Coaxial
Power Splitter/Combiner
2 Way-0° Resistive 50Ω
Maximum Ratings
Operating Temperature
Storage Temperature
Power Input (as a splitter)
Internal Dissipation
-55°C to 100°C
-55°C to 100°C
0.16W max.
0.08W max.
ZFRSC-123+
DC to 12000 MHz
Features
• very wideband, DC to 12000 MHz
• very good phase unbalance, 1 deg. typ.
• excellent amplitude unbalance, 0.1 dB typ.
• rugged shielded case
CASE STYLE: JJJ245
Connectors Model
Price
Qty.
SMA
ZFRSC-123-S+
$74.95 ea. (1-9)
Applications
• laboratory
• IP3 test set-ups
+ RoHS compliant in accordance
with EU Directive (2002/95/EC)
The +Suffix has been added in order to identify RoHS
Compliance. See our web site for RoHS Compliance
methodologies and qualifications.
Coaxial Connections
SUM PORT
PORT 1
PORT 2
S
1
2
Electrical Specifications T
AMB
=25°C
FREQ.
RANGE
(MHz)
f
L
-f
U
DC-12000
ISOLATION
(dB)
L
U
Typ.
19.5
Typ.
3.5
INSERTION LOSS (dB)
ABOVE 6.0 dB
L
Max.
4.0
Typ.
3.5
U
Max.
4.0
PHASE
UNBALANCE
(Degrees)
L
Max.
3
U
Max.
5
AMPLITUDE
UNBALANCE
(dB)
L
Max.
0.25
U
Max.
0.4
Outline Drawing
Typ.
19.5
L = DC-6000 MHz
U = 6000-12000 MHz
This is a resistive power divider to enable frequency coverage from dc to the highest rated frequency. Since resistive power divider do not
provide a high degree of isolation (basically isolation equals the insertion loss between ports), an amplifier such as Mini-Circuits' ZVA
series is recommended when high isolation is required. Matched power rating 0.16W, internal load dissipation 0.08W.
Typical Performance Data
Frequency
(MHz)
Insertion Loss
(dB)
S-1
1.00
500.00
1000.00
2000.00
3000.00
4000.00
5000.00
6000.00
7000.00
8000.00
9000.00
10000.00
10500.00
11000.00
12000.00
9.61
9.67
9.70
9.71
9.74
9.76
9.74
9.73
9.73
9.63
9.59
9.51
9.41
9.33
9.27
Amplitude
Unbalance
(dB)
0.05
0.05
0.06
0.05
0.07
0.10
0.09
0.13
0.17
0.09
0.11
0.07
0.01
0.00
0.07
Isolation
(dB)
Phase
Unbalance
(deg.)
0.06
0.07
0.21
0.48
0.61
0.78
1.20
1.60
1.46
1.56
2.82
2.52
2.37
2.67
2.79
VSWR
S
VSWR
1
VSWR
2
S-2
9.56
9.62
9.64
9.66
9.67
9.66
9.65
9.60
9.56
9.54
9.48
9.43
9.40
9.34
9.21
19.32
19.32
19.32
19.29
19.34
19.50
19.62
19.56
19.24
19.12
19.60
20.10
20.05
19.69
18.66
1.01
1.02
1.02
1.02
1.04
1.05
1.06
1.06
1.07
1.09
1.15
1.21
1.22
1.23
1.20
ZFRSC-123+
ISOLATION
25
1.00
1.01
1.01
1.01
1.02
1.04
1.05
1.06
1.07
1.12
1.10
1.05
1.03
1.04
1.02
1.01
1.01
1.01
1.01
1.01
1.02
1.04
1.06
1.07
1.07
1.06
1.03
1.01
1.01
1.05
Outline Dimensions (
inch
)
mm
A
B
C
.75
1.00
.58
19.05 25.40 14.73
D
.38
9.65
E
.29
7.37
F
wt
.35 grams
8.89
22.0
ZFRSC-123+
INSERTION LOSS
12
INSERTION LOSS (dB)
S-1(dB)
11
10
9
8
7
0
3000
6000
FREQUENCY (MHz)
9000
12000
S-2(dB)
ISOLATION (dB)
22
19
16
13
10
0
3000
6000
FREQUENCY (MHz)
9000
12000
ZFRSC-123+
VSWR
1.4
1.3
VSWR
1.2
1.1
1.0
0
3000
6000
FREQUENCY (MHz)
9000
12000
EW
ALL N
#S-VSWR
#1-VSWR
#2-VSWR
electrical schematic
Mini-Circuits
ISO 9001 ISO 14001
CERTIFIED
RF/IF MICROWAVE COMPONENTS
®
minicircuits.com
REV. A
M116296
ZFRSC-123+
ED-13066/2
AD/CP
080225
