Type WPP
Film/Foil Polypropylene Capacitors
Axial Leaded High Frequency Pulse Capacitors
Type WPP axial-leaded, polypropylene film/foil
capacitors incorporate non-inductive extended foil
construction with epoxy end seals. Type WPP is
rated for continuous-duty operation over the temper-
ature range of –55 ºC to 105 ºC without voltage derat-
ing. Low ESR, low dissipation factor and the inherent
stability make Type WPP ideal for tight tolerance, pulse
and high frequency applications
Highlights
•
•
•
•
•
High pulse rating
High frequency operation
Low ESR
Low DF
Precise values
Specifications
Capacitance Range:
Voltage Range:
Capacitance Tolerance:
Operating Temperature Range:
Dielectric Strength:
Dissipation Factor:
Insulation Resistance:
.001 to
5.0
µF
100 to 1000 Vdc (70 to 250 Vac, 60 Hz)
±10% (K) Standard, ±5% (J) Special Order
–55 to 105 ºC
160% rated voltage for 1 minute
0.1% Max @ 25 ºC, 1 kHz
100,000 MΩ x µF
200,000 MΩ Min.
Life Test:
500 h @ 85 ºC at 125% rated voltage
Pulse Capability
Rated
Voltage
100
200
400
600
Note:
Other capacitances values, sizes and performance specifications
are available. Contact CDE.
Pulse Capability:
Outline Drawing
Body Length
0.625
4200
6900
19500
60000
.750-.875 .937-1.125 1.250-1.312 1.375-1.562 ≥1.750
dv/dt – volts per microsecond, maximum
4000
4100
10000
20000
37000
2900
3000
3900
12000
15000
6700
9200
7400
1900
2400
1600
2000
2600
1100
1400
2200
3000
3400
1000
Ratings
Cap
(µF)
Catalog
D
100 Vdc (70 Vac)
0.0010 WPP1D1K–F
0.220
(5.6) 0.625 (15.9) 0.020 (0.5)
(5.6) 0.625 (15.9) 0.020 (0.5)
(5.6) 0.625 (15.9) 0.020 (0.5)
(5.8) 0.625 (15.9) 0.020 (0.5)
(6.1) 0.625 (15.9) 0.020 (0.5)
(6.3) 0.625 (15.9) 0.020 (0.5)
0.0015 WPP1D15K–F 0.220
0.0022 WPP1D22K–F 0.220
0.0033 WPP1D33K–F 0.228
0.0047 WPP1D47K–F 0.240
0.0068 WPP1D68K–F 0.250
L
d
Part Number Inches (mm) Inches (mm) Inches (mm)
Cap
(µF)
Catalog
D
RoHS Compliant
L
d
Inches (mm)
0.020
0.020
0.020
0.024
0.024
0.024
(0.5)
(0.5)
(0.5)
(0.6)
(0.6)
(0.6)
Part Number Inches (mm) Inches (mm)
100 Vdc (70 Vac)
0.0100 WPP1S1K–F
0.250
(6.3)
(6.3)
(6.9)
(8.1)
(7.6)
(8.9)
0.625
0.625
0.625
0.625
0.875
0.875
(15.9)
(15.9)
(15.9)
(15.9)
(22.2)
(22.2)
0.0150 WPP1S15K–F 0.250
0.0220 WPP1S22K–F 0.270
0.0330 WPP1S33K–F 0.319
0.0470 WPP1S47K–F 0.298
0.0680 WPP1S68K–F 0.350
CDE Cornell Dubilier • 1605 E. Rodney French Blvd. • New Bedford, MA 02744 • Phone: (508)996-8561 • Fax: (508)996-3830 • www.cde.com
