTKY BARRIER RECTIFIERS; File Size87KB，2 Pages; ManufacturerHY Electronic; Websitehttp://www.hygroup.com.tw

Download Datasheet Compare View All

12SQ080 Overview

SCHOTTKY BARRIER RECTIFIERS

Preview

Download Datasheet

View All

12SQ030 thru 12SQ100

SCHOTTKY BARRIER RECTIFIERS

REVERSE VOLTAGE - 30 to 100Volts

FORWARD CURRENT - 12.0 Amperes

R-6

FEATURES

●Metal

of silicon rectifier , majority carrier conduction

●Guard

ring for transient protection

●Low

power loss,high efficiency

●High

current capability,low VF

●High

surge capacity

●For

use in low voltage,high frequency inverters,free

wheeling,and polarity protection applications

.360(9.1)

.340(8.6)

1.0(25.4)

MIN

.052(1.3)

DIA

.048(1.2)

2100

.360(9.1)

DIA

.340(8.6)

MECHANICAL DATA

●Case:

JEDEC R-6 molded plastic

●Polarity:

Color band denotes cathode

●Weight:

0.07 ounces , 2.1 grams

●Mounting

position: Any

measurement point

1.0(25.4)

MIN

Dimensions in inches and (millimeters)

MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS

Rating at 25℃ ambient temperature unless otherwise specified.

Single phase, half wave ,60Hz, resistive or inductive load.

For capacitive load, derate current by 20%

CHARACTERISTICS

Maximum Recurrent Peak Reverse Voltage

Maximum RMS Voltage

Maximum DC Blocking Voltage

Maximum Average Forward

Rectified Current

@Tc=95

℃

SYMBOL 12SQ030 12SQ035 12SQ040 12SQ045 12SQ050 12SQ060 12SQ080 12SQ100 UNIT

RRM

RMS

(AV)

24.5

31.5

100

Peak Forward Surge Current 8.3ms single half sine-

wave super imposed on rated load(JEDEC Method)

Peak Forward Voltage at 12A DC(Note1)

Maximum DC Reverse Current @Tj=25℃

at Rated DC Bolcking Voltage @Tj=100℃

Tyical Junction Capacitance (Note2)

Tyical Thermal Resistance (Note3)

Operating Temperature Range

Storage Temperature Range

NOTES:1.300us Pulse Width, 2%Duty Cycle.

FSM

θJC

STG

0.55

275

0.7

0.5

450

3.0

-55 to+200

0.8

℃/w

℃

2.Measured at 1.0 MHZ and applied reverse voltage of 4.0VDC.

3.Thermal Resistance Junction to case.

~ 220 ~

12SQ080 Related Products

	12SQ080	12SQ040	12SQ100	12SQ060	12SQ050	12SQ045
Description	SCHOTTKY BARRIER RECTIFIERS	SCHOTTKY BARRIER RECTIFIERS	SCHOTTKY BARRIER RECTIFIERS	SCHOTTKY BARRIER RECTIFIERS	SCHOTTKY BARRIER RECTIFIERS	SCHOTTKY BARRIER RECTIFIERS
Maker	-	HY Electronic	HY Electronic	HY Electronic	HY Electronic	HY Electronic
package instruction	-	O-PALF-W2	O-PALF-W2	O-PALF-W2	O-PALF-W2	O-PALF-W2
Reach Compliance Code	-	unknown	unknown	unknown	unknow	unknown
ECCN code	-	EAR99	EAR99	EAR99	EAR99	EAR99
Other features	-	FREE WHEELING DIODE, LOW POWER LOSS	FREE WHEELING DIODE, LOW POWER LOSS	FREE WHEELING DIODE, LOW POWER LOSS	FREE WHEELING DIODE, LOW POWER LOSS	FREE WHEELING DIODE, LOW POWER LOSS
application	-	EFFICIENCY	EFFICIENCY	EFFICIENCY	EFFICIENCY	EFFICIENCY
Shell connection	-	ISOLATED	ISOLATED	ISOLATED	ISOLATED	ISOLATED
Configuration	-	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE
Diode component materials	-	SILICON	SILICON	SILICON	SILICON	SILICON
Diode type	-	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE
Maximum forward voltage (VF)	-	0.55 V	0.8 V	0.7 V	0.7 V	0.55 V
JESD-30 code	-	O-PALF-W2	O-PALF-W2	O-PALF-W2	O-PALF-W2	O-PALF-W2
Maximum non-repetitive peak forward current	-	300 A	300 A	300 A	300 A	300 A
Number of components	-	1	1	1	1	1
Phase	-	1	1	1	1	1
Number of terminals	-	2	2	2	2	2
Maximum operating temperature	-	200 °C	200 °C	200 °C	200 °C	200 °C
Minimum operating temperature	-	-55 °C	-55 °C	-55 °C	-55 °C	-55 °C
Maximum output current	-	12 A	12 A	12 A	12 A	12 A
Package body material	-	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
Package shape	-	ROUND	ROUND	ROUND	ROUND	ROUND
Package form	-	LONG FORM	LONG FORM	LONG FORM	LONG FORM	LONG FORM
Maximum repetitive peak reverse voltage	-	40 V	100 V	60 V	50 V	45 V
Maximum reverse current	-	500 µA	500 µA	500 µA	500 µA	500 µA
surface mount	-	NO	NO	NO	NO	NO
technology	-	SCHOTTKY	SCHOTTKY	SCHOTTKY	SCHOTTKY	SCHOTTKY
Terminal form	-	WIRE	WIRE	WIRE	WIRE	WIRE
Terminal location	-	AXIAL	AXIAL	AXIAL	AXIAL	AXIAL
