PDW-1415-06-NNN-05

Description
Splitter, 1429MHz Min, 1501MHz Max, 0.5dB Insertion Loss-Max
CategoryWireless rf/communication    Radio frequency and microwave
File Size71KB,1 Pages
ManufacturerVertiv
Download Datasheet Parametric View All

PDW-1415-06-NNN-05 Overview

Splitter, 1429MHz Min, 1501MHz Max, 0.5dB Insertion Loss-Max

PDW-1415-06-NNN-05 Parametric

Parameter NameAttribute value
Reach Compliance Codeunknown
Other featuresN-F, ISOLATION-MIN (DB):20
structureCOAXIAL
Maximum input power (CW)40 dBm
Maximum insertion loss0.5 dB
Maximum operating frequency1501 MHz
Minimum operating frequency1429 MHz
RF/Microwave Device TypesSPLITTER
Maximum voltage standing wave ratio1.3
Base Number Matches1
Wireless - Cellular Products
4 & 6 Way - N Connector Interfaces
Power Dividers
4 Way
Type N
Frequency
R an g e
(MH z )
800 - 900
800 - 960
890 - 960
1429 - 1501
1700 - 1990
2400 - 2500
Model N umber
PD W-8090-04-N N N -05
PD W-8096-04-N N N -05
PD W-8996-04-N N N -05
PD W-1415-04-N N N -05
PD W-1719-04-N N N -05
PD W-2425-04-N N N -05
Amplitude
B alance
(dB )
0.3
0.3
0.3
0.3
0.3
0.3
P h ase
B alance
(deg)
+ 3.0
+ 3.0
+ 3.0
+ 3.0
+ 5.0
+ 5.0
Insertion
L o ss
(dB )max
0.30
0.30
0.30
0.40
0.40
0.40
Isolation
(dB )min
20
20
20
20
20
20
VSWR
(max)
1.20
1.20
1.20
1.20
1.20
1.20
Input
P o w er
(W)max
10.0
10.0
10.0
10.0
10.0
10.0
6 Way - Type N
Frequency
R an g e
(MH z )
800 - 900
800 - 960
890 - 960
1429 - 1501
1700 - 1990
2400 - 2500
Model N umber
PD W-8090-06-N N N -05
PD W-8096-06-N N N -05
PD W-8996-06-N N N -05
PD W-1415-06-N N N -05
PD W-1719-06-N N N -05
PD W-2425-06-N N N -05
Amplitude
B alance
(dB )
0.4
0.4
0.4
0.5
0.5
0.5
P h ase
B alance
(deg)
+ 8.0
+ 8.0
+ 8.0
+ 8.0
+ 10.0
+ 10.0
Insertion
L o ss
(dB )max
0.40
0.40
0.40
0.50
0.50
0.60
Isolation
(dB )min
20
20
20
20
20
20
VSWR
(max)
1.30
1.30
1.30
1.30
1.30
1.30
Input
P o w er
(W)max
10.0
10.0
10.0
10.0
10.0
10.0
