D796ME01 datasheet, PDF - EEWORLD Datasheet

D796ME01: DescriptionVoltage Controlled Oscillator, 782MHz Min, 810MHz Max; CategoryPassive components oscillator; File Size109KB，1 Pages; ManufacturerZ-Communications, Inc.; Websitehttps://www.zcomm.com/

Download Datasheet Parametric View All

D796ME01 Overview

Voltage Controlled Oscillator, 782MHz Min, 810MHz Max

Parameter Name	Attribute value
Maker	Z-Communications, Inc.
Reach Compliance Code	compliant
Maximum control voltage	4 V
Minimum control voltage	1 V
Modulation sensitivity	17 MHz/V
offset frequency	1 kHz
Maximum operating frequency	810 MHz
Minimum operating frequency	782 MHz
Maximum operating temperature	70 °C
Minimum operating temperature	-30 °C
Oscillator type	VOLTAGE CONTROLLED OSCILLATOR
Output Power	3 dBm
phase noise	-80 dBc/Hz
power change	2 dB
Nominal supply voltage	5 V
Base Number Matches	1
