51724-10601204A0LF |
51724-10601603A0LF |
51724-10200403A0 |
51724-10202003A0LF |
51724-10202003A0 |
51724-10202400A0 |
51724-10302004A0 |
51724-10601204A0 |
| Description |
PwrBlade®, Power Supply Connectors, 6P 12S 4P STB Right Angle Header. |
Board Connector, 25 Contact(s), 4 Row(s), Male, Right Angle, Solder Terminal, Locking |
Board Connector, 9 Contact(s), 4 Row(s), Male, Right Angle, Solder Terminal, Locking |
Board Connector, 25 Contact(s), 4 Row(s), Male, Right Angle, Solder Terminal, Locking |
Board Connector, 25 Contact(s), 4 Row(s), Male, Right Angle, Solder Terminal, Locking |
Board Connector, 26 Contact(s), 4 Row(s), Male, Right Angle, Solder Terminal |
Board Connector, 27 Contact(s), 4 Row(s), Male, Right Angle, Solder Terminal, Locking |
Board Connector, 22 Contact(s), 4 Row(s), Male, Right Angle, Solder Terminal, Locking |
| Reach Compliance Code |
compliant |
compliant |
compliant |
compliant |
compliant |
compliant |
compliant |
compliant |
| Other features |
TERMINAL PITCH FOR POWER CONTACT: 6.35 MM |
TERMINAL PITCH FOR POWER CONTACT: 6.35 MM |
TERMINAL PITCH FOR POWER CONTACT: 6.35 MM |
TERMINAL PITCH FOR POWER CONTACT: 6.35 MM |
TERMINAL PITCH FOR POWER CONTACT: 6.35 MM |
TERMINAL PITCH FOR POWER CONTACT: 6.35 MM |
TERMINAL PITCH FOR POWER CONTACT: 6.35 MM |
TERMINAL PITCH FOR POWER CONTACT: 6.35 MM |
| Connector type |
BOARD CONNECTOR |
BOARD CONNECTOR |
BOARD CONNECTOR |
BOARD CONNECTOR |
BOARD CONNECTOR |
BOARD CONNECTOR |
BOARD CONNECTOR |
BOARD CONNECTOR |
| Contact to complete cooperation |
NOT SPECIFIED |
NOT SPECIFIED |
NOT SPECIFIED |
NOT SPECIFIED |
NOT SPECIFIED |
GOLD (30) OVER NICKEL |
NOT SPECIFIED |
NOT SPECIFIED |
| Contact point gender |
MALE |
MALE |
MALE |
MALE |
MALE |
MALE |
MALE |
MALE |
| DIN compliance |
NO |
NO |
NO |
NO |
NO |
NO |
NO |
NO |
| Filter function |
NO |
NO |
NO |
NO |
NO |
NO |
NO |
NO |
| IEC compliance |
NO |
NO |
NO |
NO |
NO |
NO |
NO |
NO |
| MIL compliance |
NO |
NO |
NO |
NO |
NO |
NO |
NO |
NO |
| Manufacturer's serial number |
51724 |
51724 |
51724 |
51724 |
51724 |
51724 |
51724 |
51724 |
| Plug information |
MULTIPLE MATING PARTS AVAILABLE |
MULTIPLE MATING PARTS AVAILABLE |
MULTIPLE MATING PARTS AVAILABLE |
MULTIPLE MATING PARTS AVAILABLE |
MULTIPLE MATING PARTS AVAILABLE |
MULTIPLE MATING PARTS AVAILABLE |
MULTIPLE MATING PARTS AVAILABLE |
MULTIPLE MATING PARTS AVAILABLE |
| Mixed contacts |
YES |
YES |
YES |
YES |
YES |
YES |
YES |
YES |
| Installation method |
RIGHT ANGLE |
RIGHT ANGLE |
RIGHT ANGLE |
RIGHT ANGLE |
RIGHT ANGLE |
RIGHT ANGLE |
RIGHT ANGLE |
RIGHT ANGLE |
| Installation type |
BOARD |
BOARD |
BOARD |
BOARD |
BOARD |
BOARD |
BOARD |
BOARD |
| Number of rows loaded |
4 |
4 |
4 |
4 |
4 |
4 |
4 |
4 |
| Options |
GENERAL PURPOSE |
GENERAL PURPOSE |
GENERAL PURPOSE |
GENERAL PURPOSE |
GENERAL PURPOSE |
GENERAL PURPOSE |
GENERAL PURPOSE |
GENERAL PURPOSE |
| Terminal pitch |
2.54 mm |
2.54 mm |
2.54 mm |
2.54 mm |
2.54 mm |
