FILTERS
BANDPASS
24 P
IN
- T
HROUGH
H
OLE
M
OUNT
H
IGH
S
UPPRESSION
Fc
(MHz)
LOSS
(dB)
1 dB RIPPLE
BW (MHz)
20 dB BW
(MHz)
40 dB BW (MHz)
(50dB on low end)
PACKAGE
PIN-OUT
(See Below)
MODEL
10.7
21.4
30.0
45.0
50.0
60.0
70.0
140
200
NOTE:
3.5
3.5
3.5
3.5
4.0
4.0
4.6
5.0
6.0
0.3
1.0
1.5
2.2
2.5
3.0
3.5
8.0
12.0
9.63-11.8
19.26-23.6
27-33
40-50
45-56
54-67
63-77
125-160
180-230
8.5-12.85
17-25.70
24-36
35-56
40-62
48-74
56-86
110-175
155-250
124
124
124
124
124
124
124
124
124
1
1
1
1
1
1
1
1
1
FBP-11
FBP-21
FBP-30
FBP-45
FBP-50
FBP-60
FBP-70
FBP-140
FBP-200
All units meet or exceed applicable MIL-F-18327.
For other frequencies, please contact Synergy directly.
L
EADLESS
S
URFACE-
M
OUNT
M
ODELS
H
IGH
S
UPPRESSION
Fc
(MHz)
LOSS
(dB)
1 dB RIPPLE
BW (MHz)
20 dB BW
(MHz)
40 dB BW (MHz)
(50dB on low end)
PACKAGE
PIN-OUT
(See Below)
MODEL
10.7
21.4
30.0
45.0
50.0
60.0
70.0
140
200
NOTE:
3.5
3.5
3.5
3.5
4.0
4.0
4.6
5.0
6.0
0.3
1.0
1.5
2.2
2.5
3.0
3.5
8.0
12.0
9.63-11.8
19.26-23.6
27-33
40-50
45-56
54-67
63-77
125-160
180-230
8.5-12.85
17-25.70
24-36
35-56
40-62
48-74
56-86
110-175
155-250
124S
124S
124S
124S
124S
124S
124S
124S
124S
1
1
1
1
1
1
1
1
1
PIN-OUT TABLE
FBS-11
FBS-21
FBS-30
FBS-45
FBS-50
FBS-60
FBS-70
FBS-140
FBS-200
All units meet or exceed applicable MIL-F-18327.
For other frequencies and impedances please contact us.
Impedance is 50 Ohms for all models.
INPUT
1
OUTPUT
16
CASE GROUND
All Other
For pin location and package outline drawings, see back pages.
