CV Series — Low and Medium Voltage Leaded Varistors
Description
The CV Series of transient surge suppressors are disc-shaped varistors that can be operated
continuously in low and medium voltage electronic circuits, as well as across AC power lines
Due to their radial lead construction, these components require very little mounting space. They
are available in five model sizes from 5 to 20mm and feature a wide range of AC operating
voltages from 50V to 680V.
Features
• AC operating voltage (Vrms) from 50V to 680V
• DC operating voltage (Vdc) from 65V to 820V
• Broad range of current and energy handling capability
• For RMS voltages
≤40V
see ZV leaded series
• 5 model sizes available from 5mm to 20mm
• UL, CAC, CEDD approved
• +85°C continuous operating temperature
General Technical Data
Climatic Category
Operating Temperature
Storage Temperature Range
Threshold Voltage Temperature Coefficient
Isolation Voltage Capability
Response Time
Insulation Resistance
40 / 85 / 56
-40°C to +85°C
-40°C to +125°C
≤0.05%/°C
>2.5kV
< 25 ns
>1 Gohm
In accordance with CECC 42 000
In accordance with CECC 42 000
In accordance with IEC 60068-1
In accordance with CECC 42 000
Standard Packaging Options / Quantities
Series
Voltage Range (Vrms)
Reel
11 – 17
20 – 75
95
115 – 130
140 – 150
175
CV
230
250 – 275
300
320
385
420
460 – 550
1,800
1,500
1,500
1,300
1,200
1,200
1,000
1,000
N/A
N/A
N/A
N/A
N/A
5mm
Bulk
1,500
1,500
1,500
1,500
1,500
1,500
1,000
1,000
N/A
N/A
N/A
N/A
N/A
Reel
1,500
1,500
1,500
1,300
1,200
1,200
1,000
1,000
900
N/A
N/A
N/A
N/A
7mm
Bulk
1,500
1,500
1,000
1,000
1,000
1,000
1,000
1,000
1,000
N/A
N/A
N/A
N/A
Reel
1,300
1,300
1,300
1,000
1,000
1,000
1,000
800
800
800
700
700
600
10mm
Bulk
600
600
600
500
500
500
500
500
500
500
400
400
400
Reel
N/A
700
600
600
600
500
500
400
400
400
400
300
300
14mm
Bulk
N/A
500
500
500
500
500
300
300
300
300
300
300
300
Reel
N/A
600
600
500
500
500
400
400
400
300
300
300
300
20mm
Bulk
N/A
300
300
300
300
300
300
300
200
200
200
200
200
How to Order
CV
SEI Type
1
Lead Style
140
Vrms
K
Tolerance
14
Disc Diameter
B
Packaging
Lead Style
1
5
Description
Straight
Kinked
Code
K
S
Tolerance
10%
Special
Size (mm)
5
7
10
14
20
Code
B
R
A
Description
Bulk
Tape and reel
Ammo
Toll Free: (888) SEI-SEIS
(888) 734-7347
www.seielect.com
41
email: marketing@seielect.com
CV Series — Low and Medium Voltage Leaded Varistors
Device Ratings and Dimensions
