EDGE
™
Solutions Hybrid Trunk, SMF-28
®
Ultra OS2, MTP
®
to LC Duplex Uniboot, 96
fibres
840/1000 mm leg lengths, no pulling grip, 20 m
EDGE MTP
®
trunks are preterminated cables with
12-fibre MTP connectors or LC duplex connectors on
either side. The trunks build up the major skeleton of the
passive network infrastructure, and thanks to the superior
design including Corning
®
ClearCurve
®
fibre, they enable
rapid deployment for your campus LAN or data centre
facility. All trunks are shipped with strain-relief clips that
allow for the tool-less installation in both EDGE Soluions
and Plug & Play™ Systems housings. These trunks con-
form to TIA-568 Type-B polarity.
Features and Benefits
Transition from multi-fibre into single-fibre environments
Feature non-pinned (male) MTP connectors on one end
and single-fibre connectors (LC Duplex Uniboot) on the
other
Single-fibre connector side to plug into sigle-fibre patch
panels or electronics ports
Non-pinned MTP side plugs into modules or harnesses.
Part Number: Z907896GLZ8LW020M
Standards
Intermateability
Flame Resistance
TIA/EIA-604-5 / TIA/
EIA-604-10
Flame retardant to IEC
60332-1-2 (single cable),
Zero Halogen to IEC
60754-1, Non Corrosive to
IEC 60754-2
Part Number: Z907896GLZ8LW020M
Product Specification Z907896GLZ8LW020M_AU_BEN
Page 1 | Revision date 2016-03-07
EDGE
™
Solutions Hybrid Trunk, SMF-28
®
Ultra OS2, MTP
®
to LC Duplex Uniboot, 96
fibres
840/1000 mm leg lengths, no pulling grip, 20 m
Specifications
General Specifications
Flame rating
Fibre Category
Cable assembly type
LSZH™/FRNC
SMF-28
®
Ultra fibre
Multi Fibre
Temperature Range
Operation
Installation and assembly
Storage
0 °C to 60 °C
0 °C to 50 °C
-25 °C to 70 °C
Design - Connector A
Connector Type
Ferrule Material
Polish
Housing material
Housing Colour
Boot type
Boot colour
Keyed (security)
MTP
®
(non-pinned)
Composite
APC
Composite
green
Individual
black
No
Mechanical Specifications - Connector A
Durability
Tensile strength jacketed cable
≤ 0.2 dB 200 rematings, FOTP-21
44 N
Optical Specifications - Connector A
Insertion loss, max.
≤ 0.25 dB
Design - Connector B
Connector Type
Ferrule Material
Polish
LC Duplex Uniboot
Ceramic
UPC
Product Specification Z907896GLZ8LW020M_AU_BEN
Page 2 | Revision date 2016-03-07
EDGE
™
Solutions Hybrid Trunk, SMF-28
®
Ultra OS2, MTP
®
to LC Duplex Uniboot, 96
fibres
840/1000 mm leg lengths, no pulling grip, 20 m
Design - Connector B
Housing material
Housing Colour
Boot type
Boot colour
Keyed (security)
Composite
Blue
Uniboot
Blue
No
Mechanical Specifications - Connector B
Durability
Tensile strength jacketed cable
≤ 0.2 dB 500 rematings, FOTP-21
44 N
Optical Specifications - Connector B
Reflectance, typical
Insertion loss, max.
≤ -58 dB
≤ 0.5 dB
Cable design
Polarity
Fibre Count
Outer diameter
Outer jacket colour
Outer jacket material
Min. Bend Radius Installation
Min. Bend Radius Operation
Crush resistance (reversible)
Tensile strength
Universal
96
9 mm
yellow
LSZH™/FRNC
90 mm
45 mm
750 N/10 cm
600 N
Furcation - Connector A
Leg length
Legs Count
Leg diameter
Fibre Count
Plug Type
Plug Dimensions
840 mm
8
2.9 mm
96
Size 2 EDGE™
108.6 x 20 x 20 mm
Product Specification Z907896GLZ8LW020M_AU_BEN
Page 3 | Revision date 2016-03-07
EDGE
™
Solutions Hybrid Trunk, SMF-28
®
Ultra OS2, MTP
®
to LC Duplex Uniboot, 96
fibres
840/1000 mm leg lengths, no pulling grip, 20 m
Furcation - Connector B
Legs Count
Leg length
Leg diameter
Fibre Count
48
1,000 mm
2 mm
96
Pulling grip - Connector A
Pulling grip - Connector A
No
Pulling grip - Connector B
Pulling grip - Connector B
No
Chemical Characteristics
RoHS
Free of hazardous substances according to RoHS 2002/95/
EG
Ordering Information
Part Number
Product Description
EAN Code
Length
Z907896GLZ8LW020M
EDGE™ Solutions Hybrid Trunk, SMF-28
®
Ultra OS2, MTP
®
Connector to LC Duplex Uniboot Connector, 96 fibres,
840/1000 mm leg lengths, no pulling grip, 20 m
4056418757261
20 m
Shipping Information
Packing type
Units Per Delivery
Plastic reel
1/1
Product Specification Z907896GLZ8LW020M_AU_BEN
Page 4 | Revision date 2016-03-07
EDGE
™
Solutions Hybrid Trunk, SMF-28
®
Ultra OS2, MTP
®
to LC Duplex Uniboot, 96
fibres
840/1000 mm leg lengths, no pulling grip, 20 m
Notes
Corning Optical Communications LLC • PO Box 489 • Hickory, NC 28603-0489 USA
800-743-2675 • FAX: 828-325-5060 • International: +1-828-901-5000 • www.corning.com/opcomm
A complete listing of the trademarks of Corning Optical Communications is available at www.corning.com/opcomm/trademarks.
All other trademarks are the properties of their respective owners. Corning Optical Communications is ISO 9001 certified.
© 2016 Corning Optical Communications. All rights reserved.
Product Specification Z907896GLZ8LW020M_AU_BEN
Page 5 | Revision date 2016-03-07
