JAN1N6486: DescriptionZener Diode, 3.6V V(Z), 5%, 1.5W, Silicon, Unidirectional, HERMETIC SEALED, GLASS, D-5A, 2 PIN; CategoryDiscrete semiconductor diode; File Size107KB，2 Pages; ManufacturerCompensated Devices Inc.

Download Datasheet Parametric View All

JAN1N6486 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	JAN1N6486	-	-	View	Buy Now

JAN1N6486 Overview

Zener Diode, 3.6V V(Z), 5%, 1.5W, Silicon, Unidirectional, HERMETIC SEALED, GLASS, D-5A, 2 PIN

JAN1N6486 Parametric

Parameter Name	Attribute value
Maker	Compensated Devices Inc.
package instruction	O-LALF-W2
Reach Compliance Code	unknown
Other features	METALLURGICALLY BONDED
Shell connection	ISOLATED
Configuration	SINGLE
Diode component materials	SILICON
Diode type	ZENER DIODE
JESD-30 code	O-LALF-W2
Number of components	1
Number of terminals	2
Package body material	GLASS
Package shape	ROUND
Package form	LONG FORM
polarity	UNIDIRECTIONAL
Maximum power dissipation	1.5 W
Certification status	Not Qualified
Guideline	MIL-19500/406
Nominal reference voltage	3.6 V
surface mount	NO
technology	ZENER
Terminal form	WIRE
Terminal location	AXIAL
Maximum voltage tolerance	5%
Working test current	69 mA
Base Number Matches	1

Preview

Download Datasheet

View All

• AVAILABLE IN

JAN, JANTX,

PER MIL-PRF-19500/406

• 1.5 WATT ZENER DIODES

• NON CAVITY CONSTRUCTION

• METALLURGICALLY BONDED

JANTXV,

AND

JANS

1N6485

THRU

1N6491

AND

1N4460

AND

1N4461

MAXIMUM RATINGS

Operating Temperature: -65°C to +175°C

Storage Temperature: -65°C to +200°C

Power Dissapation: 1.5W @ TA=+25°C

Power Derating: 10mW/°C above TA=+25°C

Forward Voltage: 1.0 V dc @ IF=200mA dc

1.5 V dc @ IF=1A dc

0.060/0.085

1.52/2.16

POLARITY

BAND

(CATHODE)

0.125/0.160

3.18/4.06

0.800

20.32

0.028/0.032

0.71/0.81

ELECTRICAL CHARACTERISTICS

@ 25°C, unless otherwise specified

ZENER

TEST

DYNAMIC

KNEE

TEST

REVERSE TEST

MAXIMUM VZ

(REG)

MAXIMUM

VOLTAGE CURRENT IMPEDENCE IMPEDENCE CURRENT CURRENT VOLTAGE CURRENT

v

VZ

SURGE

±5%

IZT

(MAX.)

IZK

(MAX.)

VR

IZM

VZ

ZZT@IZT

ZZK@IZT

IR@VR

VOLTS

1N6485

1N6486

1N6487

1N6488

1N6489

1N6490

1N6491

1N4460

1N4461

3.3

3.6

3.9

4.3

4.7

5.1

5.6

6.2

6.8

mA

76.0

69.0

64.0

58.0

53.0

49.0

45.0

40.0

37.0

OHMS

10

9

8

7

5

4

2.5

OHMS

400

500

600

200

mA

1.0

µ

A

50

35

5.0

4.0

1.0

0.5

10.0

5.0

VOLTS

1.0

2.0

3.72

4.08

MA

433

397

366

332

304

280

255

230

210

VOLTS

.90

.80

.75

.70

.60

.50

.40

.35

.30

AMPS

4.2

3.9

3.6

3.3

3.0

2.7

2.5

2.3

2.1

TYPE

FIGURE 1

DESIGN DATA

CASE:

Hermetically sealed, Glass “A”

Body per MIL-PRF- 19500/406

D-5A

LEAD MATERIAL:

Copper clad steel

LEAD FINISH:

Tin / Lead

THERMAL RESISTANCE: (R

OJL): 42

˚C/W maximum at L = .375

THERMAL IMPEDANCE: (Z

OJX): 4.5

˚C/W maximum

POLARITY:

Diode to be operated with

the banded (cathode) end positive.

MOUNTING POSITION:

Any

22 COREY STREET, MELROSE, MASSACHUSETTS 02176

PHONE (781) 665-1071

FAX (781) 665-7379

WEBSITE: http://www.cdi-diodes.com

E-mail: mail@cdi-diodes.com
