Low Pass Filter
50Ω
Operating Temperature
Storage Temperature
RF Power Input*
DC Current Input to Output
Ceramic
LFCN-5000+
LFCN-5000
DC to 5000 MHz
Features
-55°C to 100°C
-55°C to 100°C
9W max. at 25°C
0.5A max. at 25°C
Maximum Ratings
• excellent power handling, 9W
• small size
• 7 sections
• temperature stable
• protected by U.S. Patent 6,943,646
CASE STYLE: FV1206
Model
LFCN-5000+
LFCN-5000
LFCN-5000D+
LFCN-5000D
Price
$1.99
$1.99
$2.49
$2.49
Qty.
(10-49)
(10-49)
(10-49)
(10-49)
* Passband rating, derate linearly to 3W at 100°C ambient.
Applications
Pin Connections
RF IN
RF OUT
GROUND
** RF IN & RF OUT can be interchanged
1**
3**
2,4
• harmonic rejection
• VHF/UHF transmitters/receivers
• lab use
+ RoHS compliant in accordance
with EU Directive (2002/95/EC)
The +Suffix identifies RoHS Compliance. See our web site
for RoHS Compliance methodologies and qualifications.
Electrical Specifications
1
(T
AMB
=25°C)
PASSBAND
(MHz)
(loss < 1 dB)
Max.
DC-5000
fco, MHz
Nom.
(loss 3 dB)
Typ.
5580
STOP BAND (MHz)
(loss, dB)
F 20
Min.
6850
VSWR
(:1)
Stopband
Typ.
20
NO. OF
SECTIONS
Typ.
1.2
7
Outline Drawing
30
Typ.
7050
FR 20
Typ.
18000
Passband
1. For applications requiring DC voltage to be applied to the Input or output, use LFCN-5000D (DC Resistance to ground is 100 Mohms min.)
typical frequency response
ATTENUATION (dB)
40dB
20dB
electrical schematic
RF IN
RF OUT
PCB Land Pattern
3dB
1dB
Fco F20
FREQUENCY
FR 20dB
Typical Performance Data at 25°C
Frequency
(MHz)
Suggested Layout,
Tolerance to be within
±.002
Insertion Loss
(dB)
0.01
0.10
0.14
0.26
0.31
0.51
0.68
4.91
40.67
28.12
32.43
25.15
24.88
18.17
23.63
VSWR
(:1)
1.01
1.03
1.04
1.07
1.15
1.25
1.05
5.30
22.58
31.03
157.93
1.71
29.46
26.33
8.43
Outline Dimensions (
inch
)
mm
A
.126
3.20
H
.087
2.21
B
.063
1.60
J
.024
0.61
C
.037
0.94
K
.122
3.10
D
.020
0.51
L
.024
0.61
E
.032
0.81
M
.087
2.21
F
.009
0.23
N
.012
0.30
G
.169
4.29
P
wt
.071 grams
1.80
.020
50.00
500.00
1000.00
2000.00
3000.00
4000.00
5000.00
5800.00
6830.00
8000.00
11000.00
13000.00
15000.00
18000.00
20000.00
LFCN-5000
INSERTION LOSS
60
INSERTION LOSS (-dB)
50
Demo Board MCL P/N: TB-270
Suggested PCB Layout (PL-137)
LFCN-5000
VSWR
1000
30
20
10
0
0
5000
10000
FREQUENCY (MHz)
15000
20000
VSWR
40
100
10
1
0
5000
10000
FREQUENCY (MHz)
15000
20000
designers kit available
Kit
No.
K2-LFCN
No. of
Units in Kit
60
Description
5 of each: LFCN-800,-900,-1000,-1200,-1325,-1700,
-2000,-2250,-2400,-5000,-6000,-6700
Price $
per Kit
119.95
Distribution Centers
NORTH AMERICA 800-654-7949 • 417-335-5935 • Fax 417-335-5945 • EUROPE 44-1252-832600 • Fax 44-1252-837010
Mini-Circuits
®
INTERNET
http://www.minicircuits.com
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
Mini-Circuits
ISO 9001 & ISO 14001
Certified
REV. D
M10060
LFCN-5000
ED-6491/2
RVN/AD/CP/AM
060912
