5962F0251102QXC: DescriptionSwitching Controller, Voltage-mode, 1A, 1000kHz Switching Freq-Max, CDFP20, CERAMIC, DFP-20; CategoryPower/power management The power supply circuit; File Size64KB，3 Pages; ManufacturerDefense Logistics Agency

Download Datasheet Parametric Compare View All

5962F0251102QXC Overview

Switching Controller, Voltage-mode, 1A, 1000kHz Switching Freq-Max, CDFP20, CERAMIC, DFP-20

5962F0251102QXC Parametric

Parameter Name	Attribute value
Maker	Defense Logistics Agency
Parts packaging code	DFP
package instruction	DFP,
Contacts	20
Reach Compliance Code	unknown
ECCN code	EAR99
Other features	ALSO OPERATES IN CURRENT MODE
Analog Integrated Circuits - Other Types	SWITCHING CONTROLLER
control mode	VOLTAGE-MODE
Control Technology	PULSE WIDTH MODULATION
JESD-30 code	R-CDFP-F20
Number of functions	1
Number of terminals	20
Maximum operating temperature	125 °C
Minimum operating temperature	-50 °C
Maximum output current	1 A
Package body material	CERAMIC, METAL-SEALED COFIRED
encapsulated code	DFP
Package shape	RECTANGULAR
Package form	FLATPACK
Certification status	Qualified
Filter level	MIL-PRF-38535 Class Q
surface mount	YES
Switch configuration	PUSH-PULL
Maximum switching frequency	1000 kHz
Temperature level	AUTOMOTIVE
Terminal form	FLAT
Terminal location	DUAL
total dose	300k Rad(Si) V
Base Number Matches	1

Preview

Download Datasheet

View All

IS-1825ASRH, ISL71823ASRH

Data Sheet

September 25, 2008

FN9065.3

Single Event and Total Dose Hardened,

High-Speed, Dual Output PWMs

The single event and total dose hardened IS-1825ASRH and

ISL71823ASRH pulse width modulators are designed to be

used in high frequency, switching power supplies in either

voltage or current-mode configurations. Both designs

include a precision voltage reference, a low power start-up

circuit, a high frequency oscillator, a wide-band error

amplifier and a fast current-limit comparator.

The IS-1825ASRH features dual, alternating outputs

operating from zero to less than 50% duty-cycle, while the

ISL71823ASRH features dual, in-phase outputs operating

from zero to less than 100% duty cycle.

Constructed with the Intersil Rad-hard Silicon Gate (RSG)

dielectrically isolated BiCMOS process, these devices are

immune to single event latch-up and have been specifically

designed to provide a high level of immunity to single event

transients. All specified parameters are guaranteed and

tested for 300krad(Si) total dose performance.

Detailed Electrical Specifications for these devices are

contained in SMD 5962-02511. A “hot-link” is provided

on our website for downloading the SMD.

Features

• Electrically Screened to DSCC SMD # 5962-02511

• QML Qualified per MIL-PRF-38535 Requirements

• Radiation Environment

- Total Dose. . . . . . . . . . . . . . . . . . . . . 300krad(SI) (max)

- Latch-up Immune . . . . . . . . . . . . . Dielectrically Isolated

- SEU immune . . . . . . . . . . LET = 35MeV/mg/cm

(max)

• Oscillator Frequency . . . . . . . . . . . . . . . . . . . .1MHz(max)

• High Output Drive Current . . . . . . . . . . . . . . .1A peak(typ)

• Low Start-up Current . . . . . . . . . . . . . . . . . . . 300µA(max)

• Undervoltage Lockout

- Start Threshold . . . . . . . . . . . . . . . . . . . . . . . .8.8V(max)

- Stop Threshold . . . . . . . . . . . . . . . . . . . . . . . . 7.6V(min)

- Hysteresis. . . . . . . . . . . . . . . . . . . . . . . . . . 300mV(min)

• Improved Soft-Start Function Compared with Commercial

1825A/1823A Types

• Pulse-by-Pulse Current Limiting

• Latched Overcurrent Comparator with Full Cycle Restart

• Programmable Leading Edge Blanking

Applications

• Voltage or Current-Mode Switching Power Supplies

• Control of High Current MOSFET Drivers

• Motor Speed and Direction Control

Pinouts

IS1-1825ASRH, ISL71823ASRHQD

(CDIP2-T16 SBDIP)

TOP VIEW

INV 1

NON-INV 2

E/A OUT 3

CLK/LEB 4

RT 5

CT 6

RAMP 7

SS 8

16 VREF

15 VCC

14 OUT B

13 VC

12 PGND

11 OUT A

10 GND

9 ILIM/SD

INV

NON-INV

E/A OUT

CLK/LEB

RAMP

IS9-1825ASRH, ISL71823ASRHQF

(CDFP4-F20 FLATPACK)

TOP VIEW

VREF

VCC

OUT B

PGND

OUT A

GND

ILIM/SD

CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.

1-888-INTERSIL or 1-888-468-3774

Intersil (and design) is a trademark of Intersil Americas Inc.

All other trademarks mentioned are the property of their respective owners.
