CD-TCE065-0502
Multi-layer Power Inductor：MIPWTseries
（Low
Height Type）
Features
•
•
•
•
0.8mm in height : Corresponding to IC becoming low
CAE and fine printing technology
Stable minimum DC resistance in the class
High speed mounting: Using SMT mounter makes less than
a second mounting possible
•
Excellent mounting strength by SMD chip making
•
Completely lead-free product and support lead-free solder
MIPseries
(t=1.0mmMAX)
MIPWTseries
(t=0.8mmMAX)
Applications
•
DC-DC converters and power modules used for the following
equipments.Compact electrical instruments such as cellular
phones, DSC,DVC, PDA, DVD and HDD.
MIPWT3226D2R2
2.2±30％
0.1±30％
1.1
40 max
MIPWT3226D3R0
3.0±30％
0.12±30％
1.0
MIPWT3226D4R2
4.2±30％
0.14±30％
0.9
Specifications
Product name
Inductance
（μH）
at 1MHz
DC resistance (Ω)
Rated current（A）
*1
Weight（mg）
MIPWT3226D1R5
1.5±30％
0.09±30％
1.2
*1：In case temperature rise to 40°C due to self-heating. Operating temperature range: -40~85°C
In du c t an c e VS Fr e qu e n c y
5
MIPWT3226D4R2
4
4
5
Inducta nce V S D C B i a s Current
MIPWT3226D4R2
MIPWT3226D3R0
MIPWT3226D2R2
3
In du c t a n c e (μH)
MIPWT3226D3R0
3
MIPWT3226D2R2
2
1
0
0.1
1
Fr e qu e n c y (M Hz)
10
100
MIPWT3226D1R5
Ind uctance(μH)
MIPWT3226D1R5
2
1
0
0
0.2
0.4
0.6
0.8
1
DC Bias Current（A）
Shapes and Dimensions
0.3∼0.8
Recommended land pattern
2.6±0.2
2.1±0.4
4.0±0.3
3.2
±
0.2
3.2
±
0.2
0.8max
2.8±0.3
(mm)
As of Jan, 2005
■
The description in this catalogue is subject to change without notice.
FDK CORPORATION Electronics Sales Div.
TEL: 81-3-5473-4662(DIR)
http://www.fdk.com
FAX: 81-3-3434-1037
