PDU-13256F-4 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > logic> logic> PDU-13256F-4

PDU-13256F-4: DescriptionActive Delay Line, Programmable, 1-Func, 255-Tap, Complementary Output, TTL, LOW PROFILE, DIP-48/18; Categorylogic logic; File Size125KB，1 Pages; ManufacturerData Delay Devices

Download Datasheet Parametric Compare View All

PDU-13256F-4 Overview

Active Delay Line, Programmable, 1-Func, 255-Tap, Complementary Output, TTL, LOW PROFILE, DIP-48/18

PDU-13256F-4 Parametric

Parameter Name	Attribute value
Maker	Data Delay Devices
Parts packaging code	DIP
package instruction	DIP,
Contacts	48/18
Reach Compliance Code	compliant
Other features	WITH EBAR
series	F
JESD-30 code	R-XDIP-T18
length	62.23 mm
Logic integrated circuit type	ACTIVE DELAY LINE
Number of functions	1
Number of taps/steps	255
Number of terminals	18
Maximum operating temperature	70 °C
Minimum operating temperature
Output polarity	COMPLEMENTARY
Package body material	UNSPECIFIED
encapsulated code	DIP
Package shape	RECTANGULAR
Package form	IN-LINE
programmable delay line	YES
Certification status	Not Qualified
Maximum seat height	8.128 mm
Maximum supply voltage (Vsup)	5.25 V
Minimum supply voltage (Vsup)	4.75 V
Nominal supply voltage (Vsup)	5 V
surface mount	NO
technology	TTL
Temperature level	COMMERCIAL
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
Total delay nominal (td)	1035 ns
width	7.62 mm
Base Number Matches	1

Preview

Download Datasheet

View All

PDU-13256F-4 Related Products

	PDU-13256F-4	PDU-13256F-10	PDU-13256F-5	PDU-13256F-.5	PDU-13256F-8	PDU-13256F-7	PDU-13256F-2	PDU-13256F-9
Description	Active Delay Line, Programmable, 1-Func, 255-Tap, Complementary Output, TTL, LOW PROFILE, DIP-48/18	Active Delay Line, Programmable, 1-Func, 255-Tap, Complementary Output, TTL, LOW PROFILE, DIP-48/18	Active Delay Line, Programmable, 1-Func, 255-Tap, Complementary Output, TTL, LOW PROFILE, DIP-48/18	Active Delay Line, Programmable, 1-Func, 255-Tap, Complementary Output, TTL, LOW PROFILE, DIP-48/18	Active Delay Line, Programmable, 1-Func, 255-Tap, Complementary Output, TTL, LOW PROFILE, DIP-48/18	Active Delay Line, Programmable, 1-Func, 255-Tap, Complementary Output, TTL, LOW PROFILE, DIP-48/18	Active Delay Line, Programmable, 1-Func, 255-Tap, Complementary Output, TTL, LOW PROFILE, DIP-48/18	Active Delay Line, Programmable, 1-Func, 255-Tap, Complementary Output, TTL, LOW PROFILE, DIP-48/18
Parts packaging code	DIP	DIP	DIP	DIP	DIP	DIP	DIP	DIP
package instruction	DIP,	DIP,	LOW PROFILE, DIP-48/18	DIP,	LOW PROFILE, DIP-48/18	DIP,	LOW PROFILE, DIP-48/18	DIP,
Contacts	48/18	48/18	48/18	48/18	48/18	48/18	48/18	48/18
Reach Compliance Code	compliant	compliant	compliant	compliant	compliant	compliant	compliant	compliant
Other features	WITH EBAR	WITH EBAR	WITH EBAR	WITH EBAR	WITH EBAR	WITH EBAR	WITH EBAR	WITH EBAR
series	F	F	F	F	F	F	F	F
JESD-30 code	R-XDIP-T18	R-XDIP-T18	R-XDIP-T18	R-XDIP-T18	R-XDIP-T18	R-XDIP-T18	R-XDIP-T18	R-XDIP-T18
length	62.23 mm	62.23 mm	62.23 mm	62.23 mm	62.23 mm	62.23 mm	62.23 mm	62.23 mm
Logic integrated circuit type	ACTIVE DELAY LINE	ACTIVE DELAY LINE	ACTIVE DELAY LINE	ACTIVE DELAY LINE	ACTIVE DELAY LINE	ACTIVE DELAY LINE	ACTIVE DELAY LINE	ACTIVE DELAY LINE
Number of functions	1	1	1	1	1	1	1	1
Number of taps/steps	255	255	255	255	255	255	255	255
Number of terminals	18	18	18	18	18	18	18	18
Maximum operating temperature	70 °C	70 °C	70 °C	70 °C	70 °C	70 °C	70 °C	70 °C
Output polarity	COMPLEMENTARY	COMPLEMENTARY	COMPLEMENTARY	COMPLEMENTARY	COMPLEMENTARY	COMPLEMENTARY	COMPLEMENTARY	COMPLEMENTARY
Package body material	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED	UNSPECIFIED
encapsulated code	DIP	DIP	DIP	DIP	DIP	DIP	DIP	DIP
Package shape	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	IN-LINE	IN-LINE	IN-LINE	IN-LINE	IN-LINE	IN-LINE	IN-LINE	IN-LINE
programmable delay line	YES	YES	YES	YES	YES	YES	YES	YES
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Maximum seat height	8.128 mm	8.128 mm	8.128 mm	8.128 mm	8.128 mm	8.128 mm	8.128 mm	8.128 mm
Maximum supply voltage (Vsup)	5.25 V	5.25 V	5.25 V	5.25 V	5.25 V	5.25 V	5.25 V	5.25 V
Minimum supply voltage (Vsup)	4.75 V	4.75 V	4.75 V	4.75 V	4.75 V	4.75 V	4.75 V	4.75 V
Nominal supply voltage (Vsup)	5 V	5 V	5 V	5 V	5 V	5 V	5 V	5 V
surface mount	NO	NO	NO	NO	NO	NO	NO	NO
technology	TTL	TTL	TTL	TTL	TTL	TTL	TTL	TTL
Temperature level	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL
Terminal form	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE
Terminal pitch	2.54 mm	2.54 mm	2.54 mm	2.54 mm	2.54 mm	2.54 mm	2.54 mm	2.54 mm
Terminal location	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL	DUAL
Total delay nominal (td)	1035 ns	2565 ns	1290 ns	142.5 ns	2055 ns	1800 ns	525 ns	2310 ns
width	7.62 mm	7.62 mm	7.62 mm	7.62 mm	7.62 mm	7.62 mm	7.62 mm	7.62 mm
Maker	Data Delay Devices	-	Data Delay Devices	Data Delay Devices	Data Delay Devices	Data Delay Devices	Data Delay Devices	Data Delay Devices
Base Number Matches	1	1	1	1	1	-	-	-
