CL
Vishay Dale
Wirewound Resistors, Commercial Power, Tab Type Terminals
FEATURES
•
Variety of core diameters and lengths
•
Numerous mounting hole sizes and shapes
•
High performance for low cost
APPLICATIONS
Appliance applications include food mixers, coffee makers,
electric and electronic ranges, electric blankets, actuating
heaters for bi-metal switches, toasters and deep fryers.
Other applications include toys, entertainment devices such as
television, radio and amplifiers.
STANDARD ELECTRICAL SPECIFICATIONS
GLOBAL MODEL*
HISTORICAL MODEL*
POWER RATING
RESISTANCE RANGE
P
25
°
C
Ω
W
±
10% Standard,
±
5% Available
3.8
0.10 - 685
4
0.11 - 740
5
0.15 - 1.02k
6
0.19 - 1.35k
8
0.27 - 1.86k
9
0.31 - 2.14k
12
0.43 - 2.99k
5.7
0.10 - 175
6
0.10 - 190
8
0.13 - 285
10
0.18 - 380
12
0.22 - 475
14
0.27 - 570
18
0.35 - 765
WEIGHT
(Typical)
g
1.08
1.09
1.16
1.23
1.37
1.44
1.65
2.30
2.35
2.68
2.97
3.35
3.68
4.35
CL4095
CL4100
CL4125
CL4150
CL4200
CL4225
CL4300
CL6095
CL6100
CL6133
CL6167
CL6200
CL6233
CL6300
CL-4095
CL-4100
CL-4125
CL-4150
CL-4200
CL-4225
CL-4300
CL-6095
CL-6100
CL-6133
CL-6167
CL-6200
CL-6233
CL-6300
* CL4000 and CL6000 model numbers are calculated from the CL4000 power rating of 4 watts per inch and CL6000 power rating of 6 watts
per inch. The last three digits of the model number represent the mounting center spacing of the resistor in inches (decimal is between the
first and second digit, mounting center spacing is available between 0.95 [24.13mm] and 3.00 [76.20mm]). Example: CL6133 = 1.33 inches
x 6 watts per inch = 8 watts.
TECHNICAL SPECIFICATIONS
PARAMETER
Power Rating
Temperature Coefficient
Short Time Overload
Maximum Working Voltage
Operating Temperature Range
Terminal Strength
UNIT
W
ppm/°C
-
V
°C
lb
CL4000
CL6000
4 per inch
6 per inch
±
600 below 1.0Ω,
±
300 1.0Ω and above
5 x rated power for 5 seconds
(P x R)
1/2
- 65/+ 375
10 minimum
GLOBAL PART NUMBER INFORMATION
New Global Part Numbering: CL4100XX100RJB1410 (preferred part numbering format)
C
L
4
1
0
0
X
X
1
0
0
R
J
B
1
4
1
0
GLOBAL MODEL
(See Standard Electrical
Specifications Global Model
column for options)
LEFT
TERMINAL
A
B
C
D
F
X
RIGHT
TERMINAL
A
B
E
D
F
X
VALUE
R
= Decimal
K
= Thousand
R150
= 0.15Ω
1K00
= 1,000Ω
TOLERANCE
H
=
±
3.0%
J
=
±
5.0%
K
=
±
10%
PACKAGING
SPECIAL
B14
= Bulk
(Dash Number)
B31
= Four layer bulk (up to 2 digits)
From
1-99
as
applicable
Historical Part Number example: CL-4100XX-10 100Ω 5%
B14 (will continue to be accepted)
CL-4100XX-10
HISTORICAL MODEL
100Ω
RESISTANCE VALUE
5%
TOLERANCE
CODE
B14
PACKAGING
www.vishay.com
52
For technical questions, contact ww2aresistors@vishay.com
Document Number 30222
Revision 09-Sep-04
CL
Wirewound Resistors, Commercial Power, Tab Type Terminals
DIMENSIONS
B
C
Vishay Dale
D
0.140
[3.56]
F
0.140 [3.56]
A
Left Terminal
Right Terminal
E
G
GLOBAL
