General Purpose Relays
SCHRACK
Miniature Power PCB Relay MSR
I
I
I
I
I
I
I
1 pole 8 / 10 A, 1CO or 1NO contact
High inrush currents with AgSnO contacts (TV4 = 65 A)
4 kV/8 mm coil-contact
Reinforced insulation (protection class II)
Ambient temperature up to 85°C at 8 A
Plastic materials according to IEC60335-1 (domestic appliances)
RoHS compliant (Directive 2002 / 95 / EC) as per
product date code 0404
Applications
HVAC, interface technology, power supplies, TV-/Monitor control,
computer-/communication technology, domestic appliances, Hi-Fi
products, timers
F0143-C
Approvals
V
REG.-Nr.
of
3919,
Z
on request
E214024
Technical data approved types
Contact data
1CO or 1NO
single contact
micro disconnection
versions A,B:
8A
versions C,D:
10 A
Rated voltage / max.switching voltage AC
240/400 VAC
Maximum breaking capacity AC
2000 VA
Limiting making capacity, max 20 ms
A302: 65 A
max 4 s, duty factor 10%
15 A
15 A
Contact material
AgSnO
2
, AgCdO
AgNi0,15*
Mechanical endurance
10x10
6
cycles
Rated frequency of operation with / without load
6 / 1200 min
-1
*not recommended for AC loads with arcing (CC2 according EN61810-2)
Contact ratings
Type
V23061-A1***-A302
V23061-C2***-A302
V23061-C2***-A302
V23061-A1***-A302
V23061-*****-A30*,
Load
8 A, 250 VAC, resistive load, 85°C, 1 mm mounting
distance, 6 cycles min
-1
, 50% duty factor, EN61810-1
10 A, 250 VAC, resistive load, 85°C, 0 mm mounting
distance, 6 cycles min
-1
, 50% duty factor, EN61810-1
5 A, 250 VAC, resistive load, 105°C, 0 mm mounting
distance, 6 cycles min
-1
, 50% duty factor, EN61810-1
TV-4 Tungsten, 120 VAC, UL508
240 VAC, A300, Pilot duty, UL508
Cycles
100x10
3
10x10
3
100x10
3
25x10
3
6x10
3
Contact configuration
Contact set
Type of interruption
Rated current
Coil data
Rated coil voltage range DC coil
Coil power DC coil
Operative range
Coil insulation system according UL1446
3...60 VDC
typ. 220 mW
2
Class A, Class F
Coil versions, DC-coil
Coil
Rated
Operate
Release
Coil
Rated coil
code
voltage
voltage
voltage
resistance
power
VDC
VDC
VDC
Ohm
mW
001
3
2.1
0.3
40+10%
225
002
5
3.4
0.5
118+10%
212
003
6
4.1
0.6
165+10%
218
004
9
6.1
0.9
364+10%
223
005
12
8.2
1.2
652+10%
221
007
24
16.3
2.4
2270+10%
254
009
48
32.6
4.8
8790+10%
262
010
60
40.8
6.0
15265+15%
236
All figures are given for coil without preenergization, at ambient temperature +23°C
Other coil voltages on request
1
Datasheet
Rev. GH1
Issued 2007/08
www.tycoelectronics.com
www.schrackrelays.com
Dimensions are in mm unless
otherwise specified and are
shown for reference purposes
only.
Product specification
according to IEC 61810-1.
Product data, technical para-
meters, test conditions and
processing information
only to be used together
with the 'Definitions' at
schrackrelays.com in the
‘Schrack’ section.
Specifications subject to
change.
General Purpose Relays
SCHRACK
Miniature Power PCB Relay MSR
(Continued)
Insulation
Dielectric strength coil-contact circuit
open contact circuit
Clearance / creepage coil-contact circuit
Material group of insulation parts
Insulation to IEC 60664-1
Type of insulation coil-contact circuit
open contact circuit
Rated insulation voltage
Pollution degree
Rated voltage system
Overvoltage category
CO contact
NO contact
PCB layout / terminal assignment
Bottom view on solder pins
4000 V
rms
1000 V
rms
W
8 / 8 mms
W
8 / 8 mm
IIIb
IIIb
reinforced
functional
250 V
3
230 V
III
2
400 V
reinforced
functional
250 V
3
230 / 400 V
III
1 CO contact, 3.2 mm
Other data
RoHS - Directive 2002/95/EC
compliant as per product date code 0404
Flammability class according to UL94
V-0
For WG version: GWFI to IEC 60335-1
> 850 °C
GWIT to IEC 60335-1
> 775 °C
Ambient temperature range
-40...+85°C
Operate- / release time
6 / 2,5 ms
Bounce time NO / NC contact
0,5 / 4 ms
Vibration resistance (function) NO / NC contact
10 / 4 g
Shock resistance (function) NO / NC contact
20 / 5 g
Shock resistance (destruction)
100 g
Category of protection
RTII-flux proof; RTIII- wash tight
Mounting
pcb
Mounting position
any
Minimum mounting distance
0 mm
Resistance to soldering heat flux-proof version
270°C / 10 s
wash-tight version
260°C / 5s
Relay weight
11 g
Packaging unit
20 / 1000 pcs
S0255-AA
S0255-AB
1 NO contact, 5 mm
S0255-AH
S0255-AI
Dimensions
1 CO contact, 3.2 mm
1 NO contact, 5 mm
S0275-AA
S0275-AH
2
Datasheet
Rev. GH1
Issued 2007/08
www.tycoelectronics.com
www.schrackrelays.com
Dimensions are in mm unless
otherwise specified and are
shown for reference purposes
only.
