Ceramic
Low Pass Filters
DC to 3300 MHz
Features
• miniature size, 0.15"X0.15"X.028"
• low profile, .028" height
• high power handling, 10W
LFTC-3300 LFTC-3300L
Applications
• harmonic rejection
• internal rejection
• receivers & transmitters
Without Leads
CASE STYLE: FR933
PRICE: $3.75 ea.
QTY.(10-49)
With Leads
CASE STYLE: FR932
PRICE: $4.00 ea.
QTY.(10-49)
Electrical Specifications (T
AMB
=25°C)
MODEL
NO.
PASSBAND
(MHz)
(loss < 1dB)
LFTC-3300
LFTC-3300L
DC-3300
DC-3300
fco, MHz
Nom.
(loss 3 dB)
Typ.
4060
4060
(>20 dB)
5600
5600
STOP BAND (MHz),
LOSS (dB)
(loss >40 dB)
—
—
fr20dB
Typ.
10000
10000
VSWR (:1)
Passband
Typ.
1.2
1.2
POWER
INPUT*
(W)
10
10
MARKING THERMAL
RESIS-
TANCE
°C/W
LF9
LF9
30
30
CASE
STYLE
FR933
FR932
*Derate linearly to 4W at 100°C ambient
Pin Connections
RF IN
RF OUT
GROUND
DEMO BOARD
** pins 2&5 can be interchanged
Maximum Ratings
2**
5**
1,3,4,6
TB-233
Operating Temperature
Storage Temperature
-55°C to 100°C
-55°C to 125°C
Outline Drawing
Suggested PCB Layout (PL-112)
Outline Dimensions (
inch
)
mm
CASE NO.
A
FR932
.173
4.39
FR933
.150
3.81
B
.150
3.81
.150
3.81
C
D
E
F
G
H
J
K
L
.035 .050 .025 .043 .015 .004 .060 .030 .184
0.89 1.27 0.64 1.09 0.38 0.10 1.52 0.76 4.67
.028
—
— .035 .020
— .060 .030 .184
0.71
—
— 0.89 0.51
— 1.52 0.76 4.67
M
N
P
wt.
.050
—
— grams
1.27
—
—
0.15
.050 .075 .044
1.27 1.91 1.12
0.15
Typical Performance Data at 25°C
Freq.
(MHz)
100.00
1000.00
1600.00
2000.00
2600.00
3200.00
3500.00
4060.00
4600.00
5000.00
5600.00
7000.00
8000.00
9000.00
10000.00
Ins. Loss
(dB)
0.08
0.29
0.34
0.44
0.60
0.76
0.95
3.16
10.72
16.54
24.07
36.57
27.88
22.32
19.50
VSWR
(:1)
1.05
1.24
1.10
1.15
1.21
1.15
1.14
3.16
16.69
44.51
118.44
38.64
23.45
22.03
21.00
®
INSERTION LOSS (dB)
LFTC-3300
INSERTION LOSS
50
45
40
35
25
20
15
10
5
0
0
1000 2000 3000 4000 5000 6000 7000 8000 9000 10000
FREQUENCY (MHz)
1
0
1000
2000
3000
LFTC-3300
VSWR
1000
VSWR
30
100
10
4000
5000
6000
7000
8000
9000 10000
FREQUENCY (MHz)
Mini-Circuits
INTERNET
http://www.minicircuits.com
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
REV. OR
M84321
LFTC-3300
LFTC-3300L
WZ/RS/CP
021126
EDB020617
ED10545B/9
Distribution Centers
NORTH AMERICA 800-654-7949 • 417-335-5935 • Fax 417-335-5945 • EUROPE 44-1252-832600 • Fax 44-1252-837010
ISO 9001 CERTIFIED
