BT137F-800

Description
800V, 8A, 4 QUADRANT LOGIC LEVEL TRIAC, PLASTIC, FULL PACK-3
CategoryAnalog mixed-signal IC    Trigger device
File Size45KB,7 Pages
ManufacturerNXP
Websitehttps://www.nxp.com
Download Datasheet Parametric Compare View All

BT137F-800 Overview

800V, 8A, 4 QUADRANT LOGIC LEVEL TRIAC, PLASTIC, FULL PACK-3

BT137F-800 Parametric

Parameter NameAttribute value
MakerNXP
Parts packaging codeSFM
package instructionPLASTIC, FULL PACK-3
Contacts3
Reach Compliance Codecompliant
Shell connectionISOLATED
ConfigurationSINGLE
Critical rise rate of minimum off-state voltage100 V/us
Maximum DC gate trigger current35 mA
Maximum DC gate trigger voltage1.5 V
Maximum holding current20 mA
JESD-30 codeR-PSFM-T3
Maximum leakage current0.5 mA
Number of components1
Number of terminals3
Maximum operating temperature125 °C
Minimum operating temperature-40 °C
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formFLANGE MOUNT
Certification statusNot Qualified
Maximum rms on-state current8 A
Maximum repetitive peak off-state leakage current500 µA
Off-state repetitive peak voltage800 V
surface mountNO
Terminal formTHROUGH-HOLE
Terminal locationSINGLE
Trigger device type4 QUADRANT LOGIC LEVEL TRIAC
Base Number Matches1
Philips Semiconductors
Product specification
Triacs
BT137F series
GENERAL DESCRIPTION
Passivated triacs in a full pack plastic
envelope, intended for use in
applications
requiring
high
bidirectional transient and blocking
voltage capability and high thermal
cycling
performance.
Typical
applications include motor control,
industrial and domestic lighting,
heating and static switching.
QUICK REFERENCE DATA
SYMBOL
PARAMETER
BT137F-
BT137F-
BT137F-
Repetitive peak off-state
voltages
RMS on-state current
Non-repetitive peak on-state
current
MAX. MAX. MAX. UNIT
500
500F
500G
500
8
55
600
600F
600G
600
8
55
800
800F
800G
800
8
55
V
DRM
I
T(RMS)
I
TSM
V
A
A
PINNING - SOT186
PIN
1
2
3
DESCRIPTION
main terminal 1
PIN CONFIGURATION
case
SYMBOL
T2
main terminal 2
gate
1 2 3
T1
case isolated
G
LIMITING VALUES
Limiting values in accordance with the Absolute Maximum System (IEC 134).
SYMBOL
V
DRM
I
T(RMS)
I
TSM
PARAMETER
Repetitive peak off-state
voltages
RMS on-state current
Non-repetitive peak
on-state current
I
2
t for fusing
Repetitive rate of rise of
on-state current after
triggering
full sine wave; T
hs
73 ˚C
full sine wave; T
j
= 125 ˚C prior
to surge; with reapplied V
DRM(max)
t = 20 ms
t = 16.7 ms
t = 10 ms
I
TM
= 12 A; I
G
= 0.2 A;
dI
G
/dt = 0.2 A/µs
T2+ G+
T2+ G-
T2- G-
T2- G+
CONDITIONS
MIN.
-
-
-
-
-
-
-
-
-
-
-
-
-
-40
-
-500
500
1
MAX.
-600
600
1
8
55
60
15
50
50
50
10
2
5
5
0.5
150
125
-800
800
UNIT
V
A
A
A
A
2
s
A/µs
A/µs
A/µs
A/µs
A
V
W
W
˚C
˚C
I
2
t
dI
T
/dt
I
GM
V
GM
P
GM
P
G(AV)
T
stg
T
j
Peak gate current
Peak gate voltage
Peak gate power
Average gate power
Storage temperature
Operating junction
temperature
over any 20 ms period
1
Although not recommended, off-state voltages up to 800V may be applied without damage, but the triac may
switch to the on-state. The rate of rise of current should not exceed 6 A/µs.
June 1999
1
Rev 1.200