MODEL
DIMENSIONS
in inches [millimeters]
A
B
C
D
E
±
0.020 [0.508] Typical
±
0.010 [0.254]
±
0.010 [0.254]
±
0.005 [0.127]
GLOBAL
MODEL
TERMINAL HOLE OPTIONS AND DIMENSIONS
in inches [millimeters]
CL4095
0.95 [24.13] 0.105 [2.67] 0.344 [8.73] 0.475 [12.07] 0.015 [0.38]
CL4100
1.00 [25.40] 0.105 [2.67] 0.344 [8.73] 0.475 [12.07] 0.015 [0.38]
CL4125
1.25 [31.75] 0.105 [2.67] 0.344 [8.73] 0.475 [12.07] 0.015 [0.38]
CL4150
1.50 [38.10] 0.105 [2.67] 0.344 [8.73] 0.475 [12.07] 0.015 [0.38]
CL4200
2.00 [50.80] 0.105 [2.67] 0.344 [8.73] 0.475 [12.07] 0.015 [0.38]
CL4225
2.25 [57.15] 0.105 [2.67] 0.344 [8.73] 0.475 [12.07] 0.015 [0.38]
CL4300
3.00 [76.20] 0.105 [2.67] 0.344 [8.73] 0.475 [12.07] 0.015 [0.38]
CL6095
0.95 [24.13] 0.170 [4.32] 0.334 [8.73] 0.575 [14.61] 0.018 [0.46]
CL6100
1.00 [25.40] 0.170 [4.32] 0.344 [8.73] 0.575 [14.61] 0.018 [0.46]
CL6133
1.33 [33.78] 0.170 [4.32] 0.344 [8.73] 0.575 [14.61] 0.018 [0.46]
CL6167
1.67 [42.42] 0.170 [4.32] 0.344 [8.73] 0.575 [14.61] 0.018 [0.46]
CL6200
2.00 [50.80] 0.170 [4.32] 0.344 [8.73] 0.575 [14.61] 0.018 [0.46]
CL6233
2.33 [59.18] 0.170 [4.32] 0.344 [8.73] 0.575 [14.61] 0.018 [0.46]
CL6300
3.00 [76.20] 0.170 [4.32] 0.344 [8.73] 0.575 [14.61] 0.018 [0.46]
CL6000
CL4000
LEFT
F
G
OPTION
±
0.010 [0.254]
±
0.010 [0.254]
RIGHT
F
G
OPTION
±
0.010 [0.254]
±
0.010 [0.254]
A
B
C
D
A
B
C
F
0.130 [3.30] 0.160 [4.06]
0.172 [4.37] 0.210 [5.33]
0.200 [5.08] 0.220 [5.59]
0.128 [3.25] 0.128 [3.25]
0.130 [3.30] 0.160 [4.06]
0.172 [4.37] 0.210 [5.33]
0.200 [5.08] 0.220 [5.59]
0.180 [4.57] 0.180 [4.57]
A
B
E
D
A
B
E
F
0.130 [3.30] 0.160 [4.06]
0.172 [4.37] 0.210 [5.33]
0.200 [5.08] 0.210 [5.33]
0.128 [3.25] 0.128 [3.25]
0.130 [3.30] 0.160 [4.06]
0.172 [4.37] 0.210 [5.33]
0.200 [5.08] 0.210 [5.33]
0.180 [4.57] 0.180 [4.57]
RATED POWER IN %
MATERIAL SPECIFICATIONS
Element:
Nickel-chrome alloy or copper-nickel alloy,
depending on resistance value
Core:
Woven fiberglass
Terminals:
Electro tin plated steel
120
100
80
60
40
20
Part Marking:
Resistance is stamped on terminal in two
places, maximum of three characters
0
-65
-50
0
25
75
150
225
300
375
AMBIENT TEMPERATURE IN
°
C
PERFORMANCE
TEST
Thermal Shock
Short Time Overload
Low Temperature Operation
Humidity
Load Life
Resistance to Solder Heat
CONDITIONS OF TEST
- 55°C to + 275°C, 5 cycles, 30 minute dwell time
5 x rated power for 5 seconds
- 65°C, full rated working voltage for 45 minutes
75°C, 90% - 100% RH, 240 hours
1000 hours at rated power, + 25°C, 1.5 hours "ON", 0.5 hours "OFF"
Terminal immersed 3.5 seconds in molten solder at 1/8" to 3/16" from body
TEST LIMITS (EIA RS-344)
±
(5.0% + 0.05Ω)∆R
±
(4.0% + 0.05Ω)∆R
±
(3.0% + 0.05Ω)∆R
±
(5.0% + 0.05Ω)∆R
±
(10.0% + 0.05Ω)∆R
±
(4.0% + 0.05Ω)∆R
Document Number 30222
Revision 09-Sep-04
For technical questions, contact ww2aresistors@vishay.com
www.vishay.com
53
