TOP LED SMT505-23
Lead (Pb) Free Product RoHS compliant
SMT505-23
♦Specifications
1) Product Name
2) Type No.
3) Chip
(1) Chip Material
(2) Peak Wavelength
4) Package
(1) Lead Frame Die
(2) Package Resin
(3) Lens
(4) Diameter
High Performance Cyan color TOP LED with Lens
SMT505-23 consists of an InGaN LED mounted on the lead frame as TOP LED package
with a plastic ball lens and 3200mcd of brightness driving at 20mA.
It emits a spectral band of radiation at 505nm.
♦Outer
dimension (Unit: mm)
TOP LED
SMT505-23
InGaN
505nm typ.
Silver Plated
PPA Resin
Epoxy Resin
Φ2.6mm
♦Absolute
Maximum Ratings
Item
Symbol
Maximum Rated Value
Unit
Ambient Temperature
Power Dissipation
P
D
185
mW
Ta=25°C
Forward Current
I
F
50
mA
Ta=25°C
Reverse Voltage
V
R
5
V
Ta=25°C
Operating Temperature
T
OPR
-20 ~ +80
°C
Storage Temperature
-30 ~ +80
°C
T
STG
Soldering Temperature
T
SOL
240
°C
‡Soldering condition: Soldering condition must be completed within 3 seconds at 240°C
♦Electro-Optical
Characteristics [Ta=25°C]
Item
Symbol Condition
Minimum
Typical
3.30
10.0
3200
9.0
505
35
±15
Maximum
3.80
10
Unit
V
uA
mW
mcd
mW/sr
nm
nm
deg.
Forward Voltage
V
F
I
F
=20mA
Reverse Current
I
R
V
R
=5V
Total Radiated Power
P
O
I
F
=20mA
Brightness
I
V
I
F
=20mA
Radiant Intensity
I
E
Ｉ
F
=20mA
Peak Wavelength
500
I
F
=20mA
λ
P
Half Width
I
F
=20mA
∆λ
Viewing Half Angle
I
F
=20mA
θ
1/2
‡Total Radiated Power is measured by Photodyne #500
‡Brightness is measured by Tektronix J-16.
510
EPITEX INC. : 66-3, Minamikawabe-Cho, Higashi-Kujyo, Minami-Ku, Kyoto, Japan
Tel.: ++81-75-682-2338 Fax: ++81-75-682-2267
e-mail: sales-dep@epitex.com
http://www.epitex.com
epitex
300
250
Temperature [C°]
200
150
100
50
0
0
50
Opto-Device & Custom LED
TOP LED SMT505-23
♦SMD
Application
Recommended reflow soldering profile
10s
235°C
200°C
150°C
50s
Recommended Land Layout (Unit: mm)
60s
100
120s
40s
40s 30s
250
300
150
200
Time [s]
Solder within 4days after opening the aluminum laminated bag and
storage the circumstance of less than 30℃ and 50%RH during 4days.
♦SMD
Packing
Tape and Reel Dimensions (Unit: mm)
♦Wrapping
Moisture barrier bag aluminum laminated film with a desiccant to keep out the moisture absorption
during the transportation and storage.
EPITEX INC. : 66-3, Minamikawabe-Cho, Higashi-Kujyo, Minami-Ku, Kyoto, Japan
Tel.: ++81-75-682-2338 Fax: ++81-75-682-2267
e-mail: sales-dep@epitex.com
http://www.epitex.com
