SCHEMATICS
1
LINE
MATERIAL AND FINISH:
Insulator: Polycarbonate,
UL-94V-0 rated, color black
Contacts: Copper, Tin plated
D
ELECTRICAL SPECIFICATIONS:
Current rating: 10 A
Voltage rating: 250 VAC
Insulation resistance: 100 Mohm
min. at 500 VDC
Dielectric withstanding voltage:
2000 VAC for one minute
V
D E
E
L
2 FUSES
230
L
115
LOAD
30.0
0.80 TYP.
N
N
D
30.5+0.2
2.8±0.1 TYP.
48.6
LOAD
3.0x1.7 TYP.
LINE
N
E
L
1 FUSE
N
230
L
115
C
ORDERING CODE:
42R42-3 __ 2 __ - __ __ __
1
2
3
C
1) COLOR
1 = BLACK
2 = GRAY
2) ELECTRICAL CIRCUIT
CONFIGURATION
A+0.2
37.5+0.2
4X R1.5 MAX.
19
3X 2.00±0.05
RECOMMENDED
PANEL CUTOUT
3X 4.0±0.1
40
115
230
9.3±0.5 TYP.
3.00
X.X
1 = 10A 250V 70°C
2+GROUND, 1 FUSE
2 = 10A 250V 70°C
2+GROUND, 2 FUSE
B
3 = 10A 250V 120°C
2+GROUND, 1 FUSE
4 = 10A 250V 120°C
2+GROUND, 2 FUSE
CHNG CHCK APPR
4.00 16.0+0.5
37.0
B
5 = 10A 250V 70°C
2 POLE, 1 FUSE
6 = 10A 250V 70°C
2 POLE, 2 FUSE
3) PANEL THICKNESS
A
P/N
1.5
42R42-3X2X-150 1.5
2.0
42R42-3X2X-200 2.0
2.5
42R42-3X2X-250 2.5
ADDITIONAL PANEL THICKNESS
AVAILABLE ON REQUEST
5
4
14.0±0.2
24.0+0.5
33
TOLERANCE
UNLESS OTHERWISE SPECIFIED
X ± 1
X.X ± 0.4
X.XX ± 0.20
REPLACE WITH
CORRESPONDING
PANEL THICKNESS
REVISIONS
CHANGE
Phone: 973 560-0019
Whippany, New Jersey
Fax: 973 560-0076
A
PART: IEC 60320 APPL. INLET, VOLTAGE SELECTOR
FUSE HOLDER; SOLDER TERMINALS; SNAP-IN
A
DRAWN
BY
CHECK
BY
APPR
BY
DATE
GQ
TD
PB
DATE:
DATE:
DATE:
09/28/01
10/04/01
10/04/01
PART #:
42R42-3X2X-XXX
A
NTS
ALL DIMENSIONS FOR REFERENCE ONLY
DIMENSIONS ARE IN MILLIMETERS
SHEET
1 of 1
REV:
REV
SIZE:
SCALE:
6
3
2
1
