FEATURES
APPLICATIONS
Wireless Network
Telecom/Datacom
Industry Control System
Measurement Equipment
Semiconductor Equipment
•
1 WATT UNREGULATED OUTPUT POWER
•
OUTPUT CURRENT UP TO 0.2A
•
SINGLE-IN-LINE PACKAGE (SIP)
•
HIGH EFFICIENCY FOR LOW POWER APPLICATION
•
INPUT RANGE FROM 4.5VDC TO 5.5VDC, 10.8VDC TO 13.2 VDC,
13.5VDC TO 16.5VDC AND 21.6VDC TO 26.4VDC
•
UL 94-V0 NON-CONDUCTED CASE
•
INTERNAL INPUT & OUTPUT FILTER
•
INPUT / OUTPUT ISOLATION UP TO 3KVDC
•
SUFFIX-N ISOLATION LEVEL REINFORCE
•
CE MARK MEETS 2006/95/EC, 93/68/EEC AND 2004/108/EC
•
UL60950-1, EN60950-1 AND IEC60950-1 LICENSED
•
ISO9001 CERTIFIED MANUFACTURING FACILITIES
•
COMPLIANT TO RoHS EU DIRECTIVE 2002/95/EC
OPTIONS
3KV ISOLATION
DESCRIPTION
The DU1P0 series are the standard building blocks for on-board
distributed power systems. They are ideally suited to provide single and
dual supplies on primarily digital boards with added benefit of galvanic
isolation to reduce switching noise.
All specifications are typical at nominal input, full load and 25ºC otherwise noted
T E C H N I C A L S P E C I F I C AT I O N
OUTPUT SPECIFICATIONS
Output power
Voltage accuracy
Minimum load (Note 6)
Line regulation
Load regulation
Ripple and noise
Temperature coefficient
Short circuit protection (Note 7)
LL to HL at Full Load
20% to 100% FL
20MHz bandwidth
5V output
others
Full load and nominal Vin
INPUT SPECIFICATIONS
1 Watt, max.
± 5%
10% of FL
1.3% / 1% of Vin
± 10%
± 8%
See table
±0.1%
/ ºC, max.
1 Sec.
Input filter
Input voltage range
5V nominal input
12V nominal input
15V nominal input
24V nominal input
4.5 – 5.5VDC
10.8 – 13.2VDC
13.5 – 16.5VDC
21.6 – 26.4VDC
Capacitor
ENVIRONMENTAL SPECIFICATIONS
Operating ambient temperature
Storage temperature range
Thermal shock
Vibration
-25ºC ~ +85ºC
(with derating)
-55ºC ~ +105ºC
MIL-STD-810F
MIL-STD-810F
5% to 95% RH
GENERAL SPECIFICATIONS
Efficiency
Isolation voltage
Isolation resistance
Isolation capacitance
Switching frequency
Approvals and standard
Case material
Base material
Potting material
Dimensions
Weight
MTBF (Note 1)
BELLCORE TR-NWT-000332
MIL-HDBK-217F
Input to Output
Standard
Suffix-N
See table
1000VDC, min.
3000VDC, min.
10 ohms, min.
30pF, max.
60KHz, min.
IEC60950-1, UL60950-1, EN60950-1
Non-conductive black plastic
None
Epoxy (UL94-V0)
0.77 X 0.24 X 0.40 Inch
(19.6 X 6.1 X 10.2 mm)
2.0g (0.071oz)
1.471 x 10 hrs
7
1.238 x 10 hrs
7
Relative humidity
9
Page 1 of 2 Issued Date：2009/03/06
Model
Number
DU1P0-05S05
DU1P0-05S12
DU1P0-05S15
DU1P0-05D05
DU1P0-05D12
DU1P0-05D15
DU1P0-12S05
DU1P0-12S12
DU1P0-12S15
DU1P0-12D05
DU1P0-12D12
DU1P0-12D15
DU1P0-15S05
DU1P0-15S12
DU1P0-15S15
DU1P0-15D05
DU1P0-15D12
DU1P0-15D15
DU1P0-24S05
DU1P0-24S12
DU1P0-24S15
DU1P0-24D05
DU1P0-24D12
DU1P0-24D15
Input
Range
4.5 – 5.5 VDC
4.5 – 5.5 VDC
4.5 – 5.5 VDC
4.5 – 5.5 VDC
4.5 – 5.5 VDC
4.5 – 5.5 VDC
10.8 – 13.2 VDC
10.8 – 13.2 VDC
