BAT64-04
BAT64-05
BAT64-06
•
•
•
•
•
•
Lead Free Finish/Rohs Compliant ("P"Suffix designates
RoHS Compliant. See ordering information)
Halogen
free available upon request by adding suffix "-HF"
For low-loss, fast-recovery, meter protection,
bias isolation and clamping applications
Integrated diffused guard ring
Low forward voltage
Epoxy meets UL 94 V-0 flammability rating
Moisture Sensitivity Level 1
Small Signal Schottky
Diode
SOT-23
D
B
•
Maximum Ratings
Symbol
V
RM
IF
I
FSM
Pd
T
J
T
STG
Rthja
Parameter
Peak Reverse Voltage
Peak Forward Current
Forward Surge Current, tp=10ms
Power Dissipation , Tc=2
Junction Temperature
Storage Temperature
Thermal Resistance Junction to
Ambient
O
A
Rating
40
0.25
0.8
250
150
-55 to +125
Unit
V
A
A
mw
F
o
C/W
C
E
400
Electrical Characteristics @ 25 C Unless Otherwise Specified
Symbol
Parameter
Forward Voltage
(I
F
=1mAdc)
(I
F
=10mAdc)
(I
F
=30mAdc)
(I
F
=100mAdc)
Reverse Current
(V
R
=25Vdc)
Diode Capacitance
(VR=5V, f=1MHZ)
Min
---
---
---
---
---
Typ
---
---
---
---
---
Max
350
430
520
750
2
Units
G
H
J
K
DIMENSIONS
V
F
mVdc
I
R
µAdc
C
T
---
6
---
pF
DIM
A
B
C
D
E
F
G
H
J
K
INCHES
MIN
.110
.083
.047
.035
.070
.018
.0005
.035
.003
.015
MAX
.120
.104
.055
.041
.081
.024
.0039
.044
.007
.020
MM
MIN
2.80
2.10
1.20
.89
1.78
.45
.013
.89
.085
.37
MAX
3.04
2.64
1.40
1.03
2.05
.60
.100
1.12
.180
.51
NOTE
Suggested Solder
Pad Layout
.031
.800
.035
.900
.079
2.000
in
ches
mm
.037
.950
BAT64-06 MARKING:66S
BAT64-05 MARKING:65S
BAT64-04 MARKING:
64S
.037
.950
www.mccsemi.com
