SHB-1T2012-401JT datasheet, PDF

Datasheet> All Categories > Analog mixed-signal IC> filter> SHB-1T2012-401JT

SHB-1T2012-401JT: DescriptionFerrite Chip, 1 Function(s), 0.2A, ROHS COMPLIANT PACKAGE-2; CategoryAnalog mixed-signal IC filter; File Size543KB，5 Pages; ManufacturerSUMIDA; Websitehttp://www.sumida.com/; Environmental Compliance

Download Datasheet Parametric View All

SHB-1T2012-401JT Overview

Ferrite Chip, 1 Function(s), 0.2A, ROHS COMPLIANT PACKAGE-2

SHB-1T2012-401JT Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	SUMIDA
package instruction	ROHS COMPLIANT PACKAGE-2
Reach Compliance Code	unknown
ECCN code	EAR99
Maximum DC resistance	0.15 Ω
filter type	FERRITE CHIP
high	0.8 mm
length	2 mm
Manufacturer's serial number	SHB-2012
Installation type	SURFACE MOUNT
Number of functions	1
Output impedance	400 OHM Ω
method of packing	TAPE AND REEL
physical size	L2.0XB1.25XH0.8 (mm)/L0.079XB0.049XH0.031 (inch)
Rated current	0.2 A
width	1.25 mm
Base Number Matches	1

Preview

Download Datasheet

View All

Multilayer Chip Ferrite Beads

——SHB-2012

Features

1. Effective in suppressing noise at high frequencies.

2. Suited for preventing the abnormal oscillation from high frequency amplifying circuits.

3. Excellent solder heat resistance for soldering.

4. High reliability in the circuits of high current.

5. Lead Free (RoHS Compliance)

PAGE

1/5

Applications

1. Noise suppression in digital equipments.

2. Computers and peripheral devices, VCR and camera.

3. Noise suppression in automotive electronic equipment, car stereo, car engine controller.

4. Noise suppression for OA electronic instruments.

Ordering Information

SHB -

(1)

(1) Series

SHB : For Signal line

(2) Material & Design

S, B : For high speed

M : For high impedance type

T : For Low speed

(3) Dimension

First two digits : length (㎜)

Last two digits : width (㎜)

(2)

2012

(3)

102

(4)

(5)

(6)

(4) Impedance (at 100MHz)

First two digits are impedance values.

Last digit is the number of zeros

(5) Termination

J : Nickel barrier

(6) Packaging

B : Bulk package

T : Tape & Reel (Φ178㎜ [ 7 inches ])

L : Tape & Reel (Φ254㎜ [ 10 inches ])

Shape and Dimensions

Unit : mm [inches]

Type

2.0±0.20

1.25±0.20

0.8±0.15

0.50±0.30

SHB-1□2012-

〔.079±.008〕〔.049±.008〕

(.049±.008)

〔.020±.012〕

C₁

*All specifications are subject to change without notice.
