VOLTAGE-CONTROLLED CRYSTAL OSCILLATORS
MINIATURE CERAMIC • HCMOS • SURFACE MOUNT• 5Vdc or 3.3Vdc
ASLV and ASV V Series
FEATURES:
7.0 x 5.0 x 1.7 mm
APPLICATIONS:
• Low profile (1.7 mm) ceramic VCXO.
• Enable / Disable functions.
• 7.0 mm x 5.0 mm seam welded.
• Phase locked loops (PLLs).
• Synthesizers.
ASLV
• 5 Vdc or 3.3 Vdc.
• Suitable for reflow methods
.
• HCMOS/TTL output.
• Clock Recover, Digital transmission device.
• Digital set-top box.
ASV V
STA
Range
(F
S
Frequency
NDARD
o
)
PECIFICATIONS
(See Note)
1.544MHz -
155.52MHz
Operating Temperature (T
OPR
)
0°C to +70°C
(See Option)
Storage Temperature (T
STO
)
-40°C to +85°C
Frequency Stability
(DF/ F
o
)
±50ppm max.
(See Options)
Supply Voltage
(V
dd
)
5Vdc ±5%
3.3Vdc ±5%
Input Current
(I
dd
)
10mA max. for F < 20MHz 10mA max. for F < 20MHz
20mA max. for F < 40MHz
30mA max. for F < 60MHz
15mA max. for F < 40MHz
25mA max. for F < 60MHz
PARAMETERS
STANDARD SPECIFICATIONS
Duty Cycle or Symmetry
40 / 60% max.
(See Options)
Rise and Fall Times (T
R
/
T
F
)
8ns max.
Output Load
15pF or 2TT L
Output Voltage
(V
OH
)
0.9 *V
dd
min.
(V
OL
)
0.1*Vdd max.
Transfer Function
Positive
Voltage Control
(Vc)
2.5Vdc ±2.0V
1.65Vdc ±1.5V
Frequency Deviation
±100ppm min.
(See options)
±80ppm min.
(See options)
“1” or Open: Oscillation max.
> 2.2V
_
Linearity
±10%
“0”: (Hi Z)
< 0.8V
Start-up Time
(T
OSC
)
10ms max.
Output Disabled in high impedance
(V
IH
)
‘1’
OR
O
PEN
: O
SCILLATION
> 2.2V
Tristate Function
(V
IL
)
‘0’
(H
I
Z)
< 0.8V
Period jitter one sigma
±10ps max.
Period jitter abslute
±100ps max.
Dimensions: Inches (mm)
Note:
Higher frequencies
available. Please
call.
PIN
NO.
FUNCTION
Voltage Control Vc
Tristate E/D
GND / Case
Output
N / C
**
Vdd
A bypass capacitor 0.01 µF is required from Vdd to Gnd.
Please call us for higher frequencies. Test circuit, waveforms, see appendix B.
Environmental and mechanical specifications see appendix C, Group 2.
Marking, see appendix G. Tape and Reel, see appendix H.(1,000 pcs.reel).
Application notes, see appendix A. Recommended handling, see appendix F.
** pin 5 E/D
(ASLV1 or ASVV1)
Operating
Temperature
Range
0°C~50°C
-
0°C~60°C
-10°C~60°C
0°C~70°C
-10°C~70°C
-20°C~70°C
-40°C~85°C
code
I
B
D
C
F
E
L
0
1
2
3
4
5
6
Frequency stability (± ppm)
5ppm 10ppm 15ppm 20ppm 30ppm 50ppm
05
10
15
20
30
50
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
0
ORDERING OPTIONS
AS X V- Frequency - Temperature stability - Duty Cycle - Pulling - Packaging
L or V
-S for 45 / 55%
@
1
/
2 Vdd
N151 for ± 150ppm min.
N102 for ± 100ppm min.
N152 for ± 150ppm min.
@
Vc
@
Vc
@
Vc
XX.XXXXX MHz
-T
Tape and Reel
= 0V to 5Vdc*
= 0V to 3.0Vdc*
= 0V to 3.0Vdc*
ABRACON
60
0= available
ABRACON IS
ISO 9001 / QS 9000
CERTIFIED
®
NOTE: Left blank if standard
•
All specifications and markings subject to change without notice
C O R P O R AT I O N
29 Journey • Aliso Viejo, CA 92656 • USA
(949) 448-7070 •
F
AX
: (949) 448-8484
E-
MAIL
:
abinfo
@
abracon.com •
I
NTERNET
A
DDRESS
:
www.abracon.com
