D-SUBMINIATURE CONNECTORS
KYCON
RoHS
RoHS
Drawing
Sample
K85X Series
Documentation &
Ordering Information
Stock
Email
CofC
RFQ
Kycon Part #
K85X-EA-9P
Part Number Builder
K85X
E
A
Pin
Length
9
P
K85X Series
Vertical PCB Mount and Solder cup
Dimensions in mm [In]
B
A, A1
12.55 [.494]
2.84 [.112]
Series Shell
Type
Contact Contact Mounting Plating
Option
Type
Option Option
Series
K85X - D-Subminiature Vertical Connector
K85X
Contact Shell Size Option
E - 9 Contacts
E
A - 15 Contacts
A
B - 25 Contacts
B
C - 37 Contacts
C
Contact Construction, Pin Length
A - Precision Formed, Solder Cup ( Not Available with BR/J )
D - Precision Formed, Vertical Pin (PCB Mount)
D
Contact Option
9 ,15, 25, 37
Contact Type
P - Pin Contact (Plug)
S - Socket Contact (Receptacle)
Mounting Option
Blank
- Without Riveted Option
Blank
BR - with (4-40) Riveted Threaded Tin Plated Board Lock
BR
BRJ - with (4-40) Riveted Threaded Tin Plated Board Lock and
(4-40) Hex Jack Screws Installed
K
K - with (4-40) Bushings
KJ - with (4-40) Bushings and (4-40) Hex Jack Screws
R - with Round Riveted Jack Screws
R
-BR Option
#4-40 UNC
-K Option
#4-40 UNC
Bushing
-R Option
#4-40 UNC
Internal
Thread
C
8.36 Plug Interior,
7.90 Socket Exterior
2.77 [.109]
4.50 [.177]
0.99 [.039]
3.0 [.118]
5.9 Plug,
6.0 Socket
1.385 [.054]
D
Solder Cups
1.385 [.054]
2.77 [.109]
Ø1.09 [.043]
2.84 [.112]
10.72 [.422]
1.42 [.056]
2.84 [.112]
Ø3.05 [.120]
B
5.00 [.197]
6.00 [.236]
(Top View)
Recommended PCB Layout
Board Lock
Number
of Contacts
(Shell Size)
9 (E)
15 (A)
25 (B)
37 (C)
Dimensions (Inch/
mm)
A
.643
16.33
.971
24.66
1.511
38.38
2.159
54.84
A1
.666
16.92
.994
25.25
1.534
38.96
2.182
55.42
B
.984
24.99
1.312
33.32
1.852
47.04
2.500
63.50
C
1.213
30.81
1.541
39.14
2.088
53.04
2.729
69.32
D
.755
19.18
1.083
27.51
1.614
41.00
2.272
57.71
* Hex Jack Screws JSX-1055 recommended for BR Option
Plating Option
Blank
- Gold Flash
15
- 15u” Gold
15
30
- 30u” Gold
Contact Kycon for HT and other Options
Click here for all K85X series part number list
A = Exterior of Female Shell (S) A1 = Interior of Male Shell (P)
Click here for Performance Specification
2007
KYCON, Inc. • Tel: +1 408-494-0330 • US: 1-888-KYCON-22 • Fax: +1 408-494-0325 • www.kycon.com