2.54 mm |
2.54 mm |
2.54 mm |
| Termination type |
SOLDER |
SOLDER |
SOLDER |
SOLDER |
SOLDER |
SOLDER |
SOLDER |
SOLDER |
| Total number of contacts |
22 |
25 |
9 |
25 |
25 |
26 |
27 |
22 |
| UL Flammability Code |
94V-0 |
94V-0 |
94V-0 |
94V-0 |
94V-0 |
94V-0 |
94V-0 |
94V-0 |
| Is it Rohs certified? |
conform to |
conform to |
incompatible |
conform to |
incompatible |
- |
incompatible |
incompatible |
| body width |
0.574 inch |
0.574 inch |
0.574 inch |
0.574 inch |
0.574 inch |
- |
0.574 inch |
0.574 inch |
| subject depth |
0.93 inch |
0.93 inch |
0.93 inch |
0.93 inch |
0.93 inch |
- |
0.93 inch |
0.93 inch |
| body length |
2.89 inch |
2.74 inch |
1.44 inch |
1.84 inch |
1.84 inch |
- |
2.34 inch |
2.89 inch |
| Contact material |
NOT SPECIFIED |
NOT SPECIFIED |
NOT SPECIFIED |
NOT SPECIFIED |
NOT SPECIFIED |
- |
NOT SPECIFIED |
NOT SPECIFIED |
| Contact resistance |
20 mΩ |
20 mΩ |
20 mΩ |
20 mΩ |
20 mΩ |
- |
20 mΩ |
20 mΩ |
| Contact style |
HYBRID |
HYBRID |
HYBRID |
HYBRID |
HYBRID |
- |
HYBRID |
HYBRID |
| Dielectric withstand voltage |
2500VDC V |
2500VDC V |
2500VDC V |
2500VDC V |
2500VDC V |
- |
2500VDC V |
2500VDC V |
| Durability |
200 Cycles |
200 Cycles |
200 Cycles |
200 Cycles |
200 Cycles |
- |
200 Cycles |
200 Cycles |
| maximum insertion force |
.973 N |
.973 N |
.973 N |
.973 N |
.973 N |
- |
.973 N |
.973 N |
| Insulation resistance |
500000000 Ω |
500000000 Ω |
500000000 Ω |
500000000 Ω |
500000000 Ω |
- |
500000000 Ω |
500000000 Ω |
| insulator material |
GLASS FILLED POLYETHYLENE |
GLASS FILLED THERMOPLASTIC |
GLASS FILLED THERMOPLASTIC |
GLASS FILLED THERMOPLASTIC |
GLASS FILLED THERMOPLASTIC |
- |
GLASS FILLED THERMOPLASTIC |
GLASS FILLED THERMOPLASTIC |
| Installation option 1 |
LOCKING |
LOCKING |
LOCKING |
LOCKING |
LOCKING |
- |
LOCKING |
LOCKING |
| Number of connectors |
ONE |
ONE |
ONE |
ONE |
ONE |
- |
ONE |
ONE |
| Maximum operating temperature |
125 °C |
125 °C |
125 °C |
125 °C |
125 °C |
- |
125 °C |
125 °C |
| Minimum operating temperature |
-55 °C |
-55 °C |
-55 °C |
-55 °C |
-55 °C |
- |
-55 °C |
-55 °C |
| Plating thickness |
30u inch |
30u inch |
30u inch |
30u inch |
30u inch |
- |
30u inch |
30u inch |
| Rated current (signal) |
3 A |
3 A |
3 A |
3 A |
3 A |
- |
3 A |
3 A |
| Guideline |
UL |
UL |
UL |
UL |
UL |
- |
UL |
UL |
| reliability |
COMMERCIAL |
COMMERCIAL |
COMMERCIAL |
COMMERCIAL |
COMMERCIAL |
- |
COMMERCIAL |
COMMERCIAL |
| Terminal length |
0.135 inch |
0.135 inch |
0.135 inch |
0.135 inch |
0.135 inch |
- |
0.135 inch |
0.135 inch |
| Evacuation force-minimum value |
.17792 N |
.17792 N |
.17792 N |
.17792 N |
.17792 N |
- |
.17792 N |
.17792 N |
| Base Number Matches |
- |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
| Contact completed and terminated |
- |
- |
Tin/Lead (Sn/Pb) |
- |
Tin/Lead (Sn/Pb) |
TIN LEAD (100) OVER NICKEL |
Tin/Lead (Sn/Pb) |
Tin/Lead (Sn/Pb) |
| JESD-609 code |
- |
- |
e0 |
- |
e0 |
e0 |
e0 |
e0 |
