Physical Parameters
Inches
Millimeters
A
0.166 to 0.190
4.22 to 4.83
B
0.118 to 0.134
3.00 to 3.40
C
0.118 to 0.134
3.00 to 3.40
D
0.015 Min.
0.38 Min.
E
0.054 to 0.078
1.37 to 1.98
F
0.118 (Ref. only)
3.00 (Ref. only)
G
0.066 (Ref. only)
1.68 (Ref. only)
Dimensions “A” and “C” are over terminals
Operating Temperature Range
–55°C to +130°C
Current Rating at 90°C Ambient
40°C Rise
Maximum Power Dissipation at 90°C
0.278 W
Inductance
Measured at 1V with no‑DC‑current
Incremental Current
The current at which the
inductance will decrease by a maximum of 5% from
its inductance at zero DC current.
Packaging
Tape & reel (12mm): 7" reel, 650 pieces
max.; 13" reel, 2500 pieces max.
Lead Finish
Sn63Pb37
(Tin‑Lead) Hot Solder Dipped
Made In the U.S.A.
‑102K
‑122K
‑152K
‑182K
‑222K
‑272K
‑332K
‑392K
‑472K
‑562K
‑682K
‑822K
‑103K
‑123K
‑153K
‑183K
‑223K
‑273K
‑333K
‑393K
‑473K
‑563K
‑683K
‑823K
‑104K
‑124K
‑154K
‑184K
‑224K
‑274K
‑334K
‑01
‑02
‑03
‑04
‑05
‑06
‑07
‑08
‑09
‑10
‑11
‑12
‑13
‑14
‑15
‑16
‑17
‑18
‑19
‑20
‑21
‑22
‑23
‑24
‑25
‑26
‑27
‑28
‑29
‑30
‑31
MI
L
MIL-PRF-27/368 Qualified
Surface Mount Power Inductors
SERIES MILP1812 Ferrite Core
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
0.113
0.199
0.222
0.240
0.268
0.288
0.323
0.347
0.401
0.437
0.472
0.548
0.608
0.670
0.780
0.875
1.200
1.404
1.578
1.848
2.064
2.268
3.408
3.648
4.320
6.000
6.432
8.400
9.680
12.720
15.240
IN
D
±1 UCT
0% A
@ NCE
1 K (µ
Hz H)
DC
MA RES
XI IST
MU A
M NC
(O E
CU
HM
RR
S)
MA E
NT
X.
(m RA
A TI
DC NG
IN
)
CR
CU EM
RR EN
EN TA
T L
(m
A
DC
)
1050
1000
950
900
850
800
750
700
650
650
600
600
550
550
450
400
370
330
300
280
260
240
220
200
180
160
140
120
120
100
90
2400
2158
1980
1828
1697
1513
1397
1250
1131
1060
990
871
772
752
693
614
515
465
425
376
366
336
297
267
238
208
183
158
143
129
118
NU
MB
ER
*
Series
MILP1812
DA
SH
POWER INDUCTORS
M M
6 IL 27
U P /
6 18 3
0 16
9 28
Y - -3
Y 3 1
W3
W 4K
L
*Complete part # must include MILP1812 PLUS the dash #
