FRF1040D datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Discrete semiconductor> diode> FRF1040D

FRF1040D: DescriptionRectifier Diode, 1 Phase, 2 Element, 5A, 400V V(RRM), Silicon, TO-220AB, ITO-220AB, 3 PIN; CategoryDiscrete semiconductor diode; File Size66KB，2 Pages; ManufacturerMOSPEC; Websitehttp://www.mospec.com.tw/eng/index.html

Download Datasheet Parametric View All

FRF1040D Overview

Rectifier Diode, 1 Phase, 2 Element, 5A, 400V V(RRM), Silicon, TO-220AB, ITO-220AB, 3 PIN

FRF1040D Parametric

Parameter Name	Attribute value
package instruction	R-PSFM-T3
Reach Compliance Code	unknown
ECCN code	EAR99
Other features	FREE WHEELING DIODE
application	EFFICIENCY
Shell connection	ISOLATED
Configuration	SERIES CONNECTED, CENTER TAP, 2 ELEMENTS
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
Maximum forward voltage (VF)	1.3 V
JEDEC-95 code	TO-220AB
JESD-30 code	R-PSFM-T3
Maximum non-repetitive peak forward current	100 A
Number of components	2
Phase	1
Number of terminals	3
Maximum operating temperature	150 °C
Minimum operating temperature	-65 °C
Maximum output current	5 A
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	FLANGE MOUNT
Maximum repetitive peak reverse voltage	400 V
Maximum reverse current	5 µA
Maximum reverse recovery time	0.25 µs
surface mount	NO
Terminal form	THROUGH-HOLE
Terminal location	SINGLE
Base Number Matches	1

Preview

Download Datasheet

View All

MOSPEC

Switchmode

Full Plastic Dual Fast Recovery Power Rectifiers

Designed for use in switching power supplies. inverters and as free

wheeling diodes. These state-of-the-art devices have the following features:

＊Glass

Passivated chip junctions

＊Low

Reverse Leakage Current

＊Fast

Switching for High Efficiency

＊150℃

Operating Junction Temperature

＊Low

Forward Voltage , High Current Capability

＊Plastic

Material used Carries Underwriters Laboratory

FRF1030 Thru FRF1060

FAST RECOVERY

RECTIFIERS

10 AMPERES

30-600 VOLTS

Flammability Classification 94V-O

Plating pb free is indicated by box

ITO-220AB

MAXIMUM RATINGS

Characteristic

Peak Repetitive Reverse Voltage

Working Peak Reverse Voltage

DC Blocking Voltage

RMS Reverse Voltage

Average Rectifier Forward Current

Per Leg

=125℃

Per Total Device

Peak Repetitive Forward Current

(Rate V

, Square Wave, 20kHz,T

=125℃)

Symbol

RRM

RWM

R(RMS)

F(AV)

300

FRF10

500

600

Unit

400

210

280

5.0

350

420

DIM

MILLIMETERS

MIN

MAX

15.05

15.15

13.35

13.45

10.00

10.10

6.55

6.65

2.65

2.75

1.55

1.65

1.15

1.25

0.55

0.65

2.50

2.60

3.00

3.20

1.10

1.20

0.55

0.65

4.40

4.60

1.15

1.25

2.65

2.75

3.35

3.45

3.15

3.25

Non-Repetitive Peak Surge Current

(Surge applied at rate load conditions

halfware, single phase, 60Hz)

Operating and Storage Junction

Temperature Range

FSM

100

, T

stg

-65 to +150

℃

ELECTRIAL CHARACTERISTICS

Characteristic

Maximum Instantaneous Forward Voltage

( I

=5.0 Amp T

= 25℃)

Maximum Instantaneous Reverse Current

( Rated DC Voltage, T

= 25℃)

( Rated DC Voltage, T

= 125℃)

Reverse Recovery Time

( I

= 0.5 A, I

=1.0 , I

=0.25 A )

Typical Junction Capacitance

(Reverse Voltage of 4 volts & f=1 MHz)

Symbol

1.3

FRF10

Unit

5.0

100

250
