ADE-ED6309/3 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Wireless rf/communication> Radio frequency and microwave> ADE-ED6309/3

ADE-ED6309/3: DescriptionDouble Balanced Mixer, 400MHz Min, 1600MHz Max, PLASTIC, CASE CD542, 6 PIN; CategoryWireless rf/communication Radio frequency and microwave; File Size137KB，3 Pages; ManufacturerMini-Circuits; Websitehttps://www.minicircuits.com

Download Datasheet Parametric Compare View All

ADE-ED6309/3 Overview

Double Balanced Mixer, 400MHz Min, 1600MHz Max, PLASTIC, CASE CD542, 6 PIN

ADE-ED6309/3 Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	Mini-Circuits
Reach Compliance Code	unknown
structure	COMPONENT
JESD-609 code	e0
Maximum operating frequency	1600 MHz
Minimum operating frequency	400 MHz
RF/Microwave Device Types	DOUBLE BALANCED
Terminal surface	Tin/Lead (Sn/Pb)
Maximum voltage standing wave ratio	1.99
Base Number Matches	1

Preview

Download Datasheet

View All

Frequency Mixers

print this page

Notes:

•

Non-catalog model. Please

•

consult factory for price and

delivery.

For Surface Mount

Environmental Specifications,

please click

here.

Procedures and

Environmental Specifications

are given in

Mini- Circuits

Guarantees Quality.

Hi-Rel, MIL description are

given in

Hi-Rel and MIL

subjects to change without

notice.

ADE-ED6309/3

LO Power Level 10 dBm

Pin Configuration

Port LO RF IF Gnd Ext. Case Gnd Not Used

3 2

1,4,5

•

General Quality Control

•

Prices and Specifications

Outline Drawing

Electrical Specifications

ADE-ED6309/3

Frequency

MHz

LO/RF

LO Power Level 10 dBm

Conversion

LO-RF

LO-IF

Loss dB

Isolation dB Isolation dB

Mid-Band Total Range L M U L M U

400-1600 605-1000

L=low range(f

to 10f

) M=mid range(10f

to f

/2) U=upper range(f

/2 to f

)

Typical Performance Data

ADE-ED6309/3

MHz

Case Style - CD542

(inch,mm ) weight: 0.2 grams.

.280 .310 .220 .100 .112 .055 .100 .030 .030

7.112 7.874 5.588 2.540 2.845 1.397 2.540 0.762 0.762

.065 .300

1.651 7.620

Tolerance: .x ± .1 .xx ± .03 .xxx ± .015 inch.

Material and Finish:

Case material: plastic. Lead finish: tin-lead plate or tin plate.

Packaging:

Packaging information:

Tape Width(mm): 16

Reel Size(inches): 13

Device Cavity Pitch(mm): 12

Devices Per Reel: 1000

MHz

Conversion

Loss (dB)

LO LO LO

+7 +10 +13

dBm dBm dBm

Isolation L-R

(dB)

LO LO LO

+7 +10 +13

(MHz)

dBm dBm dBm

ISO

Isolation L-I (dB)

LO LO LO

+7 +10 +13

dBm dBm dBm

400.000 389.300 8.65 6.75 6.25

500.000 489.300 7.54 6.54 6.14

600.000 589.300 7.50 6.70 6.30

700.000 689.300 7.23 6.63 6.23

800.000 789.300 6.94 6.24 6.04

389.300 28.50 28.20 29.70 35.40 38.00 40.80

489.300 28.00 29.40 30.60 33.90 36.80 39.70

589.300 29.60 31.50 31.30 32.90 35.90 39.10

689.300 31.90 31.70 30.10 32.40 35.70 39.10

789.300 34.60 30.80 28.30 32.20 36.10 39.70

900.000 889.300 7.14 6.34 5.94 889.300 35.40 32.30 28.30 31.50 35.10 38.50

1000.000 989.300 7.22 6.52 6.02 989.300 31.00 30.60 28.80 30.60 34.10 37.90

1100.000 1089.300 6.97 6.27 5.87 1089.300 27.40 27.50 26.50 29.90 33.90 37.20

1200.000 1189.300 6.74 6.14 5.94 1189.300 25.20 25.20 24.30 30.20 35.60 39.70

1300.000 1289.300 6.70 6.30 6.20 1289.300 22.70 23.00 22.40 31.90 40.30 46.10

1400.000 1389.300 6.95 6.75 6.65 1389.300 21.10 21.50 21.40 32.20 40.20 39.80

1420.000 1409.300 7.10 6.90 6.80 1409.300 21.00 21.40 21.30 32.00 39.00 38.30

1425.000 1414.300 7.12 6.92 6.82 1414.300 20.90 21.30 21.30 32.10 39.10 38.00

1430.000 1419.300 7.12 6.92 6.82 1419.300 20.80 21.30 21.40 31.90 38.70 37.90

1435.000 1424.300 7.12 6.92 6.92 1424.300 20.80 21.30 21.30 31.90 38.50 37.60

1440.700 1430.000 7.09 6.99 6.89 1430.000 20.70 21.30 21.30 32.20 38.30 37.40

1445.000 1434.300 7.16 7.06 6.96 1434.300 20.70 21.30 21.30 31.80 38.20 37.30

1450.000 1439.300 7.19 7.09 6.99 1439.300 20.70 21.20 21.30 31.60 37.70 37.20

1500.000 1489.300 7.44 7.24 7.14 1489.300 20.50 21.10 21.30 30.60 35.90 35.70

1600.000 1589.300 7.90 7.60 7.60 1589.300 19.80 20.70 21.30 28.20 31.90 32.60

RF/LO

VSWR RF port

VSWR LO port

VSWR IF port

FREQ.

+10 +13

(MHz)

dBm dBm dBm dBm dBm dBm

389.300

489.300

589.300

689.300

789.300

7.00

3.64

2.40

1.75

1.40

3.50

2.43

1.94

1.69

1.49

1.50

1.46

1.38

1.39

1.48

1.51

1.54

3.06

2.65

2.46

2.35

2.25

2.30

2.20

2.04

2.03

2.04

2.10

2.37

2.04

2.12

2.01

1.85

2.03

1.97

1.70

1.37

1.12

1.02

1.05

1.70

1.65

1.77

1.66

1.50

1.58

1.63

1.44

1.25

1.18

1.17

1.18

1.19

1.48

1.41

1.55

1.48

1.41

1.33

1.39

1.32

1.25

1.26

1.27

1.28

FREQ.

+10 +13

(MHz)

dBm dBm dBm

1.000

1.710

3.477

7.071

10.700

14.380

29.242

40.000

1.96

1.75

1.56

1.38

1.32

1.28

1.23

1.22

1.97

1.77

1.56

1.36

1.27

1.23

1.16

1.15

1.13

1.10

1.09

1.07

1.99

1.78

1.57

1.34

1.25

1.20

1.12

1.11

1.09

1.06

1.08

1.07

1.05

889.300 1.17

989.300 1.14

1089.300 1.13

1189.300 1.26

1289.300 1.40

1389.300 1.60

1409.300 1.63

1414.300 1.64

59.465 1.20

120.924 1.16

245.902 1.15

500.050 1.15

541.712 1.13
