RMV/TSSAA-330/25-8X11X3.5: DescriptionAluminum Electrolytic Capacitor, Polarized, Aluminum, 25V, 20% +Tol, 20% -Tol, 330uF; CategoryPassive components capacitor; File Size37KB，2 Pages; ManufacturerDaewoo

Download Datasheet Parametric View All

RMV/TSSAA-330/25-8X11X3.5 Overview

Aluminum Electrolytic Capacitor, Polarized, Aluminum, 25V, 20% +Tol, 20% -Tol, 330uF

RMV/TSSAA-330/25-8X11X3.5 Parametric

Parameter Name	Attribute value
Maker	Daewoo
package instruction	,
Reach Compliance Code	unknown
ECCN code	EAR99
capacitance	330 µF
Capacitor type	ALUMINUM ELECTROLYTIC CAPACITOR
diameter	8 mm
dielectric materials	ALUMINUM
length	11.5 mm
Manufacturer's serial number	RMV(25V)
negative tolerance	20%
Number of terminals	2
Maximum operating temperature	105 °C
Minimum operating temperature	-40 °C
Package form	Radial
method of packing	Ammo Pack
polarity	POLARIZED
positive tolerance	20%
Rated (DC) voltage (URdc)	25 V
series	RMV(25V)
Terminal pitch	3.5 mm
Base Number Matches	1

Preview

Download Datasheet

View All

RMV

▣ Features

§

SERIES

ALUMINUM ELECTROLYTIC CAPACITORS

105 ℃, Sub-miniature, Radial Leads

105℃ , Sub-miniature, Radial

Wide Operating Temperature Range

High CV(Smaller than RMU)

Load Life of 1000 hours at 105℃

▣ Specifications

Item

Operating temperature range

Rated working voltage range

Nominal capacitance range

D.C Leakage current(at

20℃ )

-40℃ ½ +105℃

6.3V ½ 100V

Performance Characteristics

-40℃ ½ +105℃

160V ½ 250V

0.47㎌½22,000㎌ , ±20％(at 20℃, 120㎐)

The following specifications shall be satisfied when the rated voltage is applied for the

required time

I ≤ 0.01CV + 3㎂(2min)

I ≤ 0.01CV + 10㎂(3min)

I ≤ 0.02CV + 30㎂(5min)

Where I = Leakage current(㎂), C = Nominal capacitance(㎌), V = Rated voltage(V)

-25℃ ½ +105℃

350V ½ 450V

Tan δ

(max. at 20℃, 120㎐ )

Characteristics at low

temperature(max.)

(Impedance Ratio at 120㎐ )

Load life

Shelf life

W.V(V)

6.3

10

16

25

35

50

63

100 160½250

350½450

Tan δ

0.28 0.24 0.20 0.16 0.14 0.12 0.10 0.08

0.15

0.20

When capacitance is over 1000㎌, tan δshall be added 0.02 to the listed value with Increase of

every each 1000㎌.

W.V(V)

6.3

10

16

25

35

50½100 160½250

350½450

Z-25℃/+20℃

5

4

3

2

3

6

Z-40℃/+20℃

10

8

6

4

3

6

-

After applying rated working voltage for 1000hrs at +105℃ and then being stabilized at +20℃,

capacitors shall meet following limits.

Capacitance change

Within ±20％ of initial measured value

Tan δ

≤ 200％ of initial specified value

Leakage current

≤ The initial specified value

After storage for 1000hrs at +105℃ with no voltage applied and then being stabilized at +20℃,

capacitors shall meet following limits.

Capacitance change

Within ±20％ of initial measured value

Tan δ

≤ 150％ of initial specified value

Leakage current

≤ The initial specified value

▣ Dimensions

P±0.5

Insulating Sleeve

▣ Ripple current coefficient

◉ Frequency

C a p (㎌ )

Freq(㎐ )

50

0.8

120

1.0`

1.0

400

1.30

1.23

1.16

1.11

1K

1.45

1.36

1.25

1.17

10K 50½ 100 K

1.65

1.48

1.35

1.25

1.70

1.53

1.38

1.28

C A P≤10

10< C A P≤1 0 0

100<C A P ≤1000

1000<C A P

D´

Dia

Φ

d

Safety Vent

(DΦ

≥6.3)

L

L´

15.0 min 4.0 min

D´

Dia

◉ Standard lead style

ΦD

P

Φd

5.0

2.0

6.3

2.5

8.0

3.5

10.0

0.6

12.5

5.0

16.0

18.0

7.5

0.8

◉ Temperature

Temperature

Factor

≤70℃

1.95

85℃

1.65

105 ℃

1.0

0.5

D'=[D+0.5]Max

L'=[L+1.0]Max. at D≤8.0

L'=[L+1.5]Max. at D≥10.0
