Signal Toroidal Power Transformers
Power in the Round 100 VA to 2000 VA
The STP series of transformers offer VA power ranges from
100 VA to 2000 VA inclusive. These standard transformer products
share common lead lengths, colors, mounting configurations and more,
The STP series are designed to comply with international safety standards.
Benefits
• Minimal core losses
• Low profile
• Power/mass efficient
• Reduced EMI
• Low dB
• RoHS compliant
General Specifications
• Power - 100 VA to 2000 VA
• Dual Primaries - 2 x 115 V - 50/400 Hz
• Dual Secondaries - Standard outputs 2 x 115V with multiple output
configurations available
• Connections: 12.0” color-coded stranded leads
• Mounting: Single fastener with isolation pads and top plate standard
• Insulation System - Class B, 130º C
• Component certifications for North American and IEC/EN standards
available on request
• UL Recognized to UL 506, File number E63829
• Custom designs available on request
Power
Range
VA
STP-0100-2115
STP-0150-2115
STP-0200-2115
STP-0250-2115
STP-0300-2115
STP-0400-2115
STP-0500-2115
½
Part Number
1
Dimensions
2
Inches (mm)
A
4.2
(105)
4.6
(116)
4.8
(120)
5.0
(127)
5.1
(128)
5.3
(133)
5.6
(140)
6.1
(155)
6.7
(170)
7.1
(180)
7.8
(198)
8.3
(210)
9.2
(232)
TBD
B
1.4
(35)
1.7
(42)
1.9
(48)
2.0
(50)
2.2
(55)
2.8
(70)
2.9
(72)
2.9
(72)
2.9
(72)
3.1
(78)
3.2
(80)
3.4
(86)
3.6
(90)
TBD
Weight
lbs
(kg)
2.86
(1.3)
4.40
(2.0)
5.30
(2.4)
6.40
(2.9)
7.0
(3.2)
10.3
(4.7)
12.1
(5.5)
14.8
(6.7)
18.0
(8.2)
22.1
(10.0)
29.5
(13.4)
35.3
(16.0)
44.1
(20.0)
TBD
Recommended
Fastener Size
#8
#10
1/4”
1/4”
1/4”
5/16”
3/8”
3/8”
3/8”
3/8”
3/8”
1/2”
1/2”
Custom per
customer spec
100
150
200
250
300
400
500
600
800
1000
1200
1600
2000
TBD
½
STP-0600-2115
STP-0800-2115
STP-1000-2115
Notes:
1.
STP transformers having dual secondary windings may be ordered by specifying
the power range, output voltage and current requirements. (A 250VA transformer
with two 24V secondary windings = STP-0250-2024. A 1200 VA transformer
with two 120V windings = STP-1200-2120.) Where dissimilar or multiple output
configurations are required, please contact Customer Service for additional
information. In all cases, a serialized part number will be assigned to the final
product label.
2.
The dimension profiles depicted for each VA range are for standard transformers
with 2 x 115V output configurations. Dimensions of transformers with multiple
outputs, dissimilar outputs or ELV outputs may vary.
STP-1200-2115
STP-1600-2115
STP-2000-2115
STP-XXXX-YYYY
Custom versions available upon request.
©2007 Signal Transformer Inc. Specifications subject to change without notice. 08.07
www.signaltransformer.com
500 Bayview Avenue, Inwood, NY 11096
Toll Free 866-239-5777 • Tel 516-239-5777 • Fax 516-239-7208
sales@signaltransformer.com • techhelp@signaltransformer.com
