108LBA160M2EC datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> 108LBA160M2EC

108LBA160M2EC: DescriptionCAPACITOR, ALUMINUM ELECTROLYTIC, NON SOLID, POLARIZED, 50 V, 2200 uF, THROUGH HOLE MOUNT; CategoryPassive components; File Size586KB，6 Pages; ManufacturerIllinois Capacitor; Websitehttp://www.illinoiscapacitor.com/

Download Datasheet Parametric View All

108LBA160M2EC Overview

CAPACITOR, ALUMINUM ELECTROLYTIC, NON SOLID, POLARIZED, 50 V, 2200 uF, THROUGH HOLE MOUNT

108LBA160M2EC Parametric

Parameter Name	Attribute value
negative deviation	20 %
Minimum operating temperature	-40 Cel
Maximum operating temperature	85 Cel
positive deviation	20 %
Rated DC voltage urdc	50 V
Processing package description	ROHS COMPLIANT
each_compli	Yes
EU RoHS regulations	Yes
state	Active
Capacitor type	ALUMINUM ELECTROLYTIC CAPACITOR
capacitance	2200 µF
dielectric materials	ALUMINUM
esr__mohm_	150.72
jesd_609_code	e3
leakage_current__ma_	2.2
Manufacturer Series	LBA
Installation features	THROUGH HOLE MOUNT
packaging shape	CYLINDRICAL PACKAGE
Package Size	Radial
polarity	POLARIZED
ipple_current__ma_	2000
series	LBA
tangent angle	0.2
terminal coating	MATTE TIN
Terminal shape	SNAP-IN
diameter	22 mm
length	25 mm
custom_capabilities	Capacitance Tolerance

Preview

Download Datasheet

View All

FEATURES

Multiple Case Sizes

High Voltage

–

High Current

APPLICATIONS

Operating Temperature

Range

Capacitance Tolerance

WVDC

Surge Voltage

SVDC

WVDC

Dissipation

tan δ

Factor

(120 Hz)

Leakage Current

@20°C, Rated WVDC

applied

WVDC

Impedance

Ratio

(120 Hz)

-25°C/+20°C

-40°C/+20°C

Filtering

–

Switching Power Supplies

-40°C to +85°C (10VDC to 250VDC)

-25°C to +85°C (350VDC to 500VDC)

+20% at 120 Hz, 20°C

.55

.45

.35

100

.25

100

120

100

160

200

160

.15

200

250

200

.15

250

300

250

.15

350

400

350

.15

400

450

400

.15

450

500

450

500

550

500

For capacitance values above 33000μF

add the following to the Dissipation factors values above

(capacitance-33000 μF)*0.1

10000 μF

Time

100

5 Minutes

3√CV

160

200

250

350

400

450

500

2000 hours with rated voltage applied at 85°C with full rated ripple current applied

Load Life

Capacitance Change

Dissipation Factor

Leakage Current

Capacitance Change

Dissipation Factor

<20% of initial measured value

<200% of maximum specified value

<100% of maximum specified value

1000 hours at 85°C with no voltage applied

Shelf Life

<20% of initial measured value

<200% of maximum specified value

Ripple Current

Multipliers

Leakage Current

<100% of maximum specified value

Frequency (Hz)

WVDC

120

10k

10 to 100

0.9

1.0

1.15

1.25

160 to 250

0.8

1.0

1.15

1.47

350 to 500

0.8

1.0

1.15

1.47

Feb-17
