LMG12D5V datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > LED optoelectronic/LED> photoelectric> LMG12D5V

LMG12D5V: DescriptionSingle Color LED, Green, Diffused, T-1 3/4, 5mm, ROHS COMPLIANT PACKAGE-2; CategoryLED optoelectronic/LED photoelectric; File Size160KB，4 Pages; ManufacturerSUNLED; Websitehttp://www.sunled.com/; Environmental Compliance

Download Datasheet Parametric View All

LMG12D5V Overview

Single Color LED, Green, Diffused, T-1 3/4, 5mm, ROHS COMPLIANT PACKAGE-2

LMG12D5V Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
package instruction	ROHS COMPLIANT PACKAGE-2
Reach Compliance Code	compliant
ECCN code	EAR99
Other features	HIGH RELIABILITY
color	GREEN
Configuration	SINGLE
Maximum forward current	0.0175 A
Lens type	DIFFUSED
Nominal luminous intensity	19.0 mcd
Installation features	RADIAL MOUNT
Number of functions	1
Number of terminals	2
Maximum operating temperature	70 °C
Minimum operating temperature	-40 °C
Optoelectronic device types	SINGLE COLOR LED
total height	8.6 mm
method of packing	TAPE AND REEL
peak wavelength	565 nm
shape	ROUND
size	5 mm
surface mount	NO
T code	T-1 3/4
Terminal pitch	2.54 mm
perspective	30 deg
Base Number Matches	1

Preview

Download Datasheet

View All

Part Number:

LMG12D5V

www.SunLED.com

T-1 3/4 (5mm) SOLID STATE LAMP

Features

LOW POWER CONSUMPTION.

POPULAR T-1 3/4 DIAMETER PACKAGE.

GENERAL PURPOSE LEADS.

RELIABLE AND RUGGED.

LONG LIFE - SOLID STATE RELIABILITY.

AVAILABLE ON TAPE AND REEL.

5V INTERNAL RESISTOR.

RoHS COMPLIANT.

Notes:

1. All dimensions are in millimeters (inches).

2. Tolerance is ± 0.25(0.01") unless otherwise noted.

3.Specifications are subject to change without notice.

Absolute Maximum Ratings

=25°C)

Reverse Voltage

Forward Voltage

Power Dissipation

Operating Temperature

Storage Temperature

Lead Solder Temperature

[2mm Below Package Base]

Lead Solder Temperature

[5mm Below Package Base]

Tstg

(GaP)

-40 ~ +70

-40 ~ +85

260°C For 3 Seconds

260°C For 5 Seconds

Unit

Operating Characteristics

=25°C)

Forward Current (Typ.)

=5V)

Forward Current (Max.)

=5V)

Reverse Current (Max.)

=5V)

Wavelength of Peak

Emission (Typ.)

=5V)

Wavelength of Dominant

Emission (Typ.)

=5V)

Spectral Line Full Width

At Half-Maximum (Typ.)

=5V)

(GaP)

11.5

17.5

Unit

°C

565

568

Δλ

Part

Number

Emitting

Color

Emitting

Material

Lens-color

Luminous

Intensity

( V =5V )

mcd

min.

typ.

Wavelength

Viewing

Angle

1/2

LMG11D5V

Green

GaP

Green Diffused

565

Published Date : MAR 14\7, 2008

Drawing No : SDSA4851

Checked : B.L.LIU

P.1/4
