F210-50.000-AE0 datasheet, PDF

Datasheet> All Categories > Passive components> oscillator> F210-50.000-AE0

F210-50.000-AE0: DescriptionHCMOS Output Clock Oscillator, 50MHz Nom, ROHS COMPLIANT PACKAGE-4; CategoryPassive components oscillator; File Size189KB，2 Pages; ManufacturerFOX [Fox Electronics]; Environmental Compliance

Download Datasheet Parametric View All

F210-50.000-AE0 Overview

HCMOS Output Clock Oscillator, 50MHz Nom, ROHS COMPLIANT PACKAGE-4

F210-50.000-AE0 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
package instruction	ROHS COMPLIANT PACKAGE-4
Reach Compliance Code	compliant
ECCN code	EAR99
Other features	ENABLE/DISABLE FUNCTION; TAPE AND REEL
maximum descent time	10 ns
Frequency Adjustment - Mechanical	NO
frequency stability	100%
JESD-609 code	e4
Installation features	SURFACE MOUNT
Nominal operating frequency	50 MHz
Maximum operating temperature	70 °C
Minimum operating temperature	-10 °C
Oscillator type	HCMOS
Output load	15 pF
physical size	2.5mm x 2.0mm x 0.8mm
longest rise time	10 ns
Maximum supply voltage	1.89 V
Minimum supply voltage	1.71 V
Nominal supply voltage	1.8 V
surface mount	YES
maximum symmetry	55/45 %
Terminal surface	Gold (Au)
Base Number Matches	1

Preview

Download Datasheet

View All

HCMOS 2.5x2mm 1.8V Oscillator

Model: F210 SERIES

Page 1 of 2

RoHS Compliant / Pb Free

Rev. 10/23/2008

http://www.foxonline.com/need_a_sample.htm

FEATURES

• 1.8V Operation

• Standby Function

• Tape and Reel

(3,000 pcs. STD)

• PART NUMBER SELECTION

Learn More - Internet Required

Part Number

819-Frequency-xxxxx

819A-Frequency-xxxxx

819B-Frequency-xxxxx

819C-Frequency-xxxxx

819D-Frequency-xxxxx

Model Frequency

Operating

Number Stability

Temperature (ºC)

±100PPM

-10 ~ +70

F210

-40 ~ +85

F210R

±100PPM

±50PPM

-10 ~ +70

F215

±50PPM

-40 ~ +85

F215R

±25PPM

-10 ~ +70

F216

Frequency

Range (MHz)

0.750 ~ 50.000

2.5±0.1

2.0±0.1

• ELECTRICAL CHARACTERISTICS

PARAMETERS

Frequency Range (F

)

Storage Temperature Range (T

stg

)

Supply Voltage

)

Input Current

)

0.750 ~ 10.000 MHz

10.000+ ~ 20.000 MHz

20.000+ ~ 30.000 MHz

30.000+ ~ 40.000 MHz

40.000+ ~ 50.000 MHz

Output Symmetry (50% V

)

Rise Time (10% ~ 90% V

)

Fall Time (90% ~ 10% V

)

Output Voltage

)

Output Current

)

Output Load

(HCMOS)

Standby Current

Start-up Time

)

Output Disable Time

Output Enable Time

Reflow Soldering Temp

Moisture Sensitivity Level (MSL)

Termination Finish

MAX

(unless otherwise noted)

0.750 ~ 50.000 MHz

-55ºC ~ +100ºC

1.8V ± 5%

2.5mA

3.5mA

4.0mA

4.5mA

5.0mA

45% ~ 55%

10nS

10% V

90% V

Min

2mA Min

-2mA Min

15pF

10µA

10mS

10uS

10mS

260ºC / 10 Seconds

0.78

0.8±0.1

0.65

0.68

0.95

Recommended

Solder Pad Layout

0.95

0.8

0.65

0.9

Inclusive of 25ºC tolerance, operating temperature range, input voltage change, load change, shock,

and vibration.

An internal pullup resistor from pin 1 to pin 4 allows active output if pin 1 is left open.

Note: A 0.01µF capacitor should be placed between V

(Pin 4) and GND (Pin2) to minimize

power supply noise.

Drawing is for reference to critical specifications defined by size measurements.

Certain non-critical visual attributes, such as side castellations, reference pin shape, etc. may

vary. All specifications subject to change without notice.

All dimensions are in millimeters.

Pin Connection

#1 E/D

#2 GND

#3 Output

FOXElectronics

5570 Enterprise Parkway Fort Myers, Florida 33905 USA +1.239.693.0099 FAX +1.239.693.1554

http://www.foxonline.com

EMEA

Tel/Fax: +44 .1767.312632 |

Asia

Hong Kong Tel: +852.2854.4285 Fax +852.2854.4282

Japan

Tel: +81.3.3374/2079 Fax: +81.3.3374.5221
