Chip Coils
for Choke Winding/Magnetic Shielded Type LQH55D/LQH66S Series
LQH55D Series
5.0±0.3
5.0±0.3
s
Features
The LQH55D series are choke inductors which have
achieved low direct current resistance, large current
capacity and large inductance by using high
performance thick wire winding technology.
They are optimum for use as choke inductors in DC/DC
converters and DC power supply circuits.
4.7±0.3
5.7±0.3
EIA Code:2220
1.3
min.
1.7
min.
1.3
min.
(in mm)
Part Number
LQH55DNR12M01
LQH55DNR27M01
LQH55DNR47M01
LQH55DN1R0M01
LQH55DN1R5M01
LQH55DN2R2M01
LQH55DN3R3M01
LQH55DN4R7M01
LQH55DN6R8M01
LQH55DN100M01
LQH55DN150M01
LQH55DN220M01
LQH55DN330M01
LQH55DN470M01
LQH55DN680M01
LQH55DN101M01
LQH55DN151M01
LQH55DN221M01
LQH55DN331M01
LQH55DN471M01
LQH55DN681M01
LQH55DN102M01
LQH55DN222M01
LQH55DN472M01
LQH55DN103M01
Inductance
(µH)
0.12
±20%
0.27
±20%
0.47
±20%
1.0
±20%
1.5
±20%
2.2
±20%
3.3
±20%
4.7
±20%
6.8
±20%
10
±20%
15
±20%
22
±20%
33
±20%
47
±20%
68
±20%
100
±20%
150
±20%
220
±20%
330
±20%
470
±20%
680
±20%
1000
±20%
2200
±20%
4700
±20%
10000
±20%
Test Frequency
1MHz
1MHz
1MHz
1MHz
1MHz
1MHz
1MHz
1MHz
1MHz
1MHz
1MHz
1MHz
1MHz
1MHz
1MHz
100kHz
100kHz
100kHz
100kHz
100kHz
100kHz
10kHz
10kHz
10kHz
10kHz
Rated
Current
(mA)
6000
5300
4800
4000
3700
3200
2900
2700
2000
1700
1400
1200
900
800
640
560
420
320
270
240
190
150
100
70
50
DC Resistance
(ohm)
0.007
±40%
0.010
±40%
0.013
±40%
0.019
±40%
0.022
±40%
0.029
±40%
0.036
±40%
0.041
±40%
0.074
±40%
0.093
±40%
0.15
±40%
0.19
±40%
0.32
±40%
0.40
±40%
0.67
±40%
0.86
±40%
1.9
±40%
2.4
±40%
4.4
±40%
5.4
±40%
8.1
±40%
10.3
±40%
21.5
±40%
43.6
±40%
100
±40%
Self Resonance
Frequency
(MHz)
450 min.
300 min.
200 min.
150 min.
110 min.
80 min.
40 min.
30 min.
25 min.
20 min.
17 min.
15 min.
12 min.
10 min.
7.6 min.
6.5 min.
5.0 min.
4.0 min.
3.1 min.
2.4 min.
1.9 min.
1.7 min.
1.2 min.
0.8 min.
0.5 min.
EIA
2220
2220
2220
2220
2220
2220
2220
2220
2220
2220
2220
2220
2220
2220
2220
2220
2220
2220
2220
2220
2220
2220
2220
2220
2220
12
Operating Temp. Range : -25°C to 80°C
48
Please read CAUTION and Notice in this catalog for safety. This catalog has only typical specifications. Therefore you are requested
to approve our product specification or to transact the approval sheet for product specification, before your ordering.
O05E7.pdf 02.3.28
s
Impedance-Frequency Characteristics
s
Inductance-Current Characteristics
1000000
100000
Impedance (Ω)
10000
1000
100
10
1
0.01
0.1
1
10
100
1000
10000µH
1000µH
100µH
10µH
Inductance (µH)
1µH
1000
1000µH
10000
10000µH
100
100µH
Frequency (MHz)
10
10µH
1
1µH
0.01
0.1
DC Current (A)
1
10
LQH66S Series
6.3±0.3
6.3±0.3
s
Features
The LQH66S series are choke inductors which have
achieved low direct current resistance, large current
capacity and large inductance by using high
performance thick wire winding technology.
