MUR3020WT

Description
15A, 200V, SILICON, RECTIFIER DIODE, TO-247AE
CategoryDiscrete semiconductor    diode
File Size104KB,6 Pages
ManufacturerMotorola ( NXP )
Websitehttps://www.nxp.com
Download Datasheet Parametric Compare View All

MUR3020WT Online Shopping

Suppliers Part Number Price MOQ In stock
MUR3020WT - - View Buy Now

MUR3020WT Overview

15A, 200V, SILICON, RECTIFIER DIODE, TO-247AE

MUR3020WT Parametric

Parameter NameAttribute value
MakerMotorola ( NXP )
package instructionR-PSFM-T3
Reach Compliance Codeunknown
Other featuresFREE WHEELING DIODE
applicationPOWER
Shell connectionCATHODE
ConfigurationCOMMON CATHODE, 2 ELEMENTS
Diode component materialsSILICON
Diode typeRECTIFIER DIODE
Maximum forward voltage (VF)1.05 V
JEDEC-95 codeTO-247AE
JESD-30 codeR-PSFM-T3
JESD-609 codee0
Maximum non-repetitive peak forward current200 A
Number of components2
Phase1
Number of terminals3
Maximum operating temperature175 °C
Minimum operating temperature-65 °C
Maximum output current15 A
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formFLANGE MOUNT
Certification statusNot Qualified
Maximum repetitive peak reverse voltage200 V
Maximum reverse current10 µA
Maximum reverse recovery time0.035 µs
surface mountNO
Terminal surfaceTin/Lead (Sn/Pb)
Terminal formTHROUGH-HOLE
Terminal locationSINGLE
Base Number Matches1
MOTOROLA
SEMICONDUCTOR TECHNICAL DATA
Order this document
by MUR3020WT/D
SWITCHMODE
Power Rectifiers
. . . designed for use in switching power supplies, inverters and as free
wheeling diodes, these state–of–the–art devices have the following features:
Ultrafast 35 and 60 Nanosecond Recovery Time
175°C Operating Junction Temperature
Popular TO–247 Package
High Voltage Capability to 600 Volts
Low Forward Drop
Low Leakage Specified @ 150°C Case Temperature
Current Derating Specified @ Both Case and Ambient
Temperatures
Epoxy Meets UL94, VO @ 1/8″
High Temperature Glass Passivated Junction
Mechanical Characteristics
Case: Epoxy, Molded
Weight: 4.3 grams (approximately)
Finish: All External Surfaces Corrosion Resistant and Terminal
Leads are Readily Solderable
Lead Temperature for Soldering Purposes: 260°C Max. for 10
Seconds
Shipped 30 units per plastic tube
Marking: U3020, U3040, U3060
MAXIMUM RATINGS, PER LEG
Rating
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
Average Rectified Forward Current @ 145°C
Total Device
Peak Repetitive Surge Current
(Rated VR, Square Wave, 20 kHz, TC = 145°C)
Nonrepetitive Peak Surge Current
(Surge applied at rated load conditions,
halfwave, single phase, 60 Hz)
Operating Junction and Storage Temperature
IFM
IFSM
200
Symbol
VRRM
VRWM
VR
IF(AV)
MUR3020WT
200
MUR3020WT
MUR3040WT
MUR3060WT
Motorola Preferred Devices
ULTRAFAST RECTIFIERS
30 AMPERES
200–400–600 VOLTS
1
2, 4
3
1
2
3
CASE 340K–01
TO–247AE
MUR3040WT
400
MUR3060WT
600
Unit
Volts
15
30
30
150
Amps
Amps
Amps
TJ, Tstg
– 65 to +175
°C
THERMAL CHARACTERISTICS, PER LEG
Maximum Thermal Resistance — Junction to Case
— Junction to Ambient
R
θJC
R
θJA
1.5
40
°C/W
ELECTRICAL CHARACTERISTICS, PER LEG
Maximum Instantaneous Forward Voltage (1)
(IF = 15 Amp, TC = 150°C)
(IF = 15 Amp, TC = 25°C)
Maximum Instantaneous Reverse Current (1)
(Rated DC Voltage, TJ = 150°C)
(Rated DC Voltage, TJ = 25°C)
Maximum Reverse Recovery Time
(iF = 1.0 A, di/dt = 50 Amps/µs)
(1) Pulse Test: Pulse Width = 300
µs,
Duty Cycle
2.0%.
SWITCHMODE is a trademark of Motorola, Inc.
Preferred
devices are Motorola recommended choices for future use and best overall value.
VF
0.85
1.05
iR
500
10
trr
35
60
1000
10
1.12
1.25
1.4
1.7
Volts
µA
ns
Rev 2
©
Rectifier
Inc. 1996
Data
Motorola,
Device
1