10.8 – 13.2 VDC
10.8 – 13.2 VDC
10.8 – 13.2 VDC
10.8 – 13.2 VDC
13.5 – 16.5 VDC
13.5 – 16.5 VDC
13.5 – 16.5 VDC
13.5 – 16.5 VDC
13.5 – 16.5 VDC
13.5 – 16.5 VDC
21.6 – 26.4 VDC
21.6 – 26.4 VDC
21.6 – 26.4 VDC
21.6 – 26.4 VDC
21.6 – 26.4 VDC
21.6 – 26.4 VDC
Output
Voltage
5 VDC
12 VDC
15 VDC
± 5 VDC
± 12 VDC
± 15 VDC
5 VDC
12 VDC
15 VDC
± 5 VDC
± 12 VDC
± 15 VDC
5 VDC
12 VDC
15 VDC
± 5 VDC
± 12 VDC
± 15 VDC
5 VDC
12 VDC
15 VDC
± 5 VDC
± 12 VDC
± 15 VDC
Output Current
Min. load
20mA
8.3mA
6.7mA
± 10mA
± 4.2mA
± 3.3mA
20mA
8.3mA
6.7mA
± 10mA
± 4.2mA
± 3.3mA
20mA
8.3mA
6.7mA
± 10mA
± 4.2mA
± 3.3mA
20mA
8.3mA
6.7mA
± 10mA
± 4.2mA
± 3.3mA
Capacitor
Input Current
Output
(4)
Eff
(4)
Load
(3)
(2)
(%)
Full load Ripple & Noise No load Full load
max
(5)
200mA
83mA
67mA
± 100mA
± 42mA
± 33mA
200mA
83mA
67mA
± 100mA
± 42mA
± 33mA
200mA
83mA
67mA
± 100mA
± 42mA
± 33mA
200mA
83mA
67mA
± 100mA
± 42mA
± 33mA
100mVp-p
100mVp-p
100mVp-p
100mVp-p
100mVp-p
100mVp-p
100mVp-p
100mVp-p
100mVp-p
100mVp-p
100mVp-p
100mVp-p
100mVp-p
100mVp-p
100mVp-p
100mVp-p
100mVp-p
100mVp-p
100mVp-p
100mVp-p
100mVp-p
100mVp-p
100mVp-p
100mVp-p
42mA
32mA
35mA
40mA
35mA
40mA
17mA
17mA
18mA
18mA
18mA
18mA
20mA
18mA
18mA
18mA
16mA
16mA
12mA
12mA
10mA
12mA
10mA
10mA
274mA
255mA
261mA
270mA
258mA
257mA
114mA
106mA
112mA
114mA
109mA
106mA
97mA
89mA
88mA
94mA
88mA
87mA
61mA
56mA
57mA
59mA
57mA
55mA
77
82
81
78
82
81
77
82
79
77
81
82
73
79
80
75
80
80
72
78
78
75
78
79
330μF
330μF
330μF
±150μF
±150μF
±150μF
330μF
330μF
330μF
±150μF
±150μF
±150μF
330μF
330μF
330μF
±150μF
±150μF
±150μF
330μF
330μF
330μF
±150μF
±150μF
±150μF
Note
1.
2.
3.
4.
5.
6.
7.
BELLCORE TR-NWT-000332. Case 1: 50% Stress, Temperature at 40ºC.
MIL-HDBK-217F Notice2 @Ta=25 ºC, Full load(Ground, Benign, controlled environment).
Maximum value at nominal input voltage and full load of standard type.
Typical value at nominal input voltage and no load.
Typical value at nominal input voltage and full load.
Test by minimum Vin and constant resistive load.
The output requires a minimum loading on the output to maintain specified regulation.
Operation under no-load condition will not damage these devices, however they may not
meet all listed specification.
Internal fuse is not included, so we suggest to use an input line fuse.
STANDARD
0.77(19.6)
PIN
1
2
4
5
6
SINGLE
+ INPUT
- INPUT
- OUTPUT
NC
+ OUTPUT
DUAL
+ INPUT
- INPUT
- OUTPUT
COMMON
+ OUTPUT
0.016(0.41)
FRONT VIEW
0.14(3.6)
0.40(10.2)
0.01x0.02
(0.25x0.5) Rectangular Pin
0.100(2.54)
0.200(5.08)
BOTTOM VIEW
2
4 5 6 7
0.085(2.16)
0.24
(6.1)
0.075(1.91)
1
“N” Models
0.010(0.25)
PIN
1
2
5
6
7
SINGLE
+ INPUT
- INPUT
DUAL
+ INPUT
- INPUT
1. All dimensions in inches (mm)
Tolerance: X.XX±0.02 (X.X±0.5)
X.XXX±0.01 (X.XX±0.25)
2. Pin pitch tolerance
±0.01(0.25)
3. Pin dimension tolerance
±0.004
(0.1)
- OUTPUT - OUTPUT
NC
COMMON
+ OUTPUT + OUTPUT
Page 2 of 2 Issued Date：2009/03/06
