I P6
7
C omb inat ion D- SU B C on ne c t o r s
IP67
Combination
D-SUB
Solder cup – Precision machined contacts – For wire size AWG 20
Description
Signal contacts for wire size AWG 20
Contacts: high power or coaxial contacts
Mounting style:
with 4-40 UNC or M3 threaded insert
Quality class 3 (Also available in quality class 1)
Shell: Brass tin plated (Stainless steel on request)
Nickel plated die-cast frame
(Black plastic frame on request)
Suitable hex bolts are supplied loose
RoHS compliant – CSA listed, File No.: LR 115000-1 – UL listed, File No.: E202784
Socket connector
Shell size
1
2
3
4
5
Plug connector
A
+0.2
21.10
21.10
21.10
21.10
23.90
B
+0.2
39.40
47.70
61.40
77.90
75.50
C
25.00
33.30
47.04
63.50
61.10
+ 0.12
- 0.13
+ 0.15
- 0.10
± 0.13
± 0.13
+ 0.14
- 0.11
D2
+0.25
16.46
24.79
38.50
54.96
52.55
Shell size A
+0.2
1
2
3
4
5
21.10
21.10
21.10
21.10
23.90
B
+0.2
39.40
47.70
61.40
77.90
75.50
C
25.00
33.30
47.04
63.50
61.10
+ 0.12
- 0.13
+ 0.15
- 0.10
± 0.13
± 0.13
+ 0.14
- 0.11
D1
+0.25
E
-0.30
16.79
25.12
38.84
55.30
52.68
5.82
5.82
5.69
5.69
5.69
Shell size 1-4
Shell size 5
Shell size 1-4
Shell size 5
Order data
Socket connector
Design Mounting style 4-40 UNC
5W1
7W2
11W1
9W4
13W3
17W2
21W1
13W6
17W5
21WA4
25W3
27W2
24W7
36W4
43W2
47W1
Threaded insert
Threaded insert
Threaded insert
Threaded insert
Threaded insert
Threaded insert
Threaded insert
Threaded insert
Threaded insert
Threaded insert
Threaded insert
Threaded insert
Threaded insert
Threaded insert
Threaded insert
Threaded insert
High
power contact Part Number
10 A
10 A
10 A
10 A
10 A
10 A
10 A
10 A
10 A
10 A
10 A
10 A
10 A
10 A
10 A
10 A
6 005W1SAM 61 B30 X
6 007W2SAM 61 B30 X
6 011W1SAM 61 B30 X
6 009W4SAM 61 B30 X
6 013W3SAM 61 B30 X
6 017W2SAM 61 B30 X
6 021W1SAM 61 B30 X
6 013W6SAM 61 B30 X
6 017W5SAM 61 B30 X
6 21WA4SAM 61 B30 X
6 025W3SAM 61 B30 X
6 027W2SAM 61 B30 X
6 024W7SAM 61 B30 X
6 036W4SAM 61 B30 X
6 043W2SAM 61 B30 X
6 047W1SAM 61 B30 X
Plug connector
Design Mounting style 4-40 UNC
5W1
7W2
11W1
9W4
13W3
17W2
21W1
13W6
17W5
21WA4
25W3
27W2
24W7
36W4
43W2
47W1
Threaded insert
Threaded insert
Threaded insert
Threaded insert
Threaded insert
Threaded insert
Threaded insert
Threaded insert
Threaded insert
Threaded insert
Threaded insert
Threaded insert
Threaded insert
Threaded insert
Threaded insert
Threaded insert
High
power contact Part Number
10 A
10 A
10 A
10 A
10 A
10 A
10 A
10 A
10 A
10 A
10 A
10 A
10 A
10 A
10 A
10 A
Contact
High power 10 A
High power 20 A
6 005W1PAM 61 B30 X
6 007W2PAM 61 B30 X
6 011W1PAM 61 B30 X
6 009W4PAM 61 B30 X
6 013W3PAM 61 B30 X
6 017W2PAM 61 B30 X
6 021W1PAM 61 B30 X
6 013W6PAM 61 B30 X
6 017W5PAM 61 B30 X
6 21WA4PAM 61 B30 X
6 025W3PAM 61 B30 X
6 027W2PAM 61 B30 X
6 024W7PAM 61 B30 X
6 036W4PAM 61 B30 X
6 043W2PAM 61 B30 X
6 047W1PAM 61 B30 X
Code
61
62
For other contact configurations refer to part number creator.
=
=
