SAW Filter
Product number (please contact us)
FF-555 : Q51FF5550xxxx00
SAW FILTER
For Automotive
FF - 555
Frequency
range
:
300 MHz to 500 MHz
Thickness
:
1.5 mm Typ.
Applications
:
Remote keyless entry, RF
Excellent
shock resistance and environmental capability
(prevention for contamination)
Low-loss,
Narrow Pass bandwidth, High stability by using
crystal substrate.
Actual size
Specifications (characteristics)
Item
Nominal frequency range
Storage temperature
Operating temperature
Insertion Loss
Pass bandwidth
Attenuation
Turnover temperature
Temperature coefficient
Terminal impedance
Product Name
(Standard form)
Symbol
f_nom
T_stg
T_use
IL
P_Bw
G_Att
Ti
B
Zt
FF-555 433.920000MHz
①
②
①Model
②Frequency
Specifications
300 MHz to 500 MHz
-55
C
to +125
C
-40
C
to +85
C
3.5 dB Max.
f_nom
100 kHz Min.
f_nom -21.4 MHz 40 dB Min.
f_nom -10.7 MHz 40 dB Min.
+25
C 15 C
-(3.4 0.8)
10
-8
/
C
2
370
Typ.
160
Typ.
Conditions / Remarks
Storage as single product.
Reference to minimum loss
(3 dB down)
Ex : 315 MHz
Ex : 433.92 MHz
Test fixture
Remarks
Ex: f_nom =315 MHz
C=4 pF
L=33 nH
Ex: f_nom =433.92 MHz
C=5 pF
L=18 nH
50
C
L
SAW
50
C
L
External dimensions
(Unit:mm)
Footprint (Recommended)
(Unit:mm)
0.8
#2
#3
#4
#4
#3
#2
0.9
0.95
1.4
5.2 ±0.2
43392F
#1
#5
#5
#1
#8
#7
4.8 ±0.2
#6
#6
#7
1.27
2.54
#8
Pin map
2.54
Connection
IN, OUT
N.C.
GND
1.5 ±0.2
#1,#2,#5,#6 are connected to the cover.
Pin
3,7
4,8
1,2,5,6
3.5
4.4
E 129