Because the LQH66S series has a magnetic shielded
construction, it can be mounted in high density
without interference occuring between peripheral
components. They are optimum for use as choke
inductors in DC/DC converters and DC power supply
circuits.
Inductance
(µH)
0.27
±20%
0.68
±20%
1.0
±20%
1.5
±20%
2.2
±20%
3.3
±20%
4.7
±20%
6.8
±20%
10
±20%
15
±20%
22
±20%
33
±20%
47
±20%
68
±20%
100
±20%
150
±20%
220
±20%
330
±20%
470
±20%
680
±20%
1000
±20%
2200
±20%
4700
±20%
Rated
Current
(mA)
6000
5300
4700
3800
3300
2600
2200
1800
1600
1300
1100
860
760
600
520
420
350
280
240
200
160
100
70
4.7±0.3
6.3±0.3
EIA Code:2525
1.3
min.
1.7
min.
1.3
min.
(in mm)
Part Number
LQH66SNR27M01
LQH66SNR68M01
LQH66SN1R0M01
LQH66SN1R5M01
LQH66SN2R2M01
LQH66SN3R3M01
LQH66SN4R7M01
LQH66SN6R8M01
LQH66SN100M01
LQH66SN150M01
LQH66SN220M01
LQH66SN330M01
LQH66SN470M01
LQH66SN680M01
LQH66SN101M01
LQH66SN151M01
LQH66SN221M01
LQH66SN331M01
LQH66SN471M01
LQH66SN681M01
LQH66SN102M01
LQH66SN222M01
LQH66SN472M01
Test Frequency
1MHz
1MHz
1MHz
1MHz
1MHz
1MHz
1MHz
1MHz
1MHz
1MHz
1MHz
1MHz
1MHz
1MHz
100kHz
100kHz
100kHz
100kHz
100kHz
100kHz
10kHz
10kHz
10kHz
DC Resistance
(ohm)
0.007
±40%
0.010
±40%
0.013
±40%
0.016
±40%
0.019
±40%
0.022
±40%
0.025
±40%
0.029
±40%
0.036
±40%
0.069
±40%
0.087
±40%
0.14
±40%
0.17
±40%
0.29
±40%
0.36
±40%
0.63
±40%
0.79
±40%
1.8
±40%
2.2
±40%
3.9
±40%
4.9
±40%
9.4
±40%
19.5
±40%
Self Resonance
Frequency
(MHz)
300 min.
180 min.
150 min.
110 min.
80 min.
40 min.
30 min.
25 min.
20 min.
17 min.
15 min.
12 min.
10 min.
7.6 min.
6.5 min.
5.0 min.
4.0 min.
3.2 min.
2.5 min.
2.0 min.
1.7 min.
1.2 min.
0.8 min.
EIA
2525
2525
2525
2525
2525
2525
2525
2525
2525
2525
2525
2525
2525
2525
2525
2525
2525
2525
2525
2525
2525
2525
2525
12
Continued on the following page.
49
Please read CAUTION and Notice in this catalog for safety. This catalog has only typical specifications. Therefore you are requested
to approve our product specification or to transact the approval sheet for product specification, before your ordering.
Continued from the preceding page.
O05E7.pdf 02.3.28
Part Number
LQH66SN103M01
Inductance
(µH)
10000
±20%
Test Frequency
10kHz
Rated
Current
(mA)
50
DC Resistance
(ohm)
39.7
±40%
Self Resonance
Frequency
(MHz)
0.5 min.
EIA
2525
Operating Temp. Range : -25°C to 80°C
s
Impedance-Frequency Characteristics
s
Inductance-Current Characteristics
1000000
100000
Impedance (Ω)
10000
1000
100
10
1
0.01
0.1
1
10
100
1000
10000µH
1000µH
100µH
10µH
Inductance (µH)
1µH
100µH
1000
1000µH
10000
10000µH
100
Frequency (MHz)
10
10µH
1
1µH
0.01
0.1
DC Current (A)
1
10
12
50