Product specification
according to IEC 61810-1.
Product data, technical para-
meters, test conditions and
processing information
only to be used together
with the 'Definitions' at
schrackrelays.com in the
‘Schrack’ section.
Specifications subject to
change.
General Purpose Relays
SCHRACK
Miniature Power PCB Relay MSR
(Continued)
Product key
Type
Version
A
1 NO contact, UL-class A
B
C
1 NO contact, UL-class F
D
Version
1
wash tight
2
Coil
Coil code: please refer to coil versions
Contact system
A
standard
Contact material
5
3
AgSnO
2
4
AgCdO
6
Contact configuration
01
1 CO contact
02
Other types on request
V 2 3 0 6 1 -
- A
1 CO contact, UL-class A
1 CO contact, UL-class F
flux proof
table
AgNi 0.15
AgCdO, gold plated
1 NO contact
Product key
V23061-A1002-A302
V23061-A1002-A502
V23061-A1003-A302
V23061-A1003-A502
V23061-A1005-A302
V23061-A1005-A502
V23061-A1005-A602
V23061-A1007-A302
V23061-A1007-A502
V23061-A1007-A602
V23061-A1009-A502
V23061-A1009-A602
V23061-A1010-A502
V23061-A1010-A602
V23061-B1002-A301
V23061-B1002-A501
V23061-B1002-A601
V23061-B1003-A501
V23061-B1003-A601
V23061-B1005-A301
V23061-B1005-A501
V23061-B1005-A601
V23061-B1007-A301
V23061-B1007-A501
V23061-B1007-A601
V23061-B1009-A301
V23061-B1009-A501
V23061-B1009-A601
V23061-B1010-A501
V23061-B1010-A601
V23061-A2002-A402
V23061-A2003-A402
V23061-A2005-A402
V23061-A2007-A402
V23061-A2009-A402
V23061-A2010-A402
V23061-B2002-A401
V23061-B2003-A401
V23061-B2005-A401
V23061-B2007-A401
V23061-B2009-A401
V23061-B2010-A401
Version
wash tight
Contacts
1 NO contact
1 CO contact
flux proof
1 NO contact
Contact material
AgSnO
2
AgNi 0.15
AgSnO
2
AgNi 0.15
AgSnO
2
AgNi 0.15
AgCdO gold pl.
AgSnO
2
AgNi 0.15
AgCdO gold pl.
AgNi 0.15
AgCdO gold pl.
AgNi 0.15
AgCdO gold pl.
AgSnO
2
AgNi 0.15
AgCdO gold pl.
AgNi 0.15
AgCdO gold pl.
AgSnO
2
AgNi 0.15
AgCdO gold pl.
AgSnO
2
AgNi 0.15
AgCdO gold pl.
AgSnO
2
AgNi 0.15
AgCdO gold pl.
AgNi 0.15
AgCdO gold pl.
AgCdO
Coil
5 VDC
6 VDC
12 VDC
24 VDC
48 VDC
60 VDC
5 VDC
6 VDC
12 VDC
24 VDC
48 VDC
60 VDC
5 VDC
6 VDC
12 VDC
24 VDC
48 VDC
60 VDC
5 VDC
6 VDC
12 VDC
24 VDC
48 VDC
60 VDC
1 CO contact
Part number
0-1393222-4
0-1393222-6
0-1393222-9
1-1393222-3
2-1393222-0
2-1393222-7
2-1393222-8
3-1393222-9
4-1393222-6
4-1393222-7
5-1393222-7
5-1393222-8
6-1393222-2
6-1393222-3
7-1393222-2
7-1393222-4
7-1393222-5
8-1393222-1
8-1393222-2
9-1393222-1
9-1393222-7
9-1393222-9
1-1393223-7
2-1393223-5
2-1393223-6
3-1393223-7
3-1393223-9
4-1393223-0
4-1393223-3
4-1393223-4
6-1393222-8
1-1416200-9
2-1416200-1
2-1416200-3
2-1416200-5
2-1416200-6
2-1416200-7
2-1416200-8
3-1416200-1
5-1393223-0
3-1416200-6
4-1416200-0
3
