Solid State Devices, Inc.
14701 Firestone Blvd * La Mirada, Ca 90638
Phone: (562) 404-4474 * Fax: (562) 404-1773
ssdi@ssdi-power.com * www.ssdi-power.com
SSR1008M, SSR1008Z
SSR1009M, SSR1009Z
SSR1010M, SSR1010Z
10 AMPS
80 - 100 VOLTS
SCHOTTKY RECTIFIER
Designer’s Data Sheet
Part Number/Ordering Information
1/
SSR1008
__ __ __
SSR1009
__ __ __
SSR1010
__ __ __
│
│
│
│
│
│
│
└
│
└
Screening
2/
__
= Not Screened
│
TX = TX Level
│
TXV = TXV
│
S = S Level
│
└
Lead Options
__ = Straight Leads,
D = Bent Down, U = Bent Up
FEATURES:
•
•
•
•
•
•
•
Extremely Low Forward Voltage Drop
Low Reverse Leakage Current
Hermetically Sealed Package
Guard Ring for Overvoltage Protection
Eutectic Die Attach
175
°
C Operating Junction Temperature
TX, TXV, or Space Level Screening Available
Package
M = TO-254, Z = TO-254Z
TO-254
TO-254Z
MAXIMUM RATINGS
RATING
Peak Repetitive Reverse Voltage and DC
Blocking Voltage
SSR1008M, SSR1008Z
SSR1009M, SSR1009Z
SSR1010M, SSR1010Z
Average Rectified Output Current
(Resistive Load, 60Hz, Sine Wave, TA=25
°
C)
Peak Surge Current
(8.3 ms Pulse, Half Sine Wave, superimposed on
I
O
, allow junction to reach equilibrium between
pulses, TA=25
°
C)
Operating and Storage Temperature
Maximum Thermal Resistance
Junction to Case
NOTES:
1/
2/
3/
3/
3/
3/
SYMBOL
V
RRM
V
RWM
V
R
I
O
I
FSM
VALUE
80
90
100
10
200
UNIT
Volts
Amps
Amps
T
OP
& T
STG
R
θJC
-65 to +175
1.7
°
°
C
C/W
For ordering information, price, and availability- Contact Factory.
Screened to MIL-PRF-19500.
For optimal performance, connect leads 2 & 3 together.
NOTE:
All specifications are subject to change without notification.
SCD's for these devices should be reviewed by SSDI prior to release.
DATA SHEET #: RS0205K
DOC
Solid State Devices, Inc.
14701 Firestone Blvd * La Mirada, Ca 90638
Phone: (562) 404-4474 * Fax: (562) 404-1773
ssdi@ssdi-power.com * www.ssdi-power.com
SSR1008M, SSR1008Z
SSR1009M, SSR1009Z
SSR1010M, SSR1010Z
ELECTRICAL CHARACTERISTICS (Per Leg)
CHARACTERISTICS
Instantaneous Forward Voltage Drop
(I
F
= 1 Adc, T
A
= 25
°
C, Pulse)
(I
F
= 5 Adc, T
A
= 25
°
C, Pulse)
(I
F
= 10 Adc, T
A
= 25
°
C, Pulse)
Instantaneous Forward Voltage Drop
T
A
= 100
°
C
(I
F
= 10 Adc, Pulse)
T
A
= -55
°
C
Reverse Leakage Current
(Rated V
R
, T
A
= 25
°
C, Pulse)
Reverse Leakage Current
(Rated V
R
, T
A
= 100
°
C, Pulse)
Junction Capacitance
(V
R
= 10 Vdc, T
A
= 25
°
C, f = 1 MHz)
Case Outlines- TO-254 and TO-254Z
SYMBOL
V
F1
V
F2
V
F3
V
F4
V
F5
I
R1
I
R2
C
J
MAXIMUM
0.57
0.72
0.8
0.70
0.90
100
5
400
UNIT
Vdc
Vdc
µA
mA
pF
PIN OUT: Rectifier Configuration
4/
PIN 1- CATHODE
PIN 2- ANODE
PIN 3- ANODE
Optional Bent Down Leads
(MD & ZD Suffix)
TO-254 (M Suffix)
TO-254Z (Z Suffix)
Optional with Bent Up Leads
(MU & ZU Suffix)
For information on curves, contact the Factory Representative for Engineering Assistance.
NOTES:
4/
Pins 2 and 3 must be externally connected for best performance.
NOTE:
All specifications are subject to change without notification.
SCD's for these devices should be reviewed by SSDI prior to release.
DATA SHEET #: RS0205K
DOC
