1105W Series
Single Color Dome Lens Type
(High Reliability type, V-Series)
Product features
Package
Product features
3216 fixed lens type, Water clear epoxy
・Outer
Dimension 3.2 x 1.6 x 1.85mm( L x W x H )
・Wide
operation temperature range.
Storage Temperature : InGaN : -40℃½110℃
:
AlGaInP : -40℃½120℃
Operating Temperature : -40℃½100℃ Operation Guarantee
・Ramification
of luminosity group sorting. It is possible to have a
uniform transmission with little irregularities even when several are
lined up.
・Systematization
of luminosity groups and color tone groups.
Unified to a simple standard.
・Corresponding
to a use requiring high reliability in cars etc...
・Surface
Mount Type and Reverse Mount Type are possible.
・Shape
resin into a lens to make high luminosity possible.
・Lead–free
soldering compatible
・RoHS
compliant
Blue
Green
Yellow Green
Yellow
Orange
Red
:
:
:
:
:
:
470nm (VUB)
530nm (VUG) , 562nm(VYBG)
572nm (VYPY)
590nm (VFY)
605nm (VFA)
615nm (VFV) , 626nm (VFR)
Dominant wavelength
Spatial distribution
Die materials
Optical efficiency
VUB,VUG：20deg. VYBG,VYPY,VFY,VFA,VFV,VFR：40 deg.
VUB,VUG : InGaN
VUB : 10.9lm/W
VYBG : 1.3lm/W
VFY : 11.8lm/W
VFV : 13.2lm/W
VYBG, VYPY, VFY, VFA, VFV, VFR :AlGaInP
VUG : 23.6lm/W
VYPY : 4.8lm/W
VFA : 11.8lm/W
VFR : 11.8lm/W
Rank grouping parameter
Assembly methods (customer)
Soldering methods
Taping dimensions
ESD
Sorted by luminous intensity and wavelength and taped according
to rank.
Corresponding to surface mounter.
Corresponding to reflow soldering and manual soldering.
2,000pcs(standard) per reel in a 8mm width tape.
Reel diameter :
φ180mm
AlGaInP:2kV (HBM)
InGaN:1kV (HBM)
Recommended Applications
SW lighting for car indicators, meter panel, car audio and heater control, etc…
2007.8.31
Page 1
1105W Series
Single Color Dome Lens Type
(High Reliability type, V-Series)
Color Variations and Luminous Intensity
Dominant
Wavelength
λd
(nm)
TYP.
I
F
MIN.
(Ta=25℃)
Part No.
Material
Emitted
Color
Lens
Color
Luminous Intensity
Iv (mcd)
MAX.
I
F
Luminous Flux
φv(mlm)
TYP.
I
F
VUB1105W
VUG1105W
VYBG1105W
VYPY1105W
VFY1105W
VFA1105W
VFV1105W
VFR1105W
InGaN
InGaN
Blue
470
530
10
10
20
20
20
20
20
20
120
560
39
100
330
330
560
330
470
2,200
150
390
1,200
1,200
820
1,200
10
10
20
20
20
20
20
20
350
780
55
200
450
450
500
450
10
10
20
20
20
20
20
20
Green
AlGaInP
AlGaInP
AlGaInP
AlGaInP
AlGaInP
Red
AlGaInP
626
※Note
: The luminous intensity(I
v
) and dominant wavelength (λd
)
above are the setup
values of the sorting machine.
(Tolerance : I
V
…
±10%, λd
...
±1nm
)
562
Yellow
Green
Yellow
Orange
Water
Clear
572
590
605
615
2006.3.31
Page 2
1105W Series
Single Color Dome Lens Type
(High Reliability type, V-Series)
Absolute Maximum Ratings
Absolute Maximum Ratings
VUB
84
20
48
VUG
84
20
48
VYBG
81
30
100
1.0
3.33
5
VYPY
81
30
100
1.0
3.33
5
VFY
78
30
100
1.0
3.33
5
VFA
78
30
100
1.0
3.33
5
VFV
78
30
100
1.0
3.33
5
(Ta=25℃)
Item
Power Dissipation
Forward Current
Pulse Forward
Current
※
1
Derating
(Ta=75℃ or higher)
Reverse Voltage
Operating
Temperature
Storage Temperature
Symbol
P
d
I
F
I
FRM
⊿
I
F
⊿
I
FRM
V
R
T
opr
T
stg
VFR
78
30
100
1.0
3.33
5
Unit
mW
mA
mA
mA/℃
mA/℃
V
℃
℃
0.40
※
2
0.40
※
2
0.96
※
2
0.96
※
2
5
5
-40½ +100
-40½ +110
-40½+120
※1
I
FRM
Measurement condition : Pulse Width
≦1ms.,
Duty
≦
1/20.
※2
Temperature Condition: Ta=60℃ or higher.
Thermal Characteristics
Item
Junction Temperature
(MAX.)
Thermal Resistance
(TYP.)
(Junction/ ambient)
Symbol
Ratings
VUB
110
VUG
110
VYBG
120
VYPY
120
VFY
120
VFA
120
VFV
120
VFR
120
Unit
T
j
℃
R
(th j-a)
600
600
700
650
650
650
650
650
℃
/W
Thermal Resistance
(TYP.)
(Junction/ Solder Point)
R
(th j-s)
400
400
500
450
450
2
450
450
450
℃
/W
※R
th(j-a)
Measurement Condition / Substrate: FR4(t=1.6mm) Pattern Size: 16mm .
2009.3.27
Page 3
1105W Series
Single Color Dome Lens Type
(High Reliability type, V-Series)
Electro-Optical Characteristics
（VUB,VUG)
Characteristic
Ratings
VUB
TYP.
Forward Voltage
I
F
=10mA
V
F
MAX.
Reverse Current
Peak Wavelength
Dominant
Wavelength
Spectral Line Half
Width
Half Intensity Angle
V
R
=5V
I
F
=10mA
I
F
=10mA
I
F
=10mA
I
F
=10mA
I
R
λ
p
λ
d
⊿λ
2θ1/2
MAX.
TYP.
TYP.
TYP.
TYP.
3.8
100
465
470
26
20
3.8
100
522
530
35
20
μA
nm
nm
nm
deg.
3.3
VUG
3.3
V
(Ta=25℃)
Item
Conditions
Symbol
Unit
※Note:
The dominant wave length (λd) above is the setup value of the sorting machine.
（Tolerance
:
λd…±1nm）
Electro-Optical Characteristics
（VYBG,
VYPY, VFY, VFA, VFV, VFR)
Item
Conditions
Symbol
TYP.
Forward Voltage
I
F
=20mA
V
F
MAX.
Reverse Current
Peak Wavelength
Dominant
Wavelength
Spectral Line Half
Width
Half Intensity Angle
V
R
=5V
I
F
=20mA
I
F
=20mA
I
F
=20mA
I
F
=20mA
I
R
λ
p
λ
d
⊿λ
2θ1/2
MAX.
TYP.
TYP.
TYP.
TYP.
2.5
100
565
562
15
40
2.5
100
575
572
15
40
2.4
100
592
590
15
40
2.4
100
609
605
15
40
2.4
100
624
615
15
40
Characteristic Rating
VYBG
2.1
VYPY
2.1
VFY
1.9
VFA
1.9
VFV
1.9
(Ta=25℃)
VFR
1.9
Unit
V
2.4
100
635
626
15
40
μA
nm
nm
nm
deg.
※Note:
The dominant wave length (λd) above is the setup value of the sorting machine.
（Tolerance
:
λd…±1nm）
2006.3.31
Page 4
