Part Number

Search

536434-9

Description
CONNECTOR, 32 CONTACT(S), FEMALE, RIGHT ANGLE TWO PART EURO CONNECTOR, SOLDER, RECEPTACLE
CategoryThe connector    The connector
File Size103KB,1 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Download Datasheet Parametric View All

536434-9 Overview

CONNECTOR, 32 CONTACT(S), FEMALE, RIGHT ANGLE TWO PART EURO CONNECTOR, SOLDER, RECEPTACLE

536434-9 Parametric

Parameter NameAttribute value
Reach Compliance Codeunknow
Other featuresSTANDARD: DIN 41612
Body/casing typeRECEPTACLE
Connector typeBOARD EURO CONNECTOR
Contact to complete cooperationNOT SPECIFIED
Contact point genderFEMALE
DIN complianceYES
Filter functionNO
IEC complianceNO
MIL complianceNO
Manufacturer's serial number536434
Mixed contactsNO
Installation methodRIGHT ANGLE
Installation typeBOARD
Number of rows loaded2
OptionsGENERAL PURPOSE
Terminal pitch2.54 mm
Termination typeSOLDER
Total number of contacts32
UL Flammability Code94V-0
Base Number Matches1
C orporate Hom e
|
Electronic Components
|
Se gm e nts
|
W ho W e Are
My Account
Searc h
Products
Documentation
Resources
My Account
Customer Support
Home
>
Products
>
By Type
>
Eurocard C onnectors
>
Product Feature Selector
> Product Details
536434-9 Product Details
Live Product Chat
Product Photo
Eurocard Type R
Not re vie we d for R oHS C om plia nce
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
536434-9
T E I nternal N umber: 5 3 6 4 3 4 - 9
Product Highlights:
l
Receptacle
l
Number of Positions = 32
l
PC B Mount Angle = Right Angle
l
No PC B Retention Feature
l
Post Type = Solder Post
View all Features
Obsolete
C ontact Product Information C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Documents are temporarily unavailable. We are working hard to correct the problem. Please try
again later.
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= Receptacle
l
Number of Positions
= 32
l
PC B Mount Angle
= Right Angle
l
PC B Retention Feature
= No
l
Post Type
= Solder Post
l
Mating Polarization
= Without
l
Guides
= Without
l
Make First / Break Last
= No
l
DIN Level
= III
l
PC B Thickness (Minimum) (mm [in]) = 1.57 [0.062]
l
C olor = Gray
Termination Related Features:
l
Termination Post Length (mm [in])
= 4.24 [0.166]
Body Related Features:
l
C ontact C ross Section (mm [in]) = 0.30 x 0.61 [.012 x .024]
l
Rows Loaded
= A, C
Contact Related Features:
l
C ontact Base Material = Phosphor Bronze
Housing Related Features:
l
Housing Material = Polyester
l
Housing Flammability Rating = UL 94V-0
Industry Standards:
l
RoHS/ELV C ompliance
= Not reviewed for ELV/RoHS compliance
l
Lead Free Solder Processes
= Not reviewed for lead free solder
process
l
Flux-Tight C oating
= Without
Other:
l
Brand = AMP
Provide Website Feedback
|
Need Help?
Home
|
C ustomer Support
|
Suppliers
|
Site Map
|
Privacy Policy
|
Browser Support
©
2009 Tyco Electronics C orporation All Rights Reserved
