DMD1020-A: Description2 CHANNEL, UHF BAND, Si, N-CHANNEL, RF POWER, MOSFET, D1, 5 PIN; CategoryDiscrete semiconductor The transistor; File Size194KB，6 Pages; ManufacturerSEMELAB

Download Datasheet Parametric Compare View All

DMD1020-A Overview

2 CHANNEL, UHF BAND, Si, N-CHANNEL, RF POWER, MOSFET, D1, 5 PIN

DMD1020-A Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	SEMELAB
package instruction	FLANGE MOUNT, R-XDFM-F4
Contacts	5
Reach Compliance Code	compliant
ECCN code	EAR99
Shell connection	SOURCE
Configuration	COMMON SOURCE, 2 ELEMENTS
Minimum drain-source breakdown voltage	70 V
Maximum drain current (ID)	25 A
FET technology	METAL-OXIDE SEMICONDUCTOR
highest frequency band	ULTRA HIGH FREQUENCY BAND
JESD-30 code	R-XDFM-F4
Number of components	2
Number of terminals	4
Operating mode	ENHANCEMENT MODE
Maximum operating temperature	200 °C
Package body material	UNSPECIFIED
Package shape	RECTANGULAR
Package form	FLANGE MOUNT
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Polarity/channel type	N-CHANNEL
Certification status	Not Qualified
surface mount	YES
Terminal form	FLAT
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
transistor applications	AMPLIFIER
Transistor component materials	SILICON
Base Number Matches	1

Preview

Download Datasheet

View All

TetraFET

DMD1020

DMD1020-A

METAL GATE RF SILICON FET

MECHANICAL DATA

(2 pls)

(typ)

(2 pls) A

(4 pls)

GOLD METALLISED

MULTI-PURPOSE SILICON

DMOS RF FET

150W – 28V – 400MHz

PUSH–PULL

FEATURES

• SUITABLE FOR BROAD BAND APPLICATIONS

PIN 2

PIN 4

• SIMPLE BIAS CIRCUITS

• ULTRA-LOW THERMAL RESISTANCE

• BeO FREE

PIN 1

PIN 3

PIN 5

SOURCE (COMMON)

DRAIN 2

GATE 1

DRAIN 1

GATE 2

DIM

Millimetres

15.24

10.80

45°

9.78

8.38

27.94

1.52R

10.16

21.84

0.10

1.96

1.02

4.45

34.04

1.63R

Tol.

0.50

0.13

5°

0.13

0.15

0.23

0.02

0.13

0.38

0.13

Inches

0.600

0.425

45°

0.385

0.330

1.100

0.060R

0.400

0.860

0.004

0.077

0.040

0.175

1.340

0.064R

Tol.

0.020

0.005

5°

0.005

0.006

0.009

0.001

0.005

0.015

0.005

• LOW Crss

• HIGH GAIN – 13 dB MINIMUM

APPLICATIONS

•

VHF/UHF COMMUNICATIONS

from 1 MHz to 500 MHz

DSS

GSS

D(sat)

stg

* Per Side

Power Dissipation

Drain – Source Breakdown Voltage *

Gate – Source Breakdown Voltage*

Drain Current*

Storage Temperature

Maximum Operating Junction Temperature

760W (389W -A Version)

70V

±20V

25A

–65 to 150°C

200°C

Semelab Plc reserves the right to change test conditions, parameter limits and package dimensions without notice. Information furnished by Semelab is believed

to be both accurate and reliable at the time of going to press. However Semelab assumes no responsibility for any errors or omissions discovered in its use.

Semelab encourages customers to verify that datasheets are current before placing orders.

Semelab plc.

Telephone +44(0)1455 556565. Fax +44(0)1455 552612.

E-mail:

sales@semelab.co.uk

Website:

http://www.semelab.co.uk

Document Number 6984

Issue 1
