3.3V LOW PROFILE SMD VCXO
MODEL: VCSAXT SERIES
FEATURES
•
•
•
•
OPTIONS
• Many Stability/Pullability Options
3.3V Operation
• -40ºC ~ +85ºC Option ('R' Version)
HCMOS Output
Enable/Disable
Tape and Reel (2,000 pcs. STD)
• PART NUMBER SELECTION
Learn More - Internet Required
Part Number
421-Frequency-xxxxx
437-Frequency-xxxxx
422-Frequency-xxxxx
439-Frequency-xxxxx
423-Frequency-xxxxx
443-Frequency-xxxxx
424-Frequency-xxxxx
445-Frequency-xxxxx
425-Frequency-xxxxx
441-Frequency-xxxxx
Model
Number
VCS12AXT
VCS12AXTR
3
VCS15AXT
VCS15AXTR
VCS22AXT
VCS22AXTR
3
VCS25AXT
VCS25AXTR
VCS20AXT
VCS20AXTR
Frequency Frequency Operating
Frequency
Stability
1
Pullability Temperature
±50PPM -10 ~ +70(ºC) 1.000~80.000
±25PPM
±50PPM -40 ~ +85(ºC) 1.000~80.000
±25PPM
±50PPM -10 ~ +70(ºC) 1.000~80.000
±50PPM
±50PPM -40 ~ +85(ºC) 1.000~80.000
±50PPM
±100PPM -10 ~ +70(ºC) 1.000~80.000
±25PPM
±100PPM -40 ~ +85(ºC) 1.000~80.000
±25PPM
±100PPM -10 ~ +70(ºC) 1.000~80.000
±50PPM
±100PPM -40 ~ +85(ºC) 1.000~80.000
±50PPM
±100PPM ±100PPM -10 ~ +70(ºC) 1.000~80.000
±100PPM ±100PPM -40 ~ +85(ºC) 1.000~80.000
Learn more about:
Part Marking Identification
Tape and Reel Specification
Internet required
• ELECTRICAL CHARACTERISTICS
PARAMETERS
Frequency Range (F
O
)
Storage Temperature Range (T
STG
)
Supply Voltage
(V
DD
)
Control Voltage
(V
C
)
Input Current
(I
DD
)
1.000 ~ 30.000 MHz
30.000+ ~ 45.000 MHz
45.000+ ~ 80.000 MHz
Output Symmetry (50% V
DD
)
Rise Time (10% ~ 90% V
DD
) (T
R
)
Fall Time (90% ~ 10% V
DD
) (T
F
)
Output Voltage
(V
OL
)
(V
OH
)
Output Current
(I
OL
)
(I
OH
)
Output Load
(HCMOS)
Start-up Time
(T
S
)
Enable/Disable Time
2
Frequency Linearity
Modulation Bandwidth
1
MAX
(unless otherwise noted)
1.000 ~ 80.000
4
MHz
-40ºC ~ +85ºC
3.3V ± 10%
1.65V ± 1.5V
15mA
25mA
50mA
40% ~ 60%
5nS
5nS
10% V
DD
90% V
DD
Min
4.0mA Min
-1.0mA Min
15pF
10mS
150nS
±10%
20 kHz
Inclusive of 25ºC tolerance, operating temperature range, input voltage change, load change, aging,
shock, vibration, and Vc = 1.65V.
2
An internal pullup resistor from pin 2 to pin 6 allows active output if pin 2 is left open.
3
Available on an individual inquiry basis.
4
Custom specifications from 45.000 to 80.000 MHz available on an individual inquiry basis.
Note: A 0.01µF bypass capacitor should be placed between V
DD
(Pin 6) and GND (Pin 3) to
minimize power supply line noise.
Note: An alternate pin connection with E/D on pin #5 is available.
All specifications subject to change without notice.
Rev. 6/1/04
All dimensions are in millimeters.
• ENABLE / DISABLE FUNCTION
INH (Pin 2)
OUTPUT (Pin 4)
2
OPEN
ACTIVE
'1' Level V
IH
≥
70% V
DD
ACTIVE
'0' Level V
IL
≤
30% V
DD
High Z
76
FOXElectronics
5570 Enterprise Parkway Fort Myers, Florida 33905 USA +1(239)693-0099 FAX +1(239)693-1554
http://www.foxonline.com
© 2004 FOX ELECTRONICS
