8
7
6
5
4
REV
A
B
C
D
3
DESCRIPTION
RELEASED FOR PRODUCTION
REVISED TOLERANCES (ECN 1489)
2
REVISIONS
1
DATE
11/02/03
09/08/03
11/03/03
2/8/08
CHANGED BY
MCCORMICK
MCCORMICK
MCCORMICK
D.GRIFFIN
THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE
PROPERTY OF L-COM, INC. ANY REPRODUCTION IN PART OR WHOLE
WITHOUT THE WRITTEN PERMISSION OF L-COM, INC. IS PROHIBITED.
INSULATOR WAS POLYPROPYLENE (ECN 1576)
ECN 3194: UPDATE DWG FORMAT
D
D
1.2[30.48]
.5 [12.7]
C
BNC PLUG
C
B
NOTES:
MATERIALS:
SHELL: BRASS
CONTACTS: BRASS
INSULATOR: ACETAL
FINISH:
SHELL: NICKEL
CONTACT: GOLD
ELECTRICAL:
CHARACTERISTIC IMPEDANCE: 50 OHM
B
RoHS Compliant
APPROVALS
UNLESS OTHERWISE SPECIFIED,
DRAWN BY
DIMENSIONS ARE IN INCHES [mm]
C.MCCORMICK
TOLERANCES TO BE:
.X .1 [2.5]
ANGLES 2 CHECKED BY
.XX .01 [.25]
D.PARHAM
.XXX .005 [.13]
OVERALL CABLE LENGTH TOL:
≤
60 [1524] +3 [76.2] / - 0
> 60 [1524] +5% / -0%
PROJ
APPROVED BY
R.CARRICK
DATE
CATEGORY
11/01/2001
11/01/2001
11/01/2001
SIZE
PRODUCT DESCRIPTION
A
45 BEECHWOOD DRIVE
NORTH ANDOVER, MA
01845
APPLICATION NOTES:
RESISTOR; 1/4 WATT CARBON FILM TYPE
PACKAGING:
INDIVIDUALLY PACKAGE IN A POLYBAG
COAXIAL
50 OHM BNC TERMINATOR
A
CONFIGURATION DETAILS OF
UNDIMENSIONED FEATURES
MAY VARY
SCALE: NONE CAD FILE:
A
43321
FSCM NO.
DWG. NO.
BTB5MD
1
REV.
SHEET 1 OF 1
BTB5MD.SLDDRW
D
8
7
6
5
4
3
2
