BI4U-EM12-AP6X-H1141/S1589
Inductive Sensors
Features
■
M12 × 1 threaded barrel
■
Stainless steel, 1.4301
■
Factor 1 for all metals
■
Protection class IP68
■
Resistant to magnetic fields
■
Large switching distance
■
Recessed mountable
■
DC 3-wire, 10…30 VDC
■
NO contact, PNP output
■
M12 x 1 male connector
Wiring diagram
Technical data
Type
Ident. no.
Special version
Rated switching distance
Mounting conditions
Secured operating distance
Repeat accuracy
Temperature drift
Hysteresis
Ambient temperature
Operating voltage
Residual ripple
DC rated operational current
No-load current
Residual current
Isolation test voltage
Short-circuit protection
Voltage drop at
Wire breakage/Reverse polarity protection
Output function
Insulation class
Switching frequency
BI4U-EM12-AP6X-H1141/S1589
16348971
S1589 = With weldguard coating
4 mm
Flush
≤ (0,81 x Sn) mm
≤ 2 % of full scale
≤ ± 10 %
≤ ± 15 %, ≤ ‐25 °C v ≥ +70 °C
3…15 %
-30…+85 °C
10…30 VDC
≤ 10 % U
ss
≤ 200 mA
≤ 20 mA
≤ 0.1 mA
≤ 0.5 kV
yes / Cyclic
≤ 1.8 V
yes / Complete
3-wire, NO contact, PNP
÷
2 kHz
Functional principle
Inductive sensors detect metal objects contactless
and wear-free. Due to the patented multi-coil
system,
uprox®+
sensors have distinct advantages
over conventional sensors. They excel in largest
switching distances, maximum flexibility
and operational reliability as well as efficient
standardization.
TURCK Inc. | 3000 Campus Drive Minneapolis, MN 55441-2656 | Phone: 763-553-7300 | Application Support: 1-800-544-7769 | Fax 763-553-0708 | www.turck.com
1|3
BI4U-EM12-AP6X-H1141/S1589| 11/19/2019 15-29 | technical changes reserved
Technical data
Design
Dimensions
Housing material
Active area material
Max. tightening torque housing nut
Electrical connection
Vibration resistance
Shock resistance
Protection class
MTTF
Switching state
Threaded barrel,M12 × 1
52 mm
Stainless steel, V2A (1.4301)
Plastic, LCP
10 Nm
Connector, M12 × 1
55 Hz (1 mm)
30 g (11 ms)
IP68
874 years acc. to SN 29500 (Ed. 99) 40 °C
LED, Yellow
Mounting instructions
Mounting instructions/Description
Distance D
Distance T
24 mm
3xB
Diameter active area Ø 12 mm
B
All flush mountable
uprox®+
threaded barrel types
are also recessed mountable. Safe operation is
ensured if the sensor is screwed in by half a turn.
TURCK Inc. | 3000 Campus Drive Minneapolis, MN 55441-2656 | Phone: 763-553-7300 | Application Support: 1-800-544-7769 | Fax 763-553-0708 | www.turck.com
2|3
BI4U-EM12-AP6X-H1141/S1589| 11/19/2019 15-29 | technical changes reserved
Accessories
BST-12B
6947212
Mounting clamp for threaded barrel
sensors, with dead-stop; material: PA6
MW12
6945003
Mounting bracket for threaded barrel
sensors; material: Stainless steel A2
1.4301 (AISI 304)
BSS-12
6901321
Mounting clamp for smooth and
threaded barrel sensors; material:
Polypropylene
PN-M12
6905309
Impact protection nut for M12x1
threaded barrel devices; material:
Stainless steel A2 1.4305 (AISI 303)
Wiring accessories
Dimension drawing
Type
RKH4-2/TFE
Ident. no.
6935482
Connection cable, M12 connector, female,
straight, 3-pin, cable length: 2 m, sheath
material: PVC, grey; temperature range:
-25…+80 °C (in resting state), 0…+80 °C
(in motion); other cable lengths and types
available, see www.turck.com
RKH4-2/TFG
6934384
Connection cable, M12 connector, female,
straight, 3-pin, cable length: 2 m, sheath
material: TPE, grey; temperature range:
-40…+105 °C (in resting state), -25…+105
°C (in motion); other cable lengths and
types available, see www.turck.com
TURCK Inc. | 3000 Campus Drive Minneapolis, MN 55441-2656 | Phone: 763-553-7300 | Application Support: 1-800-544-7769 | Fax 763-553-0708 | www.turck.com
3|3
BI4U-EM12-AP6X-H1141/S1589| 11/19/2019 15-29 | technical changes reserved
