FLH
CONNECTOR
0.5mm pitch/Connectors for FPC
Emboss Tape
Specifications –––––––––––––––––––
• Current rating: 0.5A AC, DC
• Voltage rating: 50V AC, DC
• Temperature range: -25˚C to +85˚C
(including temperature rise in applying
electrical current)
• Contact resistance: Initial value/40m
Ω
max.
After environmental testing/60m
Ω
max.
• Insulation resistance:
800M
Ω
min.
• Withstanding voltage: 200V AC/minute
• Applicable FPC: Conductor pitch/0.5mm
Conductor width/0.35mm
Mating part thickness/0.3±0.03mm
Compact connector with just 1.2mm high
after mounting on the PC board.
• Thin design
• Heat resisting design suitable for surface
mounting
• In-line surface mounting
• Two types of connections
• Embossed tape for automatic mounting
Note
:
FPC to be actually used should be checked for applicability.
* Compliant with RoHS.
* Refer to "General Instruction and Notice when using
Terminals and Connectors" at the end of this catalog.
* Contact JST for details.
Standards ––––––––––––––––––––––
1
Certified LR20812
0
Recognized E60389
PC board layout (viewed from component side) and Assembly layout
0.5
±0.03
1.2
±0.1
1.75
±0.1
1.1
±0.1
0.35
±0.03
Contact point
Normal type
No pattem allowed
1.4
±0.1
4.5・5.5
1.2
0.7
Reverse type
Contact point
1.8
±0.1
Note: 1. Tolerances are non-cumulative:
±
0.03mm for all centers.
2. The dimensions above should serve as a guideline. Contact JST for details.
1
FLH CONNECTOR
Connector
Normal type
A
0.5
Circuits
(4 to 30 circuits)
4
6
7
8
10
C
B
1.2
4.5
0.7
Model No.
Reverse type
Normal type
04FLH-SM1-TB
06FLH-SM1-TB
07FLH-SM1-TB
08FLH-SM1-TB
10FLH-SM1-TB
11FLH-SM1-TB
12FLH-SM1-TB
13FLH-SM1-TB
14FLH-SM1-TB
15FLH-SM1-TB
16FLH-SM1-TB
17FLH-SM1-TB
18FLH-SM1-TB
―
20FLH-SM1-TB
21FLH-SM1-TB
22FLH-SM1-TB
24FLH-SM1-TB
26FLH-SM1-TB
28FLH-SM1-TB
30FLH-SM1-TB
32FLH-SM1-TB
―
40FLH-SM1-TB
04FLH-RSM1-TB
06FLH-RSM1-TB
07FLH-RSM1-TB
08FLH-RSM1-TB
10FLH-RSM1-TB
11FLH-RSM1-TB
12FLH-RSM1-TB
13FLH-RSM1-TB
14FLH-RSM1-TB
15FLH-RSM1-TB
16FLH-RSM1-TB
17FLH-RSM1-TB
18FLH-RSM1-TB
19FLH-RSM1-TB
20FLH-RSM1-TB
―
22FLH-RSM1-TB
24FLH-RSM1-TB
―
28FLH-RSM1-TB
30FLH-RSM1-TB
32FLH-RSM1-TB
34FLH-RSM1-TB
40FLH-RSM1-TB
Material and Finish
Dimensions (mm)
A
C
B
1.5
2.5
3.0
3.5
4.5
5.0
5.5
6.0
6.5
7.0
7.5
8.0
8.5
9.0
9.5
10.0
10.5
11.5
12.5
13.5
14.5
15.5
16.5
19.5
2.55
3.55
4.05
4.55
5.55
6.05
6.55
7.05
7.55
8.05
8.55
9.05
9.55
10.05
10.55
11.05
11.55
12.55
13.55
14.55
15.55
16.55
17.55
20.55
7.7
8.7
9.2
9.7
10.7
11.2
11.7
12.2
12.7
13.2
13.7
14.2
14.7
15.2
15.7
16.2
16.7
17.7
18.7
19.7
20.7
21.7
22.7
25.7
Q'ty /
reel
3,000
3,000
3,000
3,000
3,000
3,000
3,000
3,000
3,000
3,000
3,000
3,000
3,000
3,000
3,000
3,000
3,000
3,000
3,000
3,000
3,000
3,000
3,000
3,000
11
12
13
14
15
16
A
0.5
(32 to 40 circuits)
17
18
19
20
21
22
24
26
28
C
B
1.2
5.5
0.7
30
32
34
40
Reverse type
A
0.5
(4 to 30 circuits)
Contact: Copper alloy, copper-undercoated, tin-plated (reflow treatment)
Housing: LCP, UL94V-0
Solder tab: Copper alloy, copper-undercoated, tin-plated (reflow treatment)
Slider: PA 6T, UL94V-0
C
B
1.2
4.5
0.7
RoHS compliance
This product displays (LF)(SN) on a label.
Note: The products listed above are supplied on embossed tape.
A
0.5
(32 to 40 circuits)
C
B
1.2
5.5
0.7
Lead section dimensions of FPC
±
0.5×
N
＋1）
0.05
（
±
0.5×
N
−1）
0.03
（
0.5
±0.03
0.35
±0.04
0.3
±0.03
3.0min.
（5.5）
Reinforcing layer
Note: N --- Number of circuits
2
