CZA06S04010050HRT

Description
RF/Microwave Attenuator, 0 MHz - 3000 MHz RF/MICROWAVE FIXED ATTENUATOR, SURFACE MOUNT PACKAGE-4
CategoryWireless rf/communication    Radio frequency and microwave
File Size97KB,3 Pages
ManufacturerVishay
Websitehttp://www.vishay.com
Download Datasheet Parametric View All

CZA06S04010050HRT Overview

RF/Microwave Attenuator, 0 MHz - 3000 MHz RF/MICROWAVE FIXED ATTENUATOR, SURFACE MOUNT PACKAGE-4

CZA06S04010050HRT Parametric

Parameter NameAttribute value
Reach Compliance Codeunknown
Nominal attenuation1 dB
Characteristic impedance50 Ω
structureCOMPONENT
Maximum input power (CW)18.75 dBm
JESD-609 codee0
Maximum operating frequency3000 MHz
Minimum operating frequency
Maximum operating temperature70 °C
Minimum operating temperature-55 °C
RF/Microwave Device TypesFIXED ATTENUATOR
Terminal surfaceTIN LEAD
Maximum voltage standing wave ratio1.2
Base Number Matches1
CZA
Vishay Dale
Thick Film Chip Resistor Attenuator, Surface Mount
FEATURES
Single component reduces board space and
component counts - replaces 3 or more
components
Tolerance matching and temperature tracking
superior to individual components
Maximum power dissipation: 0.075 W for
CZA06S; 0.040 W for CZA04S
Consult
factory
for
extended
values,
non-standard tolerances, impedance matching
and other attenuation values
Frequency range: DC to 3 GHz
Compliant to RoHS directive 2002/95/EC
STANDARD ELECTRICAL SPECIFICATIONS
GLOBAL MODEL
CZA04S
CZA06S
Note
Power rating depends on the maximum temperature at the solder point, the component placement density and the substrate material.
IMPEDANCE
50
Ω
1
1.5
2
3
4
5
6
10
11
12
13
14
15
16
17
18
19
20
75
Ω
1
1.5
2
3
4
5
6
10
11
12
13
14
15
16
17
18
19
20
100
Ω
1
1.5
2
3
4
5
6
10
11
12
13
14
15
16
17
18
19
20
300
Ω
1
1.5
2
3
4
5
6
10
11
12
13
14
15
16
17
18
19
20
600
Ω
1
1.5
2
3
4
5
6
10
11
12
13
14
15
16
17
18
19
20
POWER RATING
P
70 °C
W
0.040
0.075
IMPEDANCE
Ω
50
50/75/100/300/600
ATTENUATION RANGE AND TOLERANCE
± 0.3 dB (L)
± 0.5 dB (H)
1 dB to 5 dB
6 dB to 20 dB
1 dB to 5 dB
6 dB to 20 dB
CIRCUIT SCHEMATIC
4-PIN CIRCUIT
CZA04S
(Marking)
(Marking)
CZA06S
2
R2
3
1
4
R2
2
3
R2
Attenuation
in
dB
1
R2
4
R1
R1
Unbalanced
π
Type
Unbalanced
π
Type
TECHNICAL SPECIFICATIONS
PARAMETER
Rated dissipation at 70 °C
VSWR
Category temperature range
Frequency range
UNIT
W
°C
CZA04S
0.040
1.2 max.
- 55 to + 125
DC to 3 GHz
CZA06S
0.075
1.2 max.
- 55 to + 150
DC to 3 GHz
GLOBAL PART NUMBER INFORMATION
New Global Part Numbering: CZA06S04015050LRT (preferred part numbering format)
C
MODEL
CZA04S
CZA06S
Z
A
0
6
S
0
4
0
1
5
0
5
0
L
R
T
SPECIAL
(Dash number)
Up to 1 digit
Blank = Standard
PIN COUNT
04
= 4 pin
ATTENUATION
IMPEDANCE
TOLERANCE
010
= 1.0 dB
H
= ± 0.5 dB
050
= 50
Ω
015
= 1.5 dB
075
= 75
Ω
L
= ± 0.3 dB
020
= 2.0 dB
100
= 100
Ω
Z
= 0
Ω
Jumper
150
= 15.0 dB
000
= 0
Ω
Jumper
000
= 0
Ω
Jumper
04
PIN COUNT
015
ATTENUATION
050
IMPEDANCE
PACKAGING
EA
=Lead (Pb)-free, T/R (all)
TD
= Tin lead, T/R (04 only)
RT
= Tin lead, T/R (06 only)
Historical Part Number Example: CZA06S04015050LRT (will continiue to be accepted)
CZA
MODEL
06S
CASE SIZE
L
TOLERANCE
RT
PACKAGING
* Pb containing terminations are not RoHS compliant, excemptions may apply
www.vishay.com
254
For technical questions, contact:
ff2aresistors@vishay.com
Document Number: 31061
Revision: 27-Apr-10
